Stratos
LxLx-ST11xx Low Profile Optical Transceiver
Connectivity for
Business Critical Continuity
TM
1x/2x Fiber Channel Applications
3.3V, 850nm VCSEL, Multimode, Up to 500Meters
Applications
The LxLx-ST11xx multimode optical fiber transceivers provide low profile, cost
effective solutions for rate agile 1x/2x Fiber Channel multimode optical fiber
data links with a duplex LC connector interface.
These transceivers are fully compliant with the ANSI Fiber Channel standards
but can be used for any other data communications purpose within their
operating parameters.
Ordering Information
Low Rider
L X L X - ST11
Roughrider
1
RR
L X - ST11
Shell Options
N= No GND
Tabs (Flat
Shell)
T= GND Tabs
Extended
Margin Link
BLANK=
Standard Power
2= +2dB Margin
3= +3dB Margin
5= +5dB Margin
Temperature
and coating
H= -40 to 85 C,
No Coating
M= -40 to 85 C,
Conformal
Coating
X X
X X
Mounting
BLANK= Solder
Posts
(0.125 length)
B= Screw Posts
(0.050 length)
1. See product data sheet for information on Roughrider products.
Key Features & Benefits
Low Profile Design - 0.386 inches max. height
Surface mount I/O pins for high speed signal integrity
All metal body, solder or screw mount options
Industrial Temp Range, Vibration tolerant design
RX data squelch on Signal Detect deassert
Individual (separate) +3.3 V power supply per port
Industry standard duplex multimode LC receptacle
Compliant with ANSI Fiber Channel FC-PI / PH2
EN-60825 / IEC-825 / CDRH Class 1 Compliant
Optional Parylene C Conformal Coating
High Power Options available
Optional addition of fiber pigtail
Transmitters:
VCCTX = 3.135V to 3.465V, T
A
= Operating Temperature Range
Parameter
Symbol
MIN
Typical
Optical Output Power
LxL-ST11xx
LxL2-ST11xx (+2dB Margin)
LxL3-ST11xx (+3dB Margin)
LxL5-ST11xx (+5dB Margin)
Extinction Ratio
Optical Modulation Amplitude (p-p)
2.125 GigaBaud
1.0625 GigaBaud
Total Jitter
1
1,2
MAX
-1.5
-1.5
-1.5
-1.5
Unit
dBm
dB
µW
µW
ps
P
O
ER
OMA
Tj
-10.0
-8.0
-7.0
-5.0
9
196
156
85
1. Assuming an Extinction Ratio of 9 dB
2. BER=10
-12
@ 2.125 GigaBaud, PRBS = 2
7
-1, NRZ, Compliant with FC-PI-2.
Stratos
LxLx-ST11xx Low Profile Optical Transceiver
Connectivity for
Business-Critical Continuity
TM
Receivers:
VCCRX = 3.135V to 3.465V, T
A
= Operating Temperature Range
Parameter
Symbol
MIN
Optical Sensitivity
2.125 GigaBaud
2
1.0625 GigaBaud
3
Optical Modulation Amplitude
2.125 GigaBaud
1.0625 GigaBaud
Stressed Receiver Sensitivity (OMA)
2.125 GigaBaud
50/125 µm MMF
62.5/125 µm MMF
1.0625 GigaBaud
50/125 µm MMF
62.5/125 µm MMF
1
Typical
MAX
0
0
Unit
dBm
dBm
µW
µW
µW
µW
µW
µW
P
I
OMA
-15.0
-17.0
49
31
96
109
55
67
1. Assuming an Extinction Ratio of 9 dB
2. BER=10
-12
@ 2.125 GigaBaud, PRBS = 2
7
-1, NRZ, Compliant with FC-PI-2.
3. BER=10
-12
@ 1.0625 GigaBaud, PRBS = 2
7
-1, NRZ, Compliant with FC-PH.
Link Distances
Fiber Specification
62.5/125 (200MHz*Km)
50/125 (500MHz*Km)
Application
2x Fiber Channel – ANSI X3.297 FC-PI
1x Fiber Channel – ANSI X3.297 FC-PH-2
2x Fiber Channel – ANSI X3.297 FC-PI
1x Fiber Channel – ANSI X3.297 FC-PH-2
Distance
150M
300M
300M
500M
For more information on this product consult the LxLx-ST11xx product data sheet.
IMPORTANT NOTICE
Stratos International, Inc. reserves the right to make changes to or discontinue any optical link product or service identified in this publication, without notice. Stratos International, Inc. recommends that its customers obtain the latest version of the
publications to verify, before placing orders, that the information being relied on is current. Stratos International, Inc. warrants performance of its optical link products to current specifications in accordance with the Stratos International, Inc. standard
warranty. Testing and other quality control techniques are utilized to the extent that Stratos International, Inc. has determined it to be necessary to support this warranty. Specific testing of all parameters of each optical link product is not necessarily
performed on all optical link products. Stratos International, Inc. products are not designed for use in life support appliances, devices, or systems where malfunction of a Stratos International, Inc. product can reasonably be expected to result in a personal
injury. Stratos International, Inc. customers using or selling optical link products for use in such applications do so at their own risk and agree to fully indemnify Stratos International, Inc. for any damages resulting from such improper use or sale. Stratos
International, Inc. assumes no liability for Stratos International, Inc. applications assistance, customer product design, software performance, or infringement of patents or services described here in. Nor does Stratos International, Inc. warrant or
represent that a license, either expressed or implied is granted under any patent right, copyright, or intellectual property right, and makes no representations or warranties that these products are free from patent, copyright, or intellectual property
rights. Applications that are described herein for any of the optical link products are for illustrative purposes only. Stratos International, Inc. makes no representation or warranty that such applications will be suitable for the specified use without further
testing or modification.
Emerson Network Power
Stratos Optical
1333 Gateway Drive, Suite 1007
Melbourne, FL 32901-2644
For product information:
www.stratosoptical.com
call (708) 457-2582 or 1-800-323-6858
