1.75 in
44 mm
TYP
1.97 in
50 mm
TYP
O
16X
.31 in
8 mm
1.16 in
29 mm
TYP
9.91 in
252 mm
19.81 in
503 mm
5
1.66 in
42 mm
TYP
6
3.00 in
76 mm
TYP
2X
.44 in
11 mm
O
19.81 in
503 mm
1
TOP VIEW
20.00 in
508 mm
4
2.00 in
51 mm
3.00 in
76 mm
66.12 in
1680 mm
63.12 in
1603 mm
36U
18.32 in
465 mm
19" MTG
Item Number
1
DNRRLDK - BASE
DNRRLDK - L.H. RAIL
DNRRLDK - R.H. RAIL
DNRRLDK - TOP ANGLE
DNRRLDK - L.H. SUPPORT GUSSET
DNRRLDK -RL.H. SUPPORT GUSSET
SCREW 1/4-20 X 5/8 RND HD ZP
1/4" FLAT WASHER
NUT 1/4-20 KEP
Title
Quantity
1
1
1
1
1
1
16
16
16
#10-32 UNF
STANDARD EIA SPACING.
(FRONT FLANGE ONLY)
17.82 in
453 mm
OPENING
3
6.00 in
152 mm
1.00 in
25 mm
10.75 in
273 mm
2
3
4
5
6
7
8
9
DNRR1963LDK
PART NUMBERS
PAINTED BLACK THIN FILM
2
FRONT VIEW
SIDE VIEW
9
8
7
NOTES
Shipped knockdown for handling ease & protection
See Hammond Website for Additional Accessories
Data subject to change without notice. Isometric drawing not to scale.
www.hammondmfg.com
PART NO.
DNRR1963LDK
