18 Vdc to 36 Vdc or 36 Vdc to 75 Vdc Inputs, 10 W and 15 W
Features
n
Low profile: 10.2 mm x 25.4 mm x 50.8 mm
(0.4 in. x 1.0 in. x 2.0 in.) with standoffs
(9.6 mm (0.38 in.) with standoffs recessed)
Wide input voltage range: 18 Vdc to 36 Vdc or
36 Vdc to 75 Vdc
Output current limiting, unlimited duration
Output overvoltage clamp
Undervoltage lockout
Input-to-output isolation: 1500 V
Operating case temperature range: –40 °C to
+105 °C
UL*
1950 Recognized,
CSA
†
22.2 No. 950-95
Certified, IEC950, and VDE0805 Licensed
CE mark meets 73/23/EEC and 93/68/EEC
directives
‡
Within FCC and VDE Class A radiated limits
n
n
n
n
n
n
The LC/LW010- and LC/LW015-Series Power Modules use
advanced, surface-mount technology and deliver high-qual-
ity, compact, dc-dc conversion at an economical price.
n
n
Options
n
n
n
n
n
Remote on-off
Choice of on/off configuration
Short pin: 2.8 mm ± 0.25 mm (0.110 in. ± 0.010 in.)
Synchronization (cannot be ordered on units with
remote on/off)
Output voltage adjust: 90% to 110% of V
O, nom
(single outputs only)
Tight output voltage tolerance
Applications
n
n
n
n
Telecommunications
Distributed power architectures
Private branch exchange (PBX)
Voice and data multiplexing
n
n
Description
The L Single- and Dual-Output-Series Power Modules are low-profile, dc-dc converters that operate over an
input voltage range of 18 Vdc to 36 Vdc or 36 Vdc to 75 Vdc and provide one or two precisely regulated out-
puts. The outputs are isolated from the input, allowing versatile polarity configurations and grounding connec-
tions. The modules have a maximum power rating of 10 W to 15 W and efficiencies of up to 84% for a 5 V
output and 82% for a 3.3 V output. Built-in filtering for both input and output minimizes the need for external fil-
tering.
*
UL
is a registered trademark of Underwriters Laboratories, Inc.
†
CSA
is a registered trademark of Canadian Standards Association.
‡ This product is intended for integration into end-use equipment. All the required procedures for CE marking of end-use equipment should be followed. (The CE mark is placed on selected products.)
LC/LW010- and LC/LW015-Series Power Modules:
18 Vdc to 36 Vdc or 36 Vdc to 75 Vdc Inputs, 10 W and 15 W
Data Sheet
March 27, 2008
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are abso-
lute stress ratings only. Functional operation of the device is not implied at these or any other conditions in excess
of those given in the operations sections of the data sheet. Exposure to absolute maximum ratings for extended
periods can adversely affect device reliability.
Parameter
Input Voltage:
Continuous
Transient (100 ms)
Operating Case Temperature
(See Derating Curves, Figures 43—45.)
Storage Temperature
I/O Isolation
Device
LC
LW
LW
All
All
All
Symbol
V
I
V
I
V
I, trans
T
C
T
stg
—
Min
0
0
0
–40
–55
—
Typ
—
—
—
—
—
—
Max
50
80
100
105*
125
1500
Unit
Vdc
Vdc
V
°C
°C
Vdc
* Maximum case temperature varies based on power dissipation. See derating curves, Figures 43—45, for details.
Electrical Specifications
Table 1. Input Specifications
Parameter
Operating Input Voltage
Maximum Input Current
(V
I
= 0 to V
I, max
; I
O
= I
O, max
; see Figures
1—4.)
Inrush Transient
Input Reflected-ripple Current
(5 Hz to 20 MHz; 12 µH source imped-
ance; T
A
= 25 °C; see Figure 33.)
Input Ripple Rejection (100 Hz—120 Hz)
Fusing Considerations
CAUTION: This power module is not internally fused. An input line fuse must always be used.
This encapsulated power module can be used in a wide variety of applications, ranging from simple stand-alone
operation to an integrated part of a sophisticated power architecture. To preserve maximum flexibility, internal fus-
ing is not included; however, to achieve maximum safety and system protection, always use an input line fuse. The
safety agencies require a normal-blow, dc fuse with a maximum rating of 5 A (see Safety Considerations section).
Based on the information provided in this data sheet on inrush energy and maximum dc input current, the same
type of fuse with a lower rating can be used. Refer to the fuse manufacturer’s data for further information.
Device
LC
LW
LC
LW
All
All
Symbol
V
I
V
I
I
I, max
I
I, max
I
2
t
I
I
Min
18
36
—
—
—
—
Typ
24
48
—
—
—
5
Max
36
75
1.6
800
0.2
—
Unit
Vdc
Vdc
A
mA
A
2
s
mAp-p
All
—
—
45
—
dB
2
Lineage Power
Data Sheet
March 27, 2008
LC/LW010- and LC/LW015-Series Power Modules:
18 Vdc to 36 Vdc or 36 Vdc to 75 Vdc Inputs, 10 W and 15 W
Electrical Specifications
(continued)
Table 2. Output Specifications
Parameter
Output Voltage Set Point
(V
I
= V
I, nom
; I
O
= I
O, max
; T
A
= 25 °C)
Device Code
or Suffix
D
G*
F
A
B
C
AJ
BK
CL
Output Voltage
(Over all line, load, and temperature
conditions until end of life; see
Figures 35 and 37.)
D
G*
F
A
B
C
AJ
BK
CL
Output Regulation
(See Figures 5—11):
Line (V
I
= V
I, min
to V
I, max
)
Load (I
O
= I
O, min
to I
O, max
)
Load (I
O
= I
O, min
to I
O, max
)
Temperature
(T
C
= –40 °C to +85 °C)
Output Ripple and Noise
(Across 2 x 0.47 µF ceramic capaci-
tors; see Figures 34 and 36.):
RMS
Peak-to-peak (5 Hz to 20 MHz)
Symbol
V
O, set
V
O, set
V
O, set
V
O, set
V
O, set
V
O, set
V
O1, set
V
O2, set
V
O1, set
V
O2, set
V
O1, set
V
O2, set
V
O, set
V
O, set
V
O, set
V
O, set
V
O, set
V
O, set
V
O1, set
V
O2, set
V
O1, set
V
O2, set
V
O1, set
V
O2, set
Min
1.92
—
3.17
4.85
11.52
14.40
4.75
–4.75
11.40
–11.40
14.25
–14.25
1.90
—
3.13
4.80
11.40
14.25
4.5
–4.5
10.80
–10.80
13.50
–13.50
Typ
2.0
2.5
3.3
5.0
12.0
15.0
5.0
–5.0
12.0
–12.0
15.0
–15.0
—
2.5
—
—
—
—
—
—
—
—
—
—
Max
2.08
—
3.43
5.20
12.48
15.60
5.25
–5.25
12.60
–12.60
15.75
–15.75
2.10
—
3.47
5.25
12.60
15.75
5.5
–5.5
13.20
–13.20
16.50
–16.50
Unit
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
A, F, D, G*
B, C
Lx010 A, F, D, G*
B, C
Lx015 A, F, D, G*
B, C
A, F, D, G*
B, C
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
0.01
—
0.1
—
0.1
25
0.5
5
0.1
10
0.2
15
0.2
100
2.0
mV
%V
O
mV
%V
O
mV
%V
O
mV
%V
O
External Load Capacitance
A, D, F, G*
AJ, B, C
BK, CL
A, D, F, G*
AJ, B, C
BK, CL
A, F, D, G*
B, C
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
30
35
50
100
120
150
1000
200
mVrms
mVrms
mVrms
mVp-p
mVp-p
mVp-p
µF
µF
* For a 2.5 V output, use the 2 V output module (D code) with an output voltage trim pin (optional feature).
Lineage Power
3
LC/LW010- and LC/LW015-Series Power Modules:
18 Vdc to 36 Vdc or 36 Vdc to 75 Vdc Inputs, 10 W and 15 W
Data Sheet
March 27, 2008
Electrical Specifications
(continued)
Table 2. Output Specifications
(continued)
Parameter
Output Current
(At I
O
< I
O, min
, the modules may
exceed output ripple specifications,
but operation is guaranteed.)
Note:
On the Lx01xF, the output
voltage may exceed
specifications when
I
O
< I
O, min
.
Device Code
or Suffix
Lx015D
Lx015F
Lx015A
Lx015B
Lx015C
Lx010D, G*
Lx010F
Lx010A
Lx010B
Lx010C
Lx010AJ
Lx010BK
Lx010CL
Lx015D
Lx015F
Lx015A
Lx015B
Lx015C
Lx010D, G*
Lx010F
Lx010A
Lx010B
Lx010C
Lx010AJ
Lx010BK
Lx010CL
Lx015D
Lx015F
Lx015A
Lx015B
Lx015C
Lx010D, G*
Lx010F
Lx010A
Lx010B
Lx010C
Lx010AJ
Lx010BK
Lx010CL
Symbol
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O1
, I
O2
I
O1
, I
O2
I
O1
, I
O2
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O1
, I
O2
I
O1
, I
O2
I
O1
, I
O2
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O
I
O1
, I
O2
I
O1
, I
O2
I
O1
, I
O2
Min
0.35
0.25
0.15
0.12
0.10
0.2
0.15
0.1
0.08
0.06
0.1
0.06
0.05
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
Typ
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
Max
3.0
3.0
3.0
1.25
1.0
2.0
2.42
2.0
0.83
0.67
1.0
0.42
0.33
7.5
6.5
5
3.1
2.5
7.0
5
4
2.5
2
4.0
2.5
2.5
8.5
8.5
7.5
4.5
4.5
8
7.5
6
3.5
3.5
6.0
3.5
3.5
Unit
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
Output Current-limit Inception
(V
O
= 90% V
O, set
; see Figures
12—14.)
Output Short-circuit Current
(V
O
= 0.25 V)
* For a 2.5 V output, use the 2 V output module (D code) with an output voltage trim pin (optional feature).
4
Lineage Power
Data Sheet
March 27, 2008
LC/LW010- and LC/LW015-Series Power Modules:
18 Vdc to 36 Vdc or 36 Vdc to 75 Vdc Inputs, 10 W and 15 W
Electrical Specifications
(continued)
Table 2. Output Specifications
(continued)
Parameter
Efficiency
(V
I
= V
I, nom
; I
O
= I
O, max
; T
A
= 25 °C;
see Figures 15—28, 35, and 37.)
Device Code
or Suffix
LC015D
LC015F
LC015A
LC015B, C
LC010D, G*
LC010F
LC010A, B, C
LC010AJ, BK, CL
LW015D
LW015F
LW015A
LW015B, C
LW010D, G*
LW010F
LW010A, B, C
LW010AJ, BK, CL
LC015F
LC015A
LW015F
LW015A
All
Symbol
η
η
η
η
η
η
η
η
η
η
η
η
η
η
η
η
η
η
η
η
—
Min
64
74
77
73
65
71
75
75
66
76
79
75
67
73
77
77
—
—
—
—
—
Typ
67
77
80
76
68
75
79
78
69
79
82
78
70
76
81
80
79
82
82
84
265
Max
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
Unit
%
%
%
%
%
%
%
%
%
%
%
%
%
%
%
%
%
%
%
%
kHz
Efficiency
(V
I
= V
I, nom
; I
O
= 2 A; T
A
= 25 °C;
see Figures 15, 18, 22, and 25.)
Switching Frequency
Dynamic Response
(for duals: I
O1
or I
O2
= I
O, max
;
ΔI
O
/Δt = 1A/10 µs; V
I
= V
I, nom
;
T
A
= 25 °C; see Figures 29 and 30.):
Load Change from I
O
= 50% to 75%
of I
O, max
:
Peak Deviation
Settling Time
(V
O
< 10% of peak deviation)
Load Change from I
O
= 50% to 25%
of I
O, max
:
Peak Deviation
Settling Time
(V
O
< 10% of peak deviation)
All
All
—
—
—
—
2
0.8
—
—
%V
O, set
ms
All
All
—
—
—
—
2
0.8
—
—
%V
O, set
ms
* For a 2.5 V output, use the 2 V output module (D code) with an output voltage trim pin (optional feature).
I want a program to run automatically after the system starts. Which files do I need to set and how do I set it? The initial idea is as follows: After the system starts, each folder is automatically s...
It is getting harder and harder to buy things when I go home for the Spring Festival. I am busy at work and have no time to go shopping. I haven't bought anything for my dad yet, but I bought a tonic ...
During the Shopping Festival this year, I couldn't help but buy a high-end Puyuan DS2072A oscilloscope, so the old DS1052E was idle. I bought it secretly with Huabei without my partner's knowledge. Se...
Getting Started with MSP430FR5969 When you are getting started with MSP430FR5969, you can focus on the peripherals you are interested in. Do multi-angle analysis, experiments, and share your experienc...
RT. I want to make that thing for my graduation thesis. I feel the principle is very simple. It's just a tiny sound that needs to be detected. How quiet the environment needs to be? And if the sound i...
In recent years, the government has increasingly supported electric vehicles, and the number of electric vehicles has increased. Observant drivers will notice that there are many more green license...[Details]
Amidst the wave of intelligent automotive transformation, advanced driver assistance is gradually emerging from cutting-edge technology into the mainstream, becoming a new frontier of industry comp...[Details]
In June 2014, the Ministry of Industry and Information Technology issued 4G FD-LTE licenses to China Unicom and China Telecom. Together with the 4G TD-LTE licenses issued to China Mobile, China Uni...[Details]
Laird Thermal Systems has introduced the HiTemp ET series Peltier cooler modules, which can operate at high temperatures and provide on-site cooling for sensitive electronic devices.
Dig...[Details]
Charging is a familiar process for new energy vehicles, and as a source of battery energy, charging piles are crucial. New energy vehicle charging can be divided into fast charging and slow chargin...[Details]
During daily operation of an R-type power transformer, the voltage used varies as the equipment being used adjusts. This raises the question: can the transformer change voltage at this point? The a...[Details]
Shenzhen Baowei Power Supply high frequency pure sine wave power, communication inverter power supply has two communication interfaces, RS232 and R485 interfaces, their functions and characteristic...[Details]
There are more and more electric vehicles. Recently, I have heard some news about electric vehicles performing poorly in winter. I would like to briefly introduce whether heat pump technology is mo...[Details]
Puttshack's Trackaball uses the Nordic nRF54L15 system-on-chip (SoC) to monitor sensors and enable Bluetooth low energy connectivity, while the nPM2100 power management integrated circuit (PMIC) ...[Details]
Analog Devices held a third-quarter fiscal 2025 earnings conference call. Vincent T. Roche, CEO and Chairman of the Board, and Richard C. Puccio, Executive Vice President and Chief Financial Office...[Details]
introduction
A common voltage regulator is a three-terminal one. Its function is to step down the voltage and stabilize it at a fixed output value. Voltage regulators are commonly available in...[Details]
I believe everyone has heard of memory. If your computer is slow, your experts may recommend upgrading it to a larger capacity. But what exactly is computer memory used for? Why does memory capacit...[Details]
On August 20, it was reported that the specifications of Intel's upcoming Panther Lake mobile processor appeared on the Intel GFX CI website, which mainly focuses on Intel's open source Linux drive...[Details]
The automotive driveshaft is a crucial connecting component in the automotive mechanical system. It is a circular component that allows for connection or assembly, as well as movement and rotation....[Details]
Which is better, copper braided wire flexible connector or copper stranded wire flexible connector? When choosing copper wire flexible connector, people always struggle with whether to use copper b...[Details]
PCB Design
京公网安备 11010802033920号
EEWORLD
