Material
Plating
Wire Size
Wire Type
High Conductivity
Seamless Copper Tube
Electro-Tin
2 AWG
Stranded Copper; Class B:
Compact, Compressed or
Concentric, Class C: Concentric
15/16 in.
1/4 in.
Yes, for applications up to 35kv.
Consult cable manufacturer for
voltage stress relief instructions
with applications greater than
2000 volts.
90 C
Yes
.88±.04
BROWN
P33
.31±.01
(10)
.42±.01
Wire inspection window
.25±.04
.42±.04
.38 R Ref
Color coded
barrel markings
BROWN DIE P33 (10)
Wire Strip Length
Stud Size
UL Listed Wire
Connector
.27±.02 DIA
1.77±.06
UL Temperature
Rating
C.S.A Certified
Wire Connector
Panduit Color Code
on Barrel
Panduit Die Index No.
on Barrel
Alternate Industry
Die Index No. ( )
on Barrel
PANDUIT
2 STR CU
LCAN2-14
Beveled wire
entry
.12±.02
CERTIFIED
LISTED
Wire Connector
CORP.
02
REV
TINLEY PARK, ILLINOIS
9/10
DATE
JHNU JHNU REVISED WIRE SIZE TO 2 AWG
BY
CHK
DESCRIPTION
ECN
LCAN2-14-Q
Copper Lug - One-Hole, Narrow Tongue, Standard Barrel
SCALE
N/A
DRAWING NO / CAD FILE
LCAN2-14-CUST
