11/18/2017
Type 1 Mild Steel 3 Piece Wallmount Enclosure (N1W S Series) - Hammond Mfg.
Quality Products. Service Excellence.
Type 1 Mild Steel 3 Piece Wallmount Enclosure
N1W S Series
Hinge Door with Quarter Turn
Application
Designed for indoor use to enclose controls, instruments, and components which do not
require oil-tight or dust-tight protection.
Ideal for applications where components may be easily mounted and wired prior to
installation of wrapper and door.
Standards
UL 50 Type 1
CSA Type 1
Complies with
NEMA Type 1
IEC 60529, IP20
Construction
Three piece assembly consisting of a base, wrapper, and door.
Components are attached and secured with metal screws.
14 gauge reverse formed base provides clearance for mounting hardware.
Wrapper is available in three depths: 4", 6", and 8".
Wrapper is formed from 16 gauge steel, with no knock-outs in the sides.
Door assembly formed from 16 gauge steel.
Removable door is mounted on slip hinges.
A bonding stud is provided on the door and a grounding screw is provided for the
enclosure.
Door is fastened with a slotted quarter turn latch.
Finish
Base, wrapper and door are finished in ANSI 61 gray powder coating.
Accessories
Type 1 Lock Kit
Padlock Adaptor
https://www.hammfg.com/electrical/products/commercial/n1ws
1/3
11/18/2017
Type 1 Mild Steel 3 Piece Wallmount Enclosure (N1W S Series) - Hammond Mfg.
Wrapper Size
Part No.
N1WS864
N1WS1084
N1WS12104
N1WS16124
N1WS20164
N1WS24204
N1WS866
N1WS1086
N1WS12106
N1WS16126
N1WS20166
N1WS24206
N1WS868
N1WS1088
N1WS12108
N1WS16128
N1WS20168
N1WS24208
8” Deep
6” Deep
4” Deep
A
8.00
10.00
12.00
16.00
20.00
24.00
8.00
10.00
12.00
16.00
20.00
24.00
8.00
10.00
12.00
16.00
20.00
24.00
B
6.00
8.00
10.00
12.00
16.00
20.00
6.00
8.00
10.00
12.00
16.00
20.00
6.00
8.00
10.00
12.00
16.00
20.00
C
4.00
4.00
4.00
4.00
4.00
4.00
6.00
6.00
6.00
6.00
6.00
6.00
8.00
8.00
8.00
8.00
8.00
8.00
D
8.75
10.80
12.80
16.80
20.80
24.80
8.80
10.80
12.80
16.80
20.80
24.80
8.80
10.80
12.80
16.80
20.80
24.80
Mounting Centers
E
5.00
7.00
9.00
11.00
15.00
19.00
5.00
7.00
9.00
11.00
15.00
19.00
5.00
7.00
9.00
11.00
15.00
19.00
P
6.28
8.28
10.28
12.28
16.28
20.28
6.28
8.28
10.28
12.28
16.28
20.28
6.28
8.28
10.28
12.28
16.28
20.28
R
4.16
4.16
4.16
4.16
4.16
4.16
6.16
6.16
6.16
6.16
6.16
6.16
8.16
8.16
8.16
8.16
8.16
8.16
Overall Dimensions
S
9.50
11.50
13.50
17.50
21.50
25.50
9.50
11.50
13.50
17.50
21.50
25.50
9.50
11.50
13.50
17.50
21.50
25.50
T
3.50
4.00
4.00
4.00
4.00
4.00
6.00
6.00
6.00
6.00
6.00
6.00
8.00
8.00
8.00
8.00
8.00
8.00
O
8.28
10.28
12.28
16.28
20.28
24.28
8.28
10.28
12.28
16.28
20.28
24.28
8.28
10.28
12.28
16.28
20.28
24.28
Data subject to change without notice
© 2017. Hammond Manufacturing Ltd. All rights reserved.
