Features
■
High saturation current - up to 20 A
■
Inductance range: 1.5 to 1000 µH
■
Heating current up to 9.5 A
■
AEC-Q200 qualified
■
RoHS compliant* and halogen free**
Applications
■
Automotive systems:
- Driver assistant
- Information
- Entertainment
- Lighting
■
DC/DC converters
■
Power supplies
SDR1307A Series - SMD Power Inductors
Electrical Specifications @ 25 °C
Bourns
Part Number
Inductance
@ 100 KHz / 0.1 V
L (µH)
Tol. (%)
Q
(Ref.)
Test
Freq.
(MHz)
SRF
(MHz)
Typ.
DCR
(Ω)
Max.
I rms
(A)
I sat
(A)
General Specifications
Operating Temperature
................................-40 °C to +125 °C
(Temperature rise included)
Storage Temperature
................................-40 °C to +125 °C
Resistance to Soldering Heat
............................. +245 °C for 10 sec.
Temperature Rise
......................40 °C typ. at rated I rms
Inductance Drop .......... 10 % typ. at I sat
Materials
Core ..............................................Ferrite
Wire ............................Enameled copper
Terminal Finish .........................Ag/Ni/Sn
Packaging .................... 400 pcs. per reel
Product Dimensions
13.0 ± 0.7
(.512 ± .028)
SDR1307A-1R5M
SDR1307A-2R2M
SDR1307A-2R7M
SDR1307A-3R3M
SDR1307A-4R7M
SDR1307A-5R6M
SDR1307A-6R8M
SDR1307A-8R2M
SDR1307A-100M
SDR1307A-120M
SDR1307A-150M
SDR1307A-180M
SDR1307A-220M
SDR1307A-270M
SDR1307A-330K
SDR1307A-390K
SDR1307A-470K
SDR1307A-560K
SDR1307A-680K
SDR1307A-820K
SDR1307A-101K
SDR1307A-121K
SDR1307A-151K
SDR1307A-181K
SDR1307A-221K
SDR1307A-271K
SDR1307A-331K
SDR1307A-391K
SDR1307A-471K
SDR1307A-561K
SDR1307A-681K
SDR1307A-821K
SDR1307A-102K
1.5
2.2
2.7
3.3
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
20
22
24
26
25
24
24
24
22
25
28
28
40
35
35
28
24
22
24
18
25
20
20
18
15
15
15
12
12
10
10
10
10
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.252
65
50
40
38
36
28
26
24
22
20
17
16
15
11
10
9
7.5
7.2
7
6
5.8
5.5
4.5
4
3.8
3.5
3.2
2.5
2.2
2
1.6
1.5
1.4
0.005
0.006
0.008
0.0087
0.01
0.015
0.017
0.019
0.021
0.03
0.034
0.036
0.047
0.06
0.065
0.075
0.082
0.10
0.12
0.14
0.18
0.21
0.25
0.28
0.36
0.41
0.52
0.60
0.72
0.88
1.0
1.3
1.6
9.5
9.0
8.2
7.5
7.0
6.5
6.0
5.8
5.6
4.8
4.5
4.2
3.6
3.3
3.1
2.9
2.7
2.5
2.3
2.1
1.9
1.8
1.6
1.5
1.3
1.2
1.1
1.0
0.9
0.85
0.8
0.75
0.65
20
18
16
15
13
11
10.5
9.8
9.2
8
7.5
7
6.5
5.5
5
4.6
4.2
3.8
3.5
3.2
3
2.8
2.6
2.3
2.1
1.8
1.6
1.5
1.4
1.3
1.2
1.1
1
7.0 ± 0.3
(.276 ± .012)
5.0
REF.
(.197)
13.0 ± 0.7
(.512 ± .028)
Recommended Layout
14.0
(.551)
How to Order
Electrical Schematic
SDR1307A - 100M
Model
Value Code (see table)
14.0
(.551)
4.5
(.177)
DIMENSIONS:
MM
(INCHES)
* RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
** Bourns follows the prevailing definition of “halogen free” in the industry. Bourns considers a product to be “halogen free” if (a) the Bromine (Br) content is 900 ppm or less;
(b) the Chlorine (Cl) content is 900 ppm or less; and (c) the total Bromine (Br) and Chlorine (Cl) content is 1500 ppm or less.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
SDR1307A Series - SMD Power Inductors
Soldering Profile
Temperature
Rising Area
+4.0 °C/Sec. Max.
Preheat
Area
150~200 °C / 60~120 Sec.
Reflow
Area
+3.0 °C/Sec. Max.
Forced
Cooling Area
-(1.0~5.0) °C/Sec. Max.
250
Peak Temperature: 250 °C
217 °C
Peak Temperature
250
max.
Max. Peak
Temperature -5
30 sec. max.
Max. Time Above
217 :
60~150 sec. max.
Temperature (°C)
200
150
100
50
60~120 Sec.
60~150 Sec.
60 Sec.
Max.
0
50
100
150
200
250
Time (Seconds)
L vs. IDC
3.0
2.5
2.0
SDR1307A-2R2M
L @ 25
℃
L @ 125
℃
300.0
250.0
200.0
SDR1307A-221K
L @ 25
℃
L @ 125
℃
L (uH)
1.5
1.0
0.5
0.0
0.0
5.0
10.0
15.0
20.0
L (uH)
150.0
100.0
50.0
0.0
0.0
0.5
1.0
1.5
2.0
2.5
IDC (A)
25.0
20.0
15.0
SDR1307A-220M
1,200.0
L @ 25
℃
L @ 125
℃
1,000.0
800.0
SDR1307A-102K
L @ 25
℃
L @ 125
℃
L (uH)
600.0
10.0
400.0
5.0
0.0
0.0
200.0
0.0
2.0
4.0
6.0
8.0
0.0
0.3
0.6
0.9
1.2
IDC (A)
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
FT
IDC (A)
IDC (A)
SDR1307A Series - SMD Power Inductors
Temperature vs. IDC
SDR1307A-2R2M
100.0
T @ 25
℃
80.0
60.0
80.0
SDR1307A-221K
T @ 25
℃
T (°C)
T (°C)
0.0
5.0
10.0
15.0
20.0
60.0
40.0
20.0
0.0
40.0
20.0
0.0
0.0
0.5
1.0
1.5
2.0
2.5
IDC (A)
IDC (A)
100.0
80.0
SDR1307A-220M
T @ 25
℃
80.0
SDR1307A-102K
T @ 25
℃
60.0
T (°C)
60.0
40.0
20.0
0.0
0.0
2.0
4.0
6.0
8.0
T (°C)
S
40.0
20.0
0.0
0.0
0.3
0.6
0.9
1.2
IDC(A)
IDC(A)
Packaging Specifications
330
(12.99)
DIA.
2.0 ± 0.5
(.079 ± .020)
30.4
(1.20)
21.0
±
0.8
(.827
±
.031)
13.0
±
0.5
(.512
±
.020)
DIA.
50.0 -0
(1.969 - .000)
THICKNESS
0.10
(.004)
MAX.
EMBOSSED
CAVITY
13.0
±
0.5
DIA.
(.512
±
.020)
24.0
(.945)
END
EMBOSSED
CARRIER
26 +0
(1.02 +.000)
4
(.157)
24.0
(.945)
START
USER DIRECTION OF FEED
QTY: 400 PCS. PER REEL
20
(.787)
101
101
101
101
DIMENSIONS:
MM
(INCHES)
NO COMPONENT
NO COMPONENT
COMPONENTS
200
(7.874)
400
(15.748)
REV. 09/13
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
