Connector - SACC-M 8MS-3PCON CX - 1404599
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Sensor/actuator connector, male, straight, 3-pos., M8, Piercecon , metal knurl, cable diameter max. 5 mm
®
Why buy this product
Safe use in the field, thanks to a high degree of protection
Flexible: connectors for on-site assembly
Piercecon® connection: maximum contact density in a connector that can be assembled
Key Commercial Data
Packing unit
Minimum order quantity
GTIN
GTIN
Custom tariff number
Note
4046356703246
85366990
Made to Order (non-returnable)
50 STK
50 STK
Technical data
Dimensions
External diameter
Stripping length of the sheath
3 mm ... 5 mm
35 mm
Ambient conditions
Ambient temperature (operation)
Degree of protection
-25 °C ... 85 °C (Plug / socket)
IP68
General
Rated current at 40°C
Rated voltage
Number of positions
4A
60 V
3
11/13/2016 Page 1 / 4
https://www.phoenixcontact.com/hq/products/1404599
Connector - SACC-M 8MS-3PCON CX - 1404599
Technical data
General
Insulation resistance
Coding
Standards/regulations
Status display
Overvoltage category
Degree of pollution
Connection method
Conductor cross section
Conductor cross section AWG
Wire diameter including insulation
Insertion/withdrawal cycles
Torque
≥ 100 MΩ
A - standard
M8 connector IEC 61076-2-104
No
II
3
Piercecon fast connection
0.14 mm² ... 0.38 mm²
22 ... 26
1 mm ... 1.3 mm (Black wire clamping for 0.14 mm² ... 0.25 mm²)
1.3 mm ... 1.6 mm (White wire clamping for 0.25 mm² ... 0.38 mm²)
≥ 100
0.5 Nm (Pressure nut with coupling sleeve)
0.8 Nm (Connector with coupling sleeve)
0.2 Nm (M8 knurl)
®
Material
Flammability rating according to UL 94
Contact material
Contact surface material
Contact carrier material
Material of grip body
Material, knurls
Sealing material
V0
CuZn
Ni/Au
PA 66
PA 66
Nickel-plated brass
NBR
Cable
Standards/specifications
M8 connector IEC 61076-2-104
Standards and Regulations
Standard designation
Standards/regulations
Flammability rating according to UL 94
M8 connector
IEC 61076-2-104
V0
Drawings
11/13/2016 Page 2 / 4
https://www.phoenixcontact.com/hq/products/1404599
Connector - SACC-M 8MS-3PCON CX - 1404599
Schematic diagram
4
Dimensional drawing
1
3
35,4
Ø12
M8
Pin assignment M8 plug, 3-pos., view male side
10
M8 x 1 male plug, straight version
Functional
drawing
Assembly
steps
for
M8
connector
with
®
Piercecon
connection
a
=
Cut
flush
b
=
Coding
Strip
the
conductor
by
approx.
35
mm
and
slide
on
the
union
nut
and
cable
clamp
type
cage.
Without
stripping
the
insulation
of
the
individual
cores,
guide
them
into
the
11
11/13/2016 Page 3 / 4
https://www.phoenixcontact.com/hq/products/1404599
Connector - SACC-M 8MS-3PCON CX - 1404599
corresponding
chamber
of
the
elastic
core
clamping
and
cut
them
off
flush
on
the
contact
side.
The
coding
marks
must
be
flush
when
mounted.
Phoenix Contact 2016 © - all rights reserved
http://www.phoenixcontact.com
11/13/2016 Page 4 / 4
