PA0146
Datasheet revision 1.0
www.Proto-Advantage.com
LLP-48 to DIP-48 SMT Adapter (0.5 mm pitch, 7 x 7 mm body)
DIMENSIONS
REF.
A
A2
B
C
D
E
F
G
H
MIN.
mm
TYP.
6.20
6.20
2.00
0.25
0.25
0.50
MAX.
MIN.
inches
TYP.
MAX.
0.600
0.100
0.025
Top View (SMT Footprint)
B
A
C
E
D
A2
(Representative drawing only - not to scale)
1
© 2009 Proto Advantage, a Concept to Life Solutions Inc. Company
Bottom View (DIP Pins)
F
H
G
(Representative drawing only - not to scale)
Side View (DIP Pins)
F
(Representative drawing only - not to scale)
2
© 2009 Proto Advantage, a Concept to Life Solutions Inc. Company
