Type 12 Mild Steel Junction Box
1414 PH Series
Continuous Hinge Door with Clamps
Application
Designed for use as instrument enclosures, electric, hydraulic or pneumatic control
housings, electrical junction boxes or terminal wiring enclosures.
Provides a degree of protection from falling dirt, dust, oil and water.
Standards
UL 508A Type 12, 13
CSA Type 12, 13
Complies with
NEMA Type 12 and 13
JIC EGP-1-1967 unless marked¹
IEC 60529, IP54
Construction
Body formed from 16 gauge or 14 gauge steel. Covers are formed from 14 gauge steel.
Smooth, continuously welded seams without knockouts, cutouts or holes.
Welded brackets provide for enclosure mounting.
Continuously hinged cover is secured with stainless steel clamps and plated steel screws
Seamless poured-in place gasket.
Models larger than 4" x 4" include a removable 14 gauge inner panel.
Internal threaded weld studs are provided for mounting inner panels.
A bonding stud is provided on the door and a grounding stud is provided in the enclosure
Finish
Cover and enclosure are phosphatized and finished in ANSI 61 gray recoatable powder
coating.
Removable inner panel is finished in white powder coating.
Accessories
Inner Panels
Door Clamping Hardware
Heaters
Terminal Kit Assemblies
Swing Panel Kit
Ventilation
Filtered Fans
Type 1 Louvered Ventilating Plates
Temperature Controls
Ground Wire Kits
https://www.hammfg.com/electrical/products/industrial/1414ph
1/3
11/3/2017
Type 12 Mild Steel Junction Box (1414 PH Series) - Hammond Mfg.
Part No.
w/ Inner Panel
-
1414PHC¹
1414PHG
1414PHRG
-
1414PHC4¹
1414PHE
1414PHH4
1414PHI
1414PHRI
1414PHKC4
1414PHK
1414PHRK
1414PHG6
1414PHI6
1414PHJ6
1414PHL6
1414PHMH6
1414PHM6
1414PHRM6
1414PHN6
1414PHO6
1414PHRO6
1414PHK8
1414PHM8
1414PHO8
1414PHO10
Part No.
w/o Inner Panel
1414PHA¹
1414PHCLP¹
1414PHGLP
1414PHRGLP
1414PHA4¹
1414PHC4LP¹
1414PHELP
1414PHH4LP
1414PHILP
1414PHRILP
1414PHKC4LP
1414PHKLP
1414PHRKLP
1414PHG6LP
1414PHI6LP
1414PHJ6LP
1414PHL6LP
1414PHMH6LP
1414PHM6LP
1414PHRM6LP
1414PHN6LP
1414PHO6LP
1414PHRO6LP
1414PHK8LP
1414PHM8LP
1414PHO8LP
1414PHO10LP
A
4.00
6.00
8.00
6.00
4.00
6.00
6.00
8.00
10.00
8.00
12.00
12.00
10.00
8.00
10.00
10.00
12.00
14.00
14.00
12.00
16.00
16.00
14.00
12.00
14.00
16.00
16.00
B
4.00
4.00
6.00
8.00
4.00
4.00
6.00
8.00
8.00
10.00
6.00
10.00
12.00
6.00
8.00
10.00
12.00
8.00
12.00
14.00
10.00
14.00
16.00
10.00
12.00
14.00
14.00
C
3.00
3.00
3.50
3.50
4.00
4.00
4.00
4.00
4.00
4.00
4.00
5.00
5.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
8.00
8.00
8.00
10.00
D
-
4.88
6.75
4.88
-
4.88
4.88
6.75
8.75
6.88
10.75
10.75
8.88
6.75
8.75
8.75
10.75
12.75
12.75
10.88
14.75
14.75
12.88
10.75
12.75
14.75
14.75
E
-
2.88
4.88
6.75
-
2.88
4.88
6.88
6.88
8.75
4.88
8.88
10.75
4.88
6.88
8.88
10.88
6.88
10.88
12.75
8.88
12.88
14.75
8.88
10.88
12.88
12.88
F
-
2.51
31.00
31.00
-
3.51
3.51
3.51
3.51
3.51
3.51
4.51
4.51
5.51
5.51
5.51
5.51
5.51
5.51
5.51
5.51
5.51
5.51
7.51
7.51
7.51
9.51
G
4.75
6.75
8.75
6.75
4.75
6.75
6.75
8.75
1.75
8.75
12.75
12.75
1.75
8.75
1.75
1.75
12.75
14.75
14.75
12.75
16.75
16.75
14.75
12.75
14.75
16.75
16.75
H
2.00
2.00
4.00
6.00
2.00
2.00
4.00
6.00
6.00
8.00
4.00
8.00
10.00
4.00
6.00
8.00
10.00
6.00
10.00
12.00
8.00
12.00
14.00
8.00
10.00
12.00
12.00
J
2.64
2.64
3.14
3.14
3.64
3.64
3.64
3.64
3.64
3.64
3.64
4.64
4.64
5.64
5.64
5.64
5.64
5.64
5.64
5.64
5.64
5.64
5.64
7.64
7.64
7.64
9.64
L
5.50
7.50
9.50
7.50
5.50
7.50
7.50
9.50
11.50
9.50
13.50
13.50
11.50
9.50
11.50
11.50
13.50
15.50
15.50
13.50
17.50
17.50
15.50
13.50
15.50
17.50
17.50
P
1.50
2.50
1.00
2.50
1.50
2.50
2.50
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
T
3.00
3.00
5.00
7.00
3.00
3.00
5.00
7.00
7.00
9.00
5.00
9.00
11.00
5.00
7.00
9.00
11.00
7.00
11.00
13.00
9.00
13.00
15.00
9.00
11.00
13.00
13.00
U
-
0.31
0.31
0.25
-
0.31
0.31
0.31
0.31
0.25
0.31
0.31
0.25
0.31
0.31
0.31
0.31
0.31
0.31
0.25
0.31
0.31
0.25
0.31
0.31
0.31
0.31
V
-
0.31
0.25
0.31
-
0.31
0.31
0.25
0.25
0.31
0.25
0.25
0.31
0.25
0.25
0.25
0.25
0.25
0.25
0.31
0.25
0.25
0.31
0.25
0.25
0.25
0.25
Y
-
0.56
0.63
0.56
-
0.56
0.56
0.63
0.63
0.56
0.63
0.63
0.56
0.63
0.63
0.63
0.63
0.63
0.63
0.56
0.63
0.63
0.56
0.63
0.63
0.63
0.63
Z
-
0.56
0.56
0.63
-
0.56
0.56
0.56
0.56
0.63
0.56
0.56
0.63
0.56
0.56
0.56
0.56
0.56
0.56
0.63
0.56
0.56
0.63
0.56
0.56
0.56
0.56
¹ Does not meet JIC Requirements
Data subject to change without notice
© 2017. Hammond Manufacturing Ltd. All rights reserved.
https://www.hammfg.com/electrical/products/industrial/1414ph
2/3
