CLD-DS56 Rev 10e
Product family data sheet
Cree
®
XLamp
®
XP-E2 LEDs
ProDuCt DEsCriPtion
The XLamp
®
XP-e2 LeD builds on the unprecedented
performance of the original XP-e by increasing lumen output up
to 20% while providing a single die LeD point source for precise
optical control. The XP-e2 LeD shares the same footprint as the
original XP-e, providing a seamless upgrade path to more lumens
and/or greater efficiency while shortening the design cycle for
existing XP customers.
XLamp XP-e2 LeDs are the ideal choice for lighting applications
where high light output and maximum efficacy are required,
such as LED retrofit lamps, outdoor, portable, indoor directional,
emergency vehicle or architectural.
FEAturEs
•
Available in white, outdoor white, 80-CRI, 85-CRI, 90-CRI
white, royal blue, blue, green, PC amber, amber, red-orange
& red
•
•
•
•
•
•
•
•
•
•
ANSI-compatible chromaticity bins
White binned at 85 °C
Maximum drive current: 1 A
Low thermal resistance: as low as 5 °C/W
Wide viewing angle: 110°-135°
Unlimited floor life at ≤ 30 °C/85% RH
Reflow solderable - JEDEC J-STD-020C compatible
electrically neutral thermal path
RoHS and REACh compliant
UL
®
recognized component (E349212)
www.CRee.Com/XLAmp
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are
registered trademarks and the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
XLamp
®
Xp-E2 LED
tAbLE oF ContEnts
Characteristics .......................................................................................................................................................................................................
3
Flux Characteristics - White...................................................................................................................................................................................
4
Flux Characteristics - Color ................................................................................................................................................................................. 10
Relative Spectral Power Distribution ..................................................................................................................................................................
14
Relative Flux vs. Junction Temperature
.............................................................................................................................................................. 15
electrical Characteristics - White ........................................................................................................................................................................ 16
electrical Characteristics - Color ......................................................................................................................................................................... 16
Relative Flux vs. Current - White.......................................................................................................................................................................... 17
Relative Flux vs. Current - Color .......................................................................................................................................................................... 17
Relative Chromaticity vs. Current and Temperature .......................................................................................................................................... 18
Typical Spatial Distribution.................................................................................................................................................................................. 19
Thermal Design .................................................................................................................................................................................................... 20
Performance Groups - Luminous Flux ................................................................................................................................................................ 21
Performance Groups - Radiant Flux .................................................................................................................................................................... 21
Performance Groups - Chromaticity ................................................................................................................................................................... 22
Performance Groups - Dominant Wavelength ................................................................................................................................................... 25
Performance Groups - Forward voltage ............................................................................................................................................................. 26
Cree’s Standard Chromaticity Regions Plotted on the 1931 CIE Curve
............................................................................................................ 27
Cree’s Standard Cool White Kits Plotted on ANSI Standard Chromaticity Regions......................................................................................... 28
Cree’s Standard Warm and Neutral White Kits Plotted on ANSI Standard Chromaticity Regions .................................................................. 29
Cree’s PC Amber Kit Plotted on the 1931 CIE Curve
..........................................................................................................................................
30
Cree’s 2200 K CCT White Kits Plotted on ANSI Standard Chromaticity Regions
.............................................................................................
31
Cree’s Standard Chromaticity Kits ......................................................................................................................................................................
32
Bin and Order Code Formats ...............................................................................................................................................................................
33
Reflow Soldering Characteristics
........................................................................................................................................................................
34
Notes ....................................................................................................................................................................................................................
35
Mechanical Dimensions ......................................................................................................................................................................................
37
Tape and Reel .......................................................................................................................................................................................................
38
Packaging .............................................................................................................................................................................................................
39
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
2
XLamp
®
Xp-E2 LED
ChArACtEristiCs
Characteristics
Thermal resistance, junction to solder point - white, royal blue, blue
Thermal resistance, junction to solder point - green
Thermal resistance, junction to solder point - PC amber
Thermal resistance, junction to solder point - amber
Thermal resistance, junction to solder point - red-orange, red
Viewing angle (FWHM) - white
Viewing angle (FWHM) - royal blue, blue, green
Viewing angle (FWHM) - PC amber
Viewing angle (FWHM) - amber, red-orange, red
Temperature coefficient of voltage - white
Temperature coefficient of voltage - royal blue, blue
Temperature coefficient of voltage - green
Temperature coefficient of voltage - PC amber
Temperature coefficient of voltage - amber, red-orange, red
ESD withstand voltage (HBM per Mil-Std-883D)- white, royal blue, blue, green
ESD classification (HBM per Mil-Std-883D) - PC amber, amber, red-orange, red
DC forward current
Reverse voltage
Forward voltage (@ 350 mA, 85 °C) - white
Forward voltage (@ 700 mA, 85 °C) - white
Forward voltage (@ 1000 mA, 85 °C) - white
Forward voltage (@ 350 mA, 25 °C) - royal blue, blue
Forward voltage (@ 1000 mA, 25 °C) - royal blue, blue
Forward voltage (@ 350 mA, 25 °C) - green
Forward voltage (@ 1000 mA, 25 °C) - green
Forward voltage (@ 350 mA, 25 °C) - PC amber
Forward voltage (@ 1000 mA, 25 °C) - PC amber
Forward voltage (@ 350 mA, 25 °C) - amber, red-orange, red
Forward voltage (@ 1000 mA, 25 °C) - amber, red-orange, red
LeD junction temperature
v
v
v
v
v
v
v
v
°C
mA
v
v
2.9
3.05
3.15
3.1
3.4
3.2
3.7
3.05
3.28
2.2
2.65
150
2.6
3.5
3.8
3.5
unit
°C/W
°C/W
°C/W
°C/W
°C/W
degrees
degrees
degrees
degrees
mV/°C
mV/°C
mV/°C
mV/°C
mV/°C
v
Class 2
1000
5
3.25
Minimum
typical
9
15
9
7
5
110
135
110
130
-2.3
-3.3
-3.8
-2.5
-1.8
8000
Maximum
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
3
XLamp
®
Xp-E2 LED
FLuX ChArACtEristiCs - WhitE (t
J
= 85 °C)
The following tables provide order codes for XLamp XP-e2 white LeDs. For a complete description of the order code nomenclature,
please see the Bin and Order Code Formats section (page 33). For definitions of the chromaticity kits, please see the Cree’s Standard
Chromaticity Kits section (page 32).
Minimum Luminous Flux @
350 mA
Code
R4
R3
51
6200 K
R2
Q5
Q4
R4
R3
53
6000 K
R2
Q5
Q4
R4
R3
50
6200 K
R2
Q5
Q4
R4
R3
e1
6500 K
R2
Q5
Q4
R4
R3
e2
5700 K
R2
Q5
Q4
Flux (lm)
@ 85 °C
130
122
114
107
100
130
122
114
107
100
130
122
114
107
100
130
122
114
107
100
130
122
114
107
100
Flux (lm)
@ 25 °C*
151
142
132
124
116
151
142
132
124
116
151
142
132
124
116
151
142
132
124
116
151
142
132
124
116
Calculated Minimum
Luminous Flux (lm)**
@ 85 °C
700 mA
223
209
195
183
171
223
209
195
183
171
223
209
195
183
171
223
209
195
183
171
223
209
195
183
171
1.0 A
284
266
249
233
218
284
266
249
233
218
284
266
249
233
218
284
266
249
233
218
284
266
249
233
218
Chromaticity
Kit
CCt
order Codes
70 CRI Typical
XPeBWT-L1-0000-00G51
XPeBWT-L1-0000-00F51
XPeBWT-L1-0000-00e51
XPeBWT-L1-0000-00D51
XPeBWT-L1-0000-00C51
XPEBWT-L1-0000-00G53
XPEBWT-L1-0000-00F53
XPEBWT-L1-0000-00E53
XPEBWT-L1-0000-00D53
XPEBWT-L1-0000-00C53
XPeBWT-L1-0000-00G50
XPeBWT-L1-0000-00F50
XPeBWT-L1-0000-00e50
XPeBWT-L1-0000-00D50
XPeBWT-L1-0000-00C50
XPeBWT-L1-0000-00Ge1
XPeBWT-L1-0000-00Fe1
XPeBWT-L1-0000-00ee1
XPeBWT-L1-0000-00De1
XPeBWT-L1-0000-00Ce1
XPeBWT-L1-0000-00Ge2
XPeBWT-L1-0000-00Fe2
XPeBWT-L1-0000-00ee2
XPeBWT-L1-0000-00De2
XPeBWT-L1-0000-00Ce2
Notes:
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2 on CRI measurements.
See the Measurements section (page 35).
•
Cree XLamp XP-E2 LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher than the minimum
specified by the order code without advance notice. Shipments will always adhere to the chromaticity bin restrictions specified by the order code.
*
Flux values @ 25 °C are calculated and for reference only.
** Calculated flux values at 700 mA and 1 A are for reference only.
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
4
XLamp
®
Xp-E2 LED
FLuX ChArACtEristiCs - WhitE (t
J
= 85 °C) - ConTInued
Chromaticity
Kit
CCt
Minimum Luminous Flux @ 350 mA
Code
R4
R3
E3
5000 K
R2
Q5
Q4
R4
R3
F4
4750 K
R2
Q5
Q4
R4
R3
E4
4500 K
R2
Q5
Q4
R3
R2
F5
4250 K
Q5
Q4
Q3
R3
R2
e5
4000 K
Q5
Q4
Q3
Q5
Z5
4000 K
Q4
Q3
Flux (lm)
@ 85 °C
130
122
114
107
100
130
122
114
107
100
130
122
114
107
100
122
114
107
100
93.9
122
114
107
100
93.9
107
100
93.9
Flux (lm)
@ 25 °C*
151
142
132
124
116
151
142
132
124
116
151
142
132
124
116
142
132
124
116
109
142
132
124
116
109
124
116
109
Calculated Minimum
Luminous Flux (lm)**
@ 85 °C
700 mA
223
209
195
183
171
223
209
195
183
171
223
209
195
183
171
209
195
183
171
161
209
195
183
171
161
183
171
161
1.0 A
284
266
249
233
218
284
266
249
233
218
284
266
249
233
218
266
249
233
218
205
266
249
233
218
205
233
218
205
XPeBWT-01-0000-00Fe5
XPeBWT-01-0000-00ee5
XPeBWT-01-0000-00De5
XPeBWT-L1-0000-00ee5
XPeBWT-L1-0000-00De5
XPeBWT-L1-0000-00Ce5
XPeBWT-L1-0000-00Be5
XPeBWT-L1-0000-00DZ5
XPeBWT-L1-0000-00CZ5
XPeBWT-L1-0000-00BZ5
XPEBWT-H1-0000-00EE5
XPEBWT-H1-0000-00DE5
XPEBWT-H1-0000-00CE5
XPEBWT-H1-0000-00BE5
XPEBWT-H1-0000-00DZ5
XPEBWT-H1-0000-00CZ5
XPEBWT-H1-0000-00BZ5
XPeBWT-01-0000-00FF5
XPeBWT-01-0000-00eF5
XPeBWT-01-0000-00DF5
XPeBWT-L1-0000-00eF5
XPeBWT-L1-0000-00DF5
XPeBWT-L1-0000-00CF5
XPeBWT-L1-0000-00BF5
XPEBWT-01-0000-00GE4
XPEBWT-01-0000-00FE4
XPEBWT-01-0000-00EE4
XPEBWT-L1-0000-00FE4
XPEBWT-L1-0000-00EE4
XPEBWT-L1-0000-00DE4
XPEBWT-L1-0000-00CE4
XPEBWT-01-0000-00GF4
XPEBWT-01-0000-00FF4
XPEBWT-01-0000-00EF4
XPEBWT-L1-0000-00FF4
XPEBWT-L1-0000-00EF4
XPEBWT-L1-0000-00DF4
XPEBWT-L1-0000-00CF4
70 CRI Typical
XPEBWT-01-0000-00GE3
XPEBWT-01-0000-00FE3
XPEBWT-01-0000-00EE3
XPEBWT-L1-0000-00FE3
XPEBWT-L1-0000-00EE3
XPEBWT-L1-0000-00DE3
XPEBWT-L1-0000-00CE3
order Codes
75 CRI Typical
80 CRI Minimum
Notes:
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2 on CRI measurements.
See the Measurements section (page 35).
•
Cree XLamp XP-E2 LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher than the minimum
specified by the order code without advance notice. Shipments will always adhere to the chromaticity bin restrictions specified by the order code.
*
Flux values @ 25 °C are calculated and for reference only.
** Calculated flux values at 700 mA and 1 A are for reference only.
Copyright © 2012-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
5
京公网安备 11010802033920号
EEWORLD
