Keeper
®
PT-2150
S P E C I F I C AT I O N S P T- 2 1 5 0
4.0
D I S C H A R G E C H A R AC T E R I S T I C S AT + 2 0 ° C ( 6 8 ° F )
Typical values for batteries stored at 20°C for one year
3.5
Nominal Capacity
(At 1mA/20°C/68°F/2.0V Cut-Off) .................. 1.2 Ah
VOLTAGE (V)
4.0
3.0
3.5
2.5
Voltage (V)
Open Circuit Voltage (At 20°C/68°F) ................ 3.67 V
Nominal Voltage (At 1mA/20°C/68°F) ................ 3.6 V
Maximum Continuous Current ............................ 50 mA
Maximum Pulse Current Capability .................. 100 mA
Rated 1 Sec. Pulse Capability (To 3V) ................ 20 mA
Operating Temperature
Range .................... -55° to +85°C (-67° to +185°F)
Weight .............................................. 9.2 g (0.324 oz)
Anode Surface Area ............................6 cm
2
(0.93 in
2
)
Volume .......................................... 4.3
cm
2
(0.67
in
2
)
3.0
2.5
2.0
2.0
163
Ω
20 mA
0.51 Ah
0
2
4
6
Time (Sec.)
8
10
1.68 kΩ 3.52 kΩ
2 mA
1 mA
1.13 Ah 1.2 Ah
17.5 kΩ
0.2 mA
1.1 Ah
180 kΩ
0.02 mA
0.9 Ah
1.5
1.0
0.1
1
10
10
2
10
3
10
4
10
5
TIME (HOUR)
C A PAC I T Y v s . C U R R E N T
1.2
1.1
1.0
20°C
72°C
CAPACITY (Ah)
Diameter (Max) ................................ 14.5 mm (.57 in)
Height (Max) .................................... 25.2 mm (.99 in)
0.9
0.8
0.7
0.6
0.5
0.4
50°C
-30°C
P RO D U C T S C H E M AT I C
0.3
0.01
0.1
1
10
CURRENT (mA)
T E M P E R AT U R E v s . O P E R AT I N G VO LTAG E
3.7
3.6
VOLTAGE (V)
+0
Ø 3.9 - 0.1
Ø .15 +0
- 0.004
mm
3.5
0.06mA
( in )
3.4
3.3
3.2
3.1
+
1mA
(
0.98 +0.01
)
- 0.012
+0
25.2 - 0.3
0.5
(.02)
6mA
3.0
-45
-49
-30
-22
-15
5
0
32
15
59
30
86
45
113
60
140
75
167
90 (°C)
194 (°F)
TEMPERATURE
Ø 9.0
±
0.1
(Ø .35
±
0.004)
(
+0
Ø 14.5 - 0.2
+0
Ø .57 - 0.008
)
WARNING: Fire, Explosion And Severe Burn Hazard. Do Not Recharge, Crush, Disassemble,
Heat Above 212°F (100°C), Incinerate Or Expose Contents To Water
LITHIUM-THIONYL CHLORIDE BATTERIES
Keeper
®
PT SERIES
The EaglePicher PT Series of KEEPER® cells was developed as an
economical, high-power option for design experts who prefer the
cylindrical design. With sizes and capacities ranging from the
1200 mAh (PT-2150) to the 19,000 mAh (PT-2300H), this
commercial applications.
mm
( i n)
3.9
PT-2150
(0.1
5)
0.7
(0.0 5 x 0.2
30 x
0.00
8)
19.5
(0.77)
14.9
(0.59)
5.5
(0.22)
cylindrical design will provide the long life power needed for
3.5
(0.1
4)
19.5
(0.77)
5.5
(0.22)
0.
(0.0
75 x 0.
30 x
2
0.00
8)
7
(0.28)
T H E E C O N O M I C A L H I G H - P OW E R S O L U T I O N
P T- 2 1 5 0
TERMINAL
TYPES
3.17
(0.1 x 0.15
2x.
01)
Tab (-T)
7.55
(0.3
0)
0.75
(0.0 x 0.2
30 x
0.00
8
P T S E R I E S P RO D U C T F E AT U R E S
Pins (-P)
3.5
(0.1
4)
)
• Compliant with lead-free RoHS and WEEE EC directives.
• Stainless steel construction provides corrosion resistance,
hermetic seal and structural integrity.
• Years of low-rate continuous use.
• Stand-by use with 80% capacity retention after 15 years at
room temperature.
• Wave solderable
(limit solder bath exposure to a maximum of 5 seconds).
• High energy density compared to other chemistries.
• No charging circuits required.
• Higher cell voltage allows for fewer cells and high reliability.
• Flat discharge characteristics provide optimum voltage regulation.
• Non-pressurized system allows for high-temperature usage.
• Underwriters Laboratories recognized component.
The specifications on this sheet may be changed by EaglePicher without notice.
EaglePicher™ is a trademark of and Keeper®
is
a registered trademark of EaglePicher Corporation.
Pin Tabs (-PT)
4
(1 5
.7
7)
4
(1 5
.7
7)
Housing
Axial (-A)
D=0.75
(0.030)
3
(1 0
.1
8)
16.6
(0.6
5)
2
(1 6
.0
2)
Connector (-S)
Connector Type:
Tyco / Molex / JST / Berg / Tamiya
W E C A N D E S I G N T O F I T A N Y A P P L I C AT I O N .
Our team of engineers can design any pin configuration required
to fit your specialized application. If you don't see a battery
configuration you need here, call us and we will begin working
on a EP part number just for you.
DISTRIBUTED LOCALLY BY:
Keeper
®
3220 Industrial Drive
•
Joplin, MO 64801
Tel: 1-800-201-0215
•
Fax: 417-626-2078
E-mail: solutions@eaglepicher.com
•
Web site: www.epcompower.com
Copyright ©2006 EaglePicher Corporation
