Product data sheet
Characteristics
XAPM4508
die-cast empty control station - XAPM - Ø22-
zinc alloy- 8 openings in 2 columns
Main
Range of product
Product or component
type
Device short name
Product destination
Product front plate size
Usable depth
Number of cut-out
Colour of base of en-
closure
Colour of cover
Material
Cable entry
Product mounting
IP degree of protection
Harmony XAP
Die-cast empty control station
XAPM
For Ø 22 mm control and signalling units
80 x 220 mm
74.5 mm
8 cut-outs
Blue
Blue
1 hole without blanking plug for cable gland <= 18
mm
Flush mounting
IP657 conforming to NF C 20-010
IP65 conforming to IEC 60529
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
Zinc alloy
Complementary
Number of vertical rows
Product weight
2
1.37 kg
Environment
Protective treatment
Ambient air temperature for storage
Ambient air temperature for operation
Class of protection against electric shock
TC
-40...70 °C
-25...70 °C
Class I conforming to NF C 20-030
Class I conforming to IEC 60536
Aug 10, 2016
1
Product data sheet
Dimensions Drawings
XAPM4508
Dimensions and Fixing
(1)
(3)
P
a
mm
80
1 hole, without blanking plug, for cable gland with 18 mm/0.71 in. maximum clamping capacity
2 x Ø 5.6 mm/0.22 in. holes, depth 20 mm/0.78 in.
Usable depth
b
in.
3.15
mm
220
in.
6.89
c
mm
77
in.
3.03
G
mm
50
in.
1.97
H
mm
205
in.
8.07
P
mm
74.5
in.
2.93
Refer to the product characteristics to get the number of cut-outs.
Cut-out interaxis dimensions (vertical mounting)
b1
b2
Vertical interaxis: 40 mm/1.57 in.
Horizontal interaxis: 30 mm/1.18 in.
2
