75W Single Phase Industrial DIN Rail Power Supply
F ea tures :
PS-75 Series
U nivers a l A C i nput/F ull ra nge
P rotections :Short circuit/O ver loa d/O ver v olta ge/O ver tempera ture
C ooling by f ree a ir c onvection
C a n be i ns ta lled on D IN r a il T S -35/7.5 o r 1 5
U L 5 08(indus tria l c ontrol e quipment)a pproved
L E D i ndica tor for power o n
100% f ull loa d burn-in tes t
F ix switching frequency a t 50K Hz
3 y ea rs w a rra nty
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
VOLTAGE ADJ . R ANGE
VOLTAGE TOLERANCE
Note.3
LINE R EGULATION
LOAD REGULATION
SETUP, R ISE, HOLD TIME
VOLTAGE R ANGE
FREQUENCY RANGE
INPUT
EFFICIENCY (Typ.)
AC CURRENT
INRUSH CURRENT (max.)
LEAKAGE C URRENT
OVER L OAD
PROTECTION OVER VOLTAGE
OVER TEMPERATURE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
WITHSTAND VOLTAGE
SAFETY &
ISOLATION RESISTANCE
EMC
EMI CONDUCTION & RADIATION
(Note 4)
R
PS-7512
12V
6.3A
0 ~ 6.3A
76W
12 ~ 14V
2.0%
0.5%
1.0%
1000ms, 60ms, 50ms/230VAC
85 ~ 264VAC
47 ~ 63Hz
76%
1 20 ~ 370VDC
PS-7524
24V
3.2A
0 ~ 3.2A
76.8W
150mVp-p
24 ~ 28V
1.0%
0.5%
1.0%
1 800ms, 60ms, 10ms/115VAC at full load
PS-7548
48V
1.6A
0 ~ 1.6A
76.8W
240mVp-p
48 ~ 53V
1.0%
0.5%
1.0%
RIPPLE & NOISE (max.)
Note.2
100mVp-p
80%
81%
1.6A / 115V AC 0.96A / 230V AC
COLD START 20A / 115V AC 40A / 230V AC
<1mA / 240VAC
105 ~ 150% rated output power
Protection type :
Constant current li miting, recovers automatically after fault condition is removed
15 ~ 16.5V
85
5
29 ~ 34V
(TSW1) Detect on heat sink of power transistor
(Refer to output load derating curve)
58 ~ 65V
Protection type : Hiccup m
ode, recovers automatically after fault condition is removed
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
-10 ~ +
60
20 ~ 90% RH non-condensing
-20 ~ +
85 , 10 ~ 95% RH
0.03%/ (0 ~ 50
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
UL508, EN60950 Approved
I/P-O/P:3KVAC I /P-FG:1.5KVAC O/P-FG:0.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
Compliance to EN55011,EN55022 (CISPR22) Class B
Compliance to EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,1
1, ENV50204, EN55024, EN61000-6-2 (EN50082-2) Heavy industry level, criteria
A
123.1K hrs min. MIL-HDBK-217F (25 )
55.5*125.2*100mm (W*H*D)
0.6Kg; 20pcs/13Kg/1.1CUFT
HARMONIC CURRENT
EMS IMMUNITY
MTBF
OTHERS
NOTE
DIMENSION
PACKING
1. A ll parameters N OT s pecially mentioned a re measured a t 230VAC i nput, r ated load a nd 25 of ambient temperature.
2. R ipple & n oise a re measured a t 20MHz o f bandwidth by using a 1 2" twisted pair-wire terminated with a 0 .1uf & 4 7uf parallel capacitor.
3. T olerance : i ncludes s et up tolerance, line regulation a nd load regulation.
4. T he power s upply is c onsidered a c omponent which will be installed into a f inal equipment. T he final equipment must be re-confirmed that it still meets
E MC d irectives.
