Top View of Assembly
A
SECTION A-A
End View of Assembly
177.80
[7.00]
B
B
173.36
[6.83]
(Inner Box Width)
A
304.80
[12.00]
2.14
[.08]
101.60
[4.00]
4.83
.91
[.036]
(Wall Thickness)
SECTION B-B
Side View of Assembly
[.19]
Cover
302.97
[11.93]
(Inner Box Length)
101.60
[4.00]
92.08
[3.63]
99.77
[3.93]
(Inner Box Height)
285.75
[11.25]
293.67
[11.56]
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc.)
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
Bottom
NOTE
2.69
[.11]
100.69
[3.96]
Purchased assembly includes bottom, cover and 4 cover screws.
Bottom and cover are made from 0.036" Steel.
PART NUMBERS
81.86
[3.22]
1412X Enclosure
ASA 61 Grey Enclosure
ACCESSORIES
Plated Cover Screw s (Pkg 6)
[6-32 x 1/4" Self-Tapping Screw s]
1412X
1421J6
294.26
[11.59]
302.18
[11.90]
175.18
[6.90]
Dimensions:
mm
[inches]
1412X
