T-1 3/4 (5mm) LED LAMP
Part Number: WPF5WAEMBGMBW
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
SENSITIVE
DEVICES
High Efficiency Red
Blue
Green
Features
One red, one green, two blue chips in one package.
Can produce any color in visible spectrum, including
white light.
RoHS compliant.
Description
The High Efficiency Red source color devices are made with
Gallium Arsenide Phosphide on Gallium Phosphide Orange
Light Emitting Diode.
The Blue source color devices are made with GaN on SiC
Light Emitting Diode.
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
Static electricity and surge damage the LEDS.
It is recommended to use a wrist band or anti-electrostatic
glove when handling the LEDs.
All devices, equipment and machinery must be electrically
grounded.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.25(0.01") unless otherwise noted.
3. Lead spacing is measured where the leads emerge from the package.
4. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice.
SPEC NO: DSAF5130
APPROVED: WYNEC
REV NO: V.3
CHECKED: Allen Liu
DATE: JUL/14/2010
DRAWN: C.H.HAN
PAGE: 1 OF 8
ERP: 1101009115-01
Selection Guide
Part No.
Dice
Lens Type
Iv (mcd) [2]
@ 20mA
Min.
High Efficiency Red (GaAsP/GaP)
WPF5WAEMBGMBW
Blue (GaN)
Green (GaP)
Blue (GaN)
Notes:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value.
2. Luminous intensity/ luminous Flux: +/-15%.
Viewing
Angle [1]
2θ1/2
Typ.
30
25
20
25
10
WHITE DIFFUSED
7
7
7
60
°
Electrical / Optical Characteristics at TA=25°C
Symbol
λpeak
Parameter
Peak Wavelength
Device
High Efficiency Red
Blue
Green
High Efficiency Red
Blue
Green
High Efficiency Red
Blue
Green
High Efficiency Red
Blue
Green
High Efficiency Red
Blue
Green
High Efficiency Red
Blue
Green
Typ.
627
430
565
625
466
568
45
60
30
15
100
15
2
3.8
2.2
2.5
4.5
2.5
10
10
10
Max.
Units
nm
Test Conditions
I
F
=20mA
λD
[1]
Dominant Wavelength
nm
I
F
=20mA
Δλ1/2
Spectral Line Half-width
nm
I
F
=20mA
C
Capacitance
pF
V
F
=0V;f=1MHz
V
F
[2]
Forward Voltage
V
I
F
=20mA
I
R
Reverse Current
uA
V
R
=5V
Notes:
1.Wavelength: +/-1nm.
2. Forward Voltage: +/-0.1V.
Absolute Maximum Ratings at TA=25°C
Parameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Lead Solder Temperature [3]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
3. 5mm below package base.
High Efficiency Red
75
30
160
Blue
135
30
150
5
-40°C To +85°C
260°C For 3 Seconds
260°C For 5 Seconds
Green
62.5
25
140
Units
mW
mA
mA
V
SPEC NO: DSAF5130
APPROVED: WYNEC
REV NO: V.3
CHECKED: Allen Liu
DATE: JUL/14/2010
DRAWN: C.H.HAN
PAGE: 2 OF 8
ERP: 1101009115-01
