IMC-2220
www.vishay.com
Vishay Dale
High Frequency, Surface Mount Molded Inductors
FEATURES
• Molded construction provides superior strength
and moisture resistance
• Compatible with vapor phase infrared and wave
soldering methods (100 % tin plating)
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
STANDARD ELECTRICAL SPECIFICATIONS
IND.
(μH)
TOL.
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
10 %
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
TEST
FREQ.
(MHz)
L&Q
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.0796
SRF
MIN.
(MHz)
DCR
MAX.
()
RATED DC
CURRENT
(mA)
(1)
1.0
95
0.030
1800
1.2
70
0.035
1700
1.5
55
0.040
1600
1.8
47
0.050
1400
2.2
42
0.060
1300
2.7
37
0.070
1200
3.3
34
0.080
1120
3.9
32
0.090
1050
4.7
29
0.110
950
5.6
26
0.130
880
6.8
24
0.150
810
8.2
22
0.180
750
10
19
0.210
690
12
17
0.250
630
15
16
0.300
580
18
14
0.360
530
22
13
0.430
480
27
11.5
0.520
440
33
10.5
0.620
400
39
9.5
0.720
370
47
8.5
0.850
340
56
7.8
1.00
310
68
7
1.20
290
82
6.4
1.40
270
100
6
1.60
250
120
5.4
1.90
230
150
4.8
2.20
210
180
4.4
2.80
190
220
3.9
3.40
170
270
3.6
4.20
155
330
3.2
4.90
140
390
2.9
5.80
130
470
2.6
7.00
120
560
2.4
8.50
110
680
2.2
10.0
100
820
2
13.0
90
1000
1.8
15.0
85
1200
1.5
17.0
75
1500
1.4
20.0
70
1800
1.3
30.0
60
2200
1.2
35.0
55
2700
1.1
55.0
45
3300
1
60.0
40
3900
1
70.0
38
4700
0.9
78.0
36
5600
0.8
85.0
33
6800
0.7
110.0
30
8200
0.6
125.0
28
10 000
0.5
150.0
25
Note
(1)
Rated DC current based on the maximum temperature rise, not
to exceed 40 °C at +85 °C ambient
Q
MIN.
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
15
ELECTRICAL SPECIFICATIONS
Inductance Range:
1.0 μH to 10 000 μH
Inductance and Tolerance:
± 10 %, ± 5 %
Operating Temperature:
-40 °C to +125 °C
Storage Temperature:
-40 °C to +125 °C
TEST EQUIPMENT
• Inductance and Q measured on HP4191
• SRF measured on HP3755
• DCR measured on HP34401
DIMENSIONS
in inches [millimeters]
0.221 ± 0.012
[5.6 ± 0.3]
0.197 ± 0.008
[5.0 ± 0.2]
0.157 ± 0.012
[4.0 ± 0.3]
0.043 [1.1] Ref.
0.028 ± 0.004
[0.7 ± 0.1]
0.157 ± 0.008
[4.0 ± 0.2]
0.079 [2.0] 0.157 [4.0] 0.079 [2.0]
Ref.
Ref.
Ref.
822
0.177
[4.5]
Ref.
DESCRIPTION
IMC-2220
MODEL
22 μH
INDUCTANCE VALUE
± 10 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
JEDEC
®
E3
LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
M
PRODUCT
FAMILY
Revision: 06-Feb-17
C
2
2
SIZE
2
0
E
R
2
2
INDUCTANCE
VALUE
0
K
TOL.
PACKAGE
CODE
Document Number: 34127
