Top View of Assembly
59.43
[2.340]
(Center Inlay Width)
SECTION B-B
(Side View Inside Assembly)
27.00
[1.063]
(Inner Box Height)
B
117.24
[4.616]
100.43
[3.954]
(Inlay Length)
5.00
[.197]
(Boss Height)
R353.48
[13.917]
Top Cover
Bottom Cover
52.35
[2.061]
B
(End Inlay Width)
78.97
[3.109]
Inside of Bottom Cover
40.00
[1.575]
End View of Assembly
Bottom Cover
.50
[.020]
(Inlay Depth)
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc.)
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
(Part number and text placement/orientation on our products are subject to change,
we do not recommend using them as a locating reference for modification purposes)
NOTE
57.83
[2.277]
56.47
[2.223]
56.68
[2.232]
70.46
[2.774]
63.22
(Inner Box Width
[2.489]
at Center)
(Inner Box Width
at End)
Enclosure molded from GP ABS Plastic.
Purchased assembly includes Top, Bottom, front plastic panel, Battery
Door, battery spring clips (4 pcs), 9V adapter (1pcs) and 2 cover screws.
(P.C. Board not supplied)
Recommended Cover screw torque -- 2.5 lbf-in (30 cN-m)
Front Panel
5.50
PART NUMBER
1553C Battery Enclosure
32.00
[1.260]
108.91
[4.288]
(Inner Box Length)
[.217]
Black Enclosure/Grey Over‐mold
Grey Enclosure/Grey Over‐mold
ACCESSORIES
Oval Head Cover Screws Self-Tapping (Pkg 100)
[#4 X 1" (25.4mm)]
P.C. Board Self Tapping Screw
[#4 X 1/4" (6.4mm) Plated]
1553CBKBAT
1553CGYBAT
SC1553C100 (Silver)
SC1553C100BK (Black)
1593ATS50 (Pkg 50)
1593ATS100 (Pkg 100)
1599CLIP (Black)
1599CLIPGY (Grey)
BS61
1553HDR‐BKIT
27.50
[1.083]
Front Panel
65.28
[2.570]
3.20
Maximum P.C. Board Size
78.18
[3.078]
[.126]
Belt or Pocket Clip
68.73
[2.706]
56.75
[2.234]
6.33
62.48
[2.460]
24.50
[.965]
[.249]
56.68
[2.232]
60.78
[2.393]
9V Battery Kit
AA Battery Clip Kit (4 positive and 4 Negative)
(Viewing Area)
(Viewing Area)
57.83
[2.277]
(NOT SUPPLIED)
2.75
[.108]
10.90
[.429]
40.00
[1.575]
R357.35
[14.069]
Dimensions:
mm
[inches]
1553CBAT
www.hammondmfg.com
®
