Printed-circuit board connector - MC 1,5/12-ST-3,81 BDS:12-1
X7 - 1709950
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Plug component, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 12, Pitch: 3.81 mm,
Connection method: Screw connection with tension sleeve, Color: green, Contact surface: Tin
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
Note
4055626167664
85366990
Made to Order (non-returnable)
50 STK
Technical data
Dimensions
Pitch
3.81 mm
General
Range of articles
Type of contact
Number of positions
Connection method
Insulating material group
Rated voltage (III/2)
Nominal current I
N
Nominal cross section
Flammability rating according to UL 94
MC 1,5/..-ST
Female connector
12
Screw connection with tension sleeve
I
160 V
8A
1.5 mm²
V0
Standards and Regulations
Flammability rating according to UL 94
V0
Environmental Product Compliance
China RoHS
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
11/14/2016 Page 1 / 3
https://www.phoenixcontact.com/hq/products/1709950
Printed-circuit board connector - MC 1,5/12-ST-3,81 BDS:12-1
X7 - 1709950
Approvals
Approvals
Approvals
CSA / VDE report with production monitoring / cULus Recognized / IECEE CB Scheme / EAC
Ex Approvals
Approval details
CSA
http://www.csagroup.org/services/testing-and-certification/certified-product-listing/ 13631
B
28-16
8A
300 V
D
28-16
8A
300 V
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
VDE report with production monitoring
Search.aspx 40011723
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://www.vde.com/en/Institute/OnlineService/VDE-approved-products/Pages/Online-
0.2-1.5
8A
160 V
cULus Recognized http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm E60425-20110128
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
30-14
8A
300 V
D
30-14
8A
300 V
IECEE CB Scheme
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://www.iecee.org/ DE1-56063-B1B2
0.2-1.5
8A
160 V
11/14/2016 Page 2 / 3
https://www.phoenixcontact.com/hq/products/1709950
Printed-circuit board connector - MC 1,5/12-ST-3,81 BDS:12-1
X7 - 1709950
Approvals
EAC B.01742
