121.44
[4.78]
107.00
[4.21]
B
66.94
[2.64]
36.00
[1.42]
INSIDE
HEIGHT
2.00
[.08]
WALL
THICKNESS
A
A
52.50
[2.07]
60.65
[2.39]
INSIDE
WIDTH
B
TOP VIEW
6.50
[.26]
LID HEIGHT
M3-0.5 X10mm
MACHINE SCREW
37.25
[1.47]
BOX HEIGHT
40.00
[1.57]
SECTION B-B
END VIEW
114.50
[4.51]
99.00
[3.90]
6.10
[.24]
4.34
[.17]
44.50
[1.75]
4.50
[.18]
115.15
[4.53]
INSIDE LENGTH
60.50
[2.38]
MAX SIZE PCB. FITS IN BOX OR IN LID
NOT SUPPLIED WITH ENCLOSURE
39.50
[1.56]
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc.)
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
(Part number and text placement/orientation on our products are subject to change,
we do not recommend using them as a locating reference for modification purposes)
SECTION A-A
SIDE VIEW
118.98
[4.68]
R3.50
[.14]
84.50
[3.33]
114.57
[4.51]
3.50
NOTE
Purchased assembly includes box, lid, 4 cov screws and installed brass inserts.
er
Enclosure molded from FRABS UL 94-V0 Plastic.
Other materials / colours av
ailable consult factory.
Recommended Torque : (43-50) Ozf.in / (30-35) cN.m
[.14]
PART NUM
BERS
64.48
[2.54]
5.00
[.20]
39.50
[1.56]
60.07
[2.36]
5.00
39.50
[1.56]
[.20]
1591XXC Enclosure
1591X CBK
X
1591X CGY
X
ACCESSORIES
1591MS100BK (Pkg 100)
Black Cov Screws [M3-0.5 X10mm]
er
Plated Cov Screws [M3-0.5 X10mm]
er
1591MS100 (Pkg 100)
P.C. Board Screws
1593ATS50 (Pkg 50)
1593ATS100 (Pkg 100)
[#4 x 1/4" self-tapping (6.4mm)]
Black Textured Enclosure
Gray Textured Enclosure
84.50
[3.33]
INSIDE BOX
M3-0.5
BRASS INSERTS
INSTALLED
BOX AND LID PCB POSTS
ACCEPT #4 X1/4"
SELF-TAPPING SCREW
84.50
[3.33]
4X
3.50 THRU
6.00 X 82°
INSIDE LID
Dimensions:
mm
[inches]
1591XXC
www.hammondmfg.com
®
