LUXEON S1000
High Flux Density Product
Introduction
The LUXEON
®
S1000 emitters deliver uniform beam intensity and high flux density from a uniform
source. This enables tight beam control at the system level using secondary optics to provide the high
center beam intensity, uniform beam and crisp, single shadow required for high performance accent
spotlighting applications. LUXEON S1000 delivers tight Correlated Color Temperature control to ensure
consistency in system color point. In addition these parts deliver the efficacy, lifetime and reliability that
all LUXEON LEDs are renowned for. This document contains the performance data needed to design
and engineer LUXEON S1000 based applications.
Features and Benefits
• Specified, targeted and tested hot, at real world operating temperatures:
T
j
= 85°C, to ensure in application performance.
• High flux density from 8mm diameter source products in 2700K, 3000K,
3500K, 4000K with 80 CRI and 3000K with 90 CRI.
• Uniform intensity and color across source with high efficacy for
sustainable design.
• Freedom from Binning delivers color consistency within either 3-step or
4-step MacAdam ellipse.
• Exceed ENERGY STAR
®
lumen maintenance requirements.
• Recognized under the Component Recognition Program of
Underwriters Laboratories Inc. UL listing E327436.
Key Applications
• Architecture
• Downlights
• Spotlights
Table of Contents
Product Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Average Lumen Maintenance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Selection Guide for LUXEON S1000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Optical Characteristics for LUXEON S1000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical Characteristics for LUXEON S1000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Relative Spectral Distribution vs . Wavelength Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Typical Forward Current Characterisics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Typical Radiation Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Product Binning and Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
LUXEON S1000 Color Bin Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
LUXEON S Datasheet DS80 20130907 ©2013 Philips Lumileds Lighting Company.
i
Product Nomenclature
LUXEON S1000 is tested and binned hot at T
j
= 85ºC and 700 mA DC.
The part number designation is explained as follows:
L X S A - B C D D
Where:
A — designates minimum CRI (value 8 for 80,9 for 90)
B — designates radiation pattern (value P for Lambertian)
C — designates color (W for White)
DD — designates nominal CCT (27 for 2700K, 30 for 3000K, 35 for 3500K and 40 for 4000K)
Therefore 3000K 80CRI 3-step MacAdams product will be:
L X S 8 - P W 3 0
Average Lumen Maintenance Characteristics
Lumen maintenance for solid-state lighting devices (LEDs) is typically defined in terms of the percentage of initial light output
remaining after a specified period of time. Philips Lumileds projects that LUXEON S1000 products will deliver, on average,
70% lumen maintenance (L70) at 50,000 hours of operation at a forward current of up to 700 mA. This projection is based
on constant current operation with junction temperature maintained at or below 110°C. This performance is based on
independent test data, Philips Lumileds historical data from tests run on similar material systems, and internal LUXEON
reliability testing. Observation of design limits included in this data sheet is required in order to achieve this projected lumen
maintenance.
Environmental Compliance
Philips Lumileds is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON
S1000 is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment,
namely the RoHS and REACH directives. Philips Lumileds will not intentionally add the following restricted material to the
LUXEON S1000: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated diphenyl
ethers (PBDE).
LUXEON S Datasheet DS80 20130907 ©2013 Philips Lumileds Lighting Company.
2
Product Selection Guide for LUXEON S1000
Junction Temperature = 85ºC; Test Current = 700 mA
Table 1.
Nominal
CCT
2700K
3000K
3000K
3500K
4000K
Part
Number
LXS8-PW27
LXS8-PW30
LXS9-PW30
LXS8-PW35
LXS8-PW40
Minimum
CRI
[1]
80
80
90
80
80
Typical
R9
Min Luminous
Flux (lm)
F
V [1]
1150
1250
1050
1300
1360
Typ Luminous
Flux (lm)
F
V [1]
1250
1390
1175
1420
1450
>20
>20
>50
>20
>20
Note for Table 1:
1. Philips Lumileds maintains a tolerance of ± 6.5% on luminous flux and ± 2 on CRI measurements.
Optical Characteristics for LUXEON S1000
Junction Temperature = 85ºC; Test Current = 700 mA
Table 2.
Nominal
CCT
2700K
3000K
3500K
4000K
Color Temperature
Minimum
2656K
2963K
3359K
3849K
Typical
2725K
3045K
3465K
3985K
Maximum
2795K
3129K
3575K
4129K
Typ Total Included Angle
[1]
(degrees)
u
0 .90V
129
129
129
129
Typ Viewing Angle
[2]
(degrees) 2u 1/2
105
105
105
105
Notes for Table 2:
1. Total angle at which 90% of total luminous flux is captured.
2. Viewing angle is the off axis angle from lamp centerline where the luminous intensity is ½ of the peak value.
Electrical Characteristics for LUXEON S1000
Junction Temperature = 85ºC; Test Current = 700 mA
Table 3.
Nominal
CCT
Forward Voltage Vf
[1]
(V)
Minimum
23.5
Typical
25.6
Maximum
29
Typ . Temperature Coefficient
of Forward Voltage
[2]
(mV/°C)
DV
f
/
DT
J
- 15
Typical Thermal Resistance
Junction to Thermal Pad (°C/W)
Ru
J-C
1.3
2700K, 3000K, 3500K, 4000K
Notes for Table 3:
1. Philips Lumileds maintains a tolerance of 0.5% on forward voltage measurements.
2. Measured at 25°C ≤ T
J
≤ 125°C at I
f
= 700 mA.
LUXEON S Datasheet DS80 20130907 ©2013 Philips Lumileds Lighting Company.
3
Absolute Maximum Ratings
T
able 4.
Parameter
DC Forward Current
Peak Pulsed Forward Current
ESD Sensitivity
Maximum Performance
900 mA
900 mA
< 8000V Human Body Model (HBM)
Class 3A JESD22-A114-E
< 400V Machine Model (MM)
Class B JESD22-A115-B
- 40°C - 135°C
115°C
- 40°C - 85°C
121°C at 2 ATM
LUXEON S LEDs are not designed to be driven in reverse bias
Storage Temperature
LED Junction Temperature
[1]
Operating CaseTemperature at 700 mA
Autoclave Conditions
Reverse Voltage (Vr)
Notes for Table 4:
1. Proper current derating must be observed to maintain junction temperature below the maximum.
LUXEON S Datasheet DS80 20130907 ©2013 Philips Lumileds Lighting Company.
4
