STANDARD RF INDUCTORS - THRU HOLE
15M
TRADITIONAL
Pb
15MLF
*
PART
NUMBER
15M150M
15M220M
15M330M
15M470M
15M560K
15M680K
15M820K
15M101K
15M121K
15M151K
15M181K
15M221K
15M271K
15M331K
15M391K
15M471K
15M561K
15M681K
15M821K
15M102K
15M122K
15M152K
15M182K
15M222K
15M272K
15M332K
COMPLIANT
RoHS
Wirewound, Molded
L
µH
0.15
0.22
0.33
0.47
0.56
0.68
0.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.0
12.0
15.0
18.0
22.0
27.0
33.0
Q
MIN
50
50
45
45
50
50
50
50
33
33
33
33
33
33
33
33
45
50
50
55
65
65
75
75
60
65
TEST FREQ
L&Q
MHz
PHENOLIC CORE
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
SRF
MHz
MIN
525
450
360
310
280
250
220
200
180
160
150
135
120
110
100
90
60
55
50
45.
42
40
34
30
25
19
DCR
OHMS
MAX
0.030
0.055
0.090
0.120
0.135
0.150
0.220
0.290
0.420
0.500
0.650
0.950
1.20
2.00
2.30
2.60
0.32
0.50
0.60
0.90
1.10
1.40
2.25
2.50
2.60
3.00
CURRENT
RATING
mA DC
2450
1900
1400
1225
1220
1100
900
830
650
600
525
435
385
300
280
260
495
395
360
290
265
240
185
175
170
165
continued next page
POWDERED IRON CORE
Suffix “M” for 20% tolerance, “K” for 10% tolerance and “J” for 5% tolerance
Optional tolerances available; please contact factory
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example:
15M150MLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
NOTES:
Operating Temperature Range:
-55°C to +125°C for Phenolic
-55°C to +105°C for Powdered Iron
• Current Rating at a 90°C ambient:
15°C temperature rise for Powdered Iron
35°C temperature rise for Phenolic
• DWV 1000 Vrms @ Sea Level
200 Vrms @ 70,000 Feet
• Laser marking is standard
1.438 ± 0.188
(36.525 ± 4.77)
10µH
± 10%
in. (mm)
0.375 ± 0.010
(9.525 ± 0.25)
0.156 ± 0.008
(3.962 ± 0.20)
22 AWG
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Inside tape spacing:
Reel diameter:
Class:
2500
0.200 in.
2.062 in.
12 in.
1
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
010814
STANDARD RF INDUCTORS - THRU HOLE
continued from previous page
15M
TRADITIONAL
Pb
15MLF
*
PART
NUMBER
15M362J
15M392J
15M432J
15M472J
15M512J
15M562J
15M622J
15M682J
15M752J
15M822J
15M912J
15M103J
15M113J
15M123J
15M133J
15M153J
15M163J
15M183J
15M203J
15M223J
15M243J
15M273J
15M303J
15M333J
15M363J
15M393J
15M433J
15M473J
15M513J
15M563J
15M623J
15M683J
15M753J
15M823J
15M913J
15M104J
COMPLIANT
RoHS
Wirewound, Molded
L
µH
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
180
200
220
240
270
300
330
360
390
430
470
510
560
620
680
750
820
910
1000
Q
MIN
60
60
60
55
55
55
55
55
55
50
50
50
60
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
TEST FREQ
L&Q
MHz
POWDERED IRON CORE
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
15.5
14.5
13.7
13.0
12.7
12.0
11.5
11.0
10.5
10.3
10.0
9.5
8.9
8.7
8.5
8.0
7.5
7.0
6.5
6.2
5.9
5.7
5.4
5.1
4.8
4.5
4.2
3.9
3.8
3.7
3.3
3.1
2.9
2.7
2.5
2.3
2.50
2.60
2.70
2.75
2.85
3.00
3.15
3.30
3.70
3.90
4.30
4.50
4.90
5.20
5.45
6.05
6.40
6.75
7.10
7.45
7.80
11.0
11.5
12.0
12.5
16.3
17.1
17.9
18.8
19.5
25.9
27.2
28.6
30.0
31.5
33.0
180
176
172
170
167
164
160
156
147
143
136
133
128
124
121
114
111
108
106
103
101
85
83
81
80
70
68
67
65
64
55
54
53
52
50
49
SRF
MHz
MIN
DCR
OHMS
MAX
CURRENT
RATING
mA DC
Suffix “M” for 20% tolerance, “K” for 10% tolerance and “J” for 5% tolerance
Optional tolerances available; please contact factory
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example:
15M150MLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the
part number. These LF components meet the ≤ .1% lead requirement and they are
compatible with 260°C soldering processes.
NOTES:
Operating Temperature Range:
-55°C to +125°C for Phenolic
-55°C to +105°C for Powdered Iron
• Current Rating at a 90°C ambient:
15°C temperature rise for Powdered Iron
35°C temperature rise for Phenolic
• DWV 1000 Vrms @ Sea Level
200 Vrms @ 70,000 Feet
• Laser marking is standard
1.438 ± 0.188
(36.525 ± 4.77)
10µH
± 10%
0.375 ± 0.010
(9.525 ± 0.25)
0.156 ± 0.008
(3.962 ± 0.20)
22 AWG
in. (mm)
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Inside tape spacing:
Reel diameter:
Class:
2500
0.200 in.
2.062 in.
12 in.
1
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
010814
