175.00
[6.89]
A
163.00
[6.42]
53.00
[2.09]
(INSIDE
DEPTH)
4.00
[.16]
(AVERAGE
WALL
THICKNESS)
68.00
[2.68]
70.76
[2.79]
80.00
[3.15]
(INSIDE
WIDTH)
B
B
A
TOP VIEW
20.00
[.79]
60.00
[2.36]
SECTION A-A
END VIEW
2.00
[.08]
163.00
[6.42]
147.01
[5.79]
42.00
[1.65]
165.76
[6.53]
(INSIDE LENGTH
)
68.00
[2.68]
68.00
[2.68]
44.03
[1.73]
C
UL
O
®
US LISTED
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc.)
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
FILE #E65324
NEMA 4, 4X
SECTION B-B
SIDE VIEW
167.07
[6.58]
151.07
[5.95]
NOTE
163.00
[6.42]
Purchased assembly includes box, lid, silicone gasket,
4 cover screws and 3 ground screws with washers.
Box and lid are made from Diecast Aluminum Alloy.
Recommended cover screw Torque 5-7.5 lbf.in ( 50 -75 cN.m)
INSIDE LID
C
ACCEPTS M4 - 0.7
MACHINE SCREW
8.00
[.31]
13.50
[.53]
1590Z135
1590Z135 Enclosure
Basic Enclosure
Black Enclosure
20.00
[.79]
52.00
[2.05]
163.00
[6.42]
48.07 72.07
[1.89] [2.84]
7.44 4.40
[.29] [.17]
10.00
[.39]
Grey Enclosure - RAL7001 Gloss
1590Z135
1590Z135BK
1590Z135GY
1590Z135G
ACCESSORIES
Pre-Formed Silicone Gasket
Copper Ground Hardware (2 Pack)
[M4 - 0.7 X 6mm / M4 Washer]
SCGM4
ACCEPTS
M4 MACHINE
GROUND SCREW
C
SECTION C-C
MOUNTING HOLE
Dimensions:
mm
[inches]
®
INSIDE BOX
1590Z135
