Table 2 . Optical characteristics for LUXEON 5050 at test current, T
j
=25°C .
Part numBEr
L150-xxxx50xx00000
tyPIcal total IncludEd anGlE
[1]
138°
tyPIcal VIEWInG anGlE
[2]
116°
Notes for Table 2:
1.
Total angle at which 90% of total luminous flux is captured.
2.
Viewing angle is the off axis angle from the LED centerline where the luminous intensity is ½ of the peak value.
Electrical and Thermal Characteristics
Table 3 . Electrical and thermal characteristics for LUXEON 5050 at test current, T
j
=25°C .
Part numBEr
L150-xxxx502400000
L150-xxxx500600000
ForWard VoltaGE
[1]
(V
f
)
mInImum
23.5
5.8
tyPIcal
24.5
6.1
maXImum
26.5
6.6
tyPIcal tEmPEraturE
coEFFIcIEnt oF ForWard
VoltaGE
[2]
(mV/°c)
-12
-3
tyPIcal thErmal
rEsIstancE—JunctIon
to soldEr Pad (°c/W)
2
2
Notes for Table 3:
1. Lumileds maintains a tolerance of ±1% on forward voltage measurements.
2. Measured between 25°C and 85°C.
Absolute Maximum Ratings
Table 4 . Absolute maximum ratings for LUXEON 5050 .
ParamEtEr
DC Forward Current
[1, 2]
Peak Pulsed Forward Current
[1, 3]
LED Junction Temperature
[1]
(DC & Pulse)
ESD Sensitivity (ANSI/ESDA/JEDEC JS-001-2012)
Operating Case Temperature
[1]
LED Storage Temperature
Allowable Reflow Cycles
Reverse Voltage (V
reverse
)
maXImum PErFormancE
240mA for 24V
800mA for 6V
300mA for 24V
1000mA for 6V
125°C
Class 2
105°C
-40°C to 105°C
3
LUXEON LEDs are not designed to be driven in reverse bias
Notes for Table 4:
1.
Proper current derating must be observed to maintain the junction temperature below the maximum allowable junction temperature.
2. Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple,” are acceptable if the following conditions are met:
– The frequency of the ripple current is 100Hz or higher
– The average current for each cycle does not exceed the maximum allowable DC forward current
– The maximum amplitude of the ripple does not exceed the maximum peak pulsed forward current
