Type 3R Painted Galvanized Steel Junction Box
C3R HCR SM Series
Hinge Door with Snap Latch and w/ Knockouts
Application
Designed for use as a wiring/junction box.
Provides protection against rain, sleet, snow and dripping water.
Standards
UL-50 Type 3R
CSA Type 3R
Complies with
NEMA Type 3R
IEC 60529, IP24
Construction
Formed and spot welded from 16 gauge galvanized steel.
Drip-shield top and seam-free sides, front and back.
Galvanized steel hinge has stainless steel pin.
Provisions for padlocking on zinc-plated draw pull catch.
Easily removed knockouts on bottom of enclosure.
Panel studs provided for mounting optional panels.
External mounting feet.
Oil resistant gaskets are permanently secured.
Finish
Enclosure and cover are finished in ANSI 61 gray powder coating.
https://www.hammfg.com/electrical/products/commercial/c3rhcrsm
1/2
11/20/2017
Type 3R Painted Galvanized Steel Junction Box (C3R HCR SM Series) - Hammond Mfg.
Optional Panel Part
Part No.
C3R644HCR
C3R664HCR
C3R864HCR
C3R886HCR
C3R1086HCR
C3R12106HCR
C3R12126HCR
Number
N1JP64
N1JP66
N1JP86
N1JP88
N1JP108
N1JP1210
N1JP1212
A
6.00
6.00
8.00
8.00
B
4.00
6.00
6.00
8.00
C
4.00
4.00
4.00
6.00
6.00
Overall
Panel Size Mounting Dimensions Knockout
D
4.25
4.25
6.25
6.25
8.25
E
2.25
4.25
4.25
6.25
6.25
F
7.00
7.00
9.00
9.00
11.00
13.00
13.00
13.00
G
8.00
8.00
10.00
10.00
12.00
H
5.10
7.10
7.10
9.10
9.10
Pattern
2-3-4
2-3-4
2-3-4
6-7-8-9
6-7-8-9
10.00 8.00
12.00 10.00 6.00 10.25 8.25
12.00 12.00 6.00 10.25 10.25
12.00 12.00 10.00 10.25 10.25
14.00 11.10 3-4-5-6-7
14.00 13.10 3-4-5-6-7
14.00 13.10 3-4-5-6-7
C3R121210HCR N1JP1212
Data subject to change without notice
