805-003 and 805-004 Ordering Information
Three Shell Mounting Options:
Jam
nut with O-ring for rear panel mounting,
square flange for front or rear panel
mounting, or in-line receptacles for
free-hanging cables.
Gold-Plated Crimp Contacts are held in
place with beryllium copper retention
clips. Contacts are removable.
How To Order
Sample Part Number
Series (See Table I)
805-003
= Receptacle with Banding Platform
805-004
= Receptacle with Accessory Thread
-01
= In-line
-02
= Square Flange Front or Rear Mount
-12
= Square Flange Rear Mount Non-Locking Clinch Nuts
-22
= Square Flange Rear Mount Locking Clinch Nuts
-07
= Jam Nut for Rear Panel Mounting
C
= Aluminum / Black Anodize (Non-Conductive); RoHS Compliant
M
= Aluminum / Electroless Nickel; RoHS Compliant
Shell Material and Finish
MT
= Aluminum / Nickel-PTFE RoHS Compliant
NF
= Aluminum / Cadmium with Olive Drab Chromate
ZNU
= Aluminum / Zinc-Nickel with Black Chromate
Z1
= Stainless Steel / Passivated; RoHS Compliant
ZB
= Stainless Steel / Olive Drab Chromate over Cadmium
ZC
= Stainless Steel / Zinc Cobalt Alloy/Black Chromate
Shell Size - Insert
Arrangement
Contact Type
Shell Key Positions
(See Table III)
See Contact Arrangements Page H-2
With contacts
P
= Pin
S
= Socket
A
= Normal
Without contacts
A
= Pin Connector, less contacts
B
= Socket Connector, less contacts
B
= Pos. B
C
= Pos. C
D
= Pos. D
E
= Pos. E
With 30 AWG Crimp Barrel
G
= #23 Pin
H
= #23 Socket
F
= Pos. F
Two Shell Styles: Choose integral band
platform for direct attachment of a cable
shield. Install a boot, or overmold a boot
over the band platform. An accessory
thread is available for attaching strain
reliefs and backshells.
805-004
-02
NF
9-10
P
A
Shell Style (See Table II)
Table I: Series
Table II: Shell Style
805-003
Receptacle with Banding
Platform
805-004
Receptacle with Accessory
Thread
-01
In-line Receptacle
-02, -12, -22
Square Flange
-07
Jam Nut
Dimensions in Inches (millimeters) are subject to change without notice.
© 2014 Glenair, Inc.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
H-13
E-Mail: sales@glenair.com
Series 805
