This document was generated on 09/08/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
78079-0051
Active
DDR3 DIMM
1.00mm Pitch DDR3 DIMM Socket, Vertical, Through Hole, with Beveled Metal Pins,
Black Housing, Off-White Latches, 0.38µm Gold (Au) Plating, 2.67mm Soldertail, 240
Circuits, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-78079-001 (PDF)
RoHS Certificate of Compliance (PDF)
image - Reference only
Series
Agency Certification
CSA
UL
LR19980
E29179
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Not Low-Halogen
China RoHS
General
Product Family
Series
Component Type
Electrical Model
JEDEC Outline
Overview
Product Name
UPC
Memory Module Sockets
78079
Socket
Yes
MO-269
DDR3 DIMM
DDR3 DIMM
800756834757
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Entry Angle
Flammability
Function Key
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Temperature Range - Operating
Termination Interface: Style
240
240
Black, Natural
25
Vertical
94V-0
None
Yes
Copper Alloy
Gold
Tin
High Temperature Thermoplastic
8.500/g
2.67mm
Yes
Yes
1.57mm
Tray
1.00mm
1.00mm
0.381µm
2.540µm
-55°C to +85°C
Through Hole
Search Parts in this Series
78079Series
Mates With
JEDEC Standard 1.27mm Modules
Electrical
Current - Maximum per Contact
Voltage - Maximum
Voltage Key
1A
30V AC (RMS)/DC
Center
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
10
Wave Capable (TH only)
2
240
Material Info
Reference - Drawing Numbers
Electrical Model Document
Product Specification
S-Parameter Model
Sales Drawing
EE-78079-001, EE-78079-002, EE-78079-003,
EE-78079-004, EE-78079-005, EE-78079-008
PS-78079-001
SP-78079-008
SD-78079-001
