25Watts Single Output LED Driver
Q
ualtek
P
P C
Electronics Corporation
PLC-025 Series
Features:
Constant Current Design
Universal AC input/ Full Range
Built-in Active PFC function, PF 0.95 Typical
High Efficiency (Up to 84%)
Output Protections: OVP/SCP/OTP
Lightning Protection
Class 2 Power Unit
Waterproof (IP65)
3 Year Warranty
(See Note)
Model
Rated Current
Voltage Range
Ripple and Noise (max)
Voltage Accuracy
Line Regulation
Load Regulation
Rise Time
Hold-up Time (Typ.)
Note 1
See Note
PLC-025S035 PLC-025S045
PLC-025S062
PLC-025S070 PLC-025S105
PLC-025S140
PLC-025S175 PLC-025S208
Output Characteristics
0.35A
24~72V
±10% Vo
±5% Vo
±1% Vo
±5% Vo
20mS Max @ Rated Load
8.5mS Min (110VAC input, full load), 10mS Min (220VAC input, full load)
90VAC~305VAC
47Hz-63Hz
>0.95
>0.90
84%
>0.95
>0.90
84%
>0.95
>0.90
83%
>0.95
>0.90
83%
>0.95
>0.90
82%
>0.95
>0.90
81%
>0.95
>0.90
81%
>0.95
>0.90
80%
110VAC
220VAC
(1)
0.45A
19~56V
(2)
0.62A
13~40V
(2)
0.70A
12~36V
(3)
1.05A
8~24V
(3)
1.40A
6~18V
(3)
1.75A
5~14V
(3)
2.08A
4~12V
(3)
Input Characteristics
Voltage Range
Frequency Range
Power Factor
(Typical)
Efficiency (Typical)
AC Current (max)
Inrush Current (max)
Leakage Current
0.35A @ 100-277VAC Input Full Load
65A @ 230VAC, 25°C
0.5mA max @ 277VAC
110°C (Temperature of internal components); shut down, auto recover after the temperature decreases
1.2~1.7Vo
Long-term mode, auto recovery
-35°C~50°C
5% RH to 95% RH
-40°C~85°C, 5% to 100% RH non-condensing
10 to 300Hz sweep at constant acceleration of 1.0G(Breadth: 3.5mm) for 1 Hour for each of the perpendicular axes X, Y, Z
IP65
UL8750, Compliance to UL1012 UL935, IEC61347
L/N-GND: 4kV, L-N: 2kV
I/P-O/P: >100M Ohms / 500VDC / 25°C / 70% RH
Compliance to EN55022(CISPR22) Class B, EN61000-3-2 Class A, EN61000-3-3
Compliance to EN61000-3-2, 3 EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547
More than 78,000Hrs (25°C, 80% Load)
More than 488,000Hrs (25°C, 80% Load)
80x78x27mm
1. Ripple & Noise: Measured by 20 MHz bandwidth oscilloscope and the output paralleled with a 0.1 uF ceramic capacitor and a 10 uF electrolytic capacitor.
2. Latch Mode: The power supply shall return to normal operation only after the power is turned on again
(1) Non-Class 2 output (USR & CNR)
(2) Class 2 output (USR); Non-Class 2 output (CNR)
(3) Class 2 output (USR & CNR)
Page 1 of 2
Protection
Over Temperature (OTP)
Over Voltage (OVP)
Short Circuit (SCP)
Operating Temperature
Operating Relative Humidity
Storage Temperature
Vibration
Waterproof Rating
Safety Standards
Withstand Voltage
Isolation Resistance
EMC Emission
EMC Immunity
Note 2
Environmental Characteristics
Characteristics
Life Time
MTBF (MIL-HDBK-217F)
Dimension (LxWxH)
Note
