REVISIONS
ECN #
REV.
001
426
002
DESCRIPTION
REVISED PER ECR 111009AZ01
REVISED PER ECR 041212KH02
DATE
6/20/10
4/13/12
1
D
NOTES:
ROHS COMPLIANT
1.
2.
MATERIAL: HOUSING - NYLON 6/6, U.L.94-V0 RATING, BLACK (UNLESS OTHERWISE SPECIFIED)
CONTACTS - PHOSPHER BRONZE, TIN PLATED
3.
MOUNTING: SPACING ON .250" [6.35mm] CENTERS. OPTIONAL .060" [1.52mm] HOLES FOR OPPOSITE SIDE
MOUNTING. SAME SIDE MOUNTING , DELETE THE .060"[1.52mm] HOLES (SEE PATTERN)
4.
OPTO: STANDARD VISIBLE, IR LED, OR PHOTO DETECTOR WITH LEADS ON .100" [.25mm] CENTERS
5.
LED LEAD DIMENSIONS: MINIMUM .017" [.43mm] ROUND OR SQUARE SHAPE. MAXIMUM .030" [.76mm]
THICKNESS - .040" [1.02mm] WIDTH
6.
U.S. & FOREIGN PATENTS ISSUED
0.060in
1.52mm
THRU HOLES
FOR OPP. SIDE
MOUNTING
INITIALS
SMU
KH
CHK'D
DZ
ED
D
.040
1.02mm
.095
2.41mm
C
.100
2.54mm
PCB HOLE PATTERN
2X
0.015in
0.38mm
0.010in
0.25mm
C
SECTION A-A
0.100in
2.54mm
B
0.245in
6.22mm
0.010in
0.25mm
DETAIL B
SCALE 10 : 1
0.030in
0.76mm
POLARITY
REF
A
B
0.125in
3.18mm
0.010in
0.25mm
0.150in
3.81mm
0.330in
8.38mm
0.010in
0.25mm
DIMENSION STYLE: INCHES [MM]
GENERAL TOLERANCES UNLESS
OTHERWISE SPECIFIED
A
0.240in
6.10mm
APPROVAL
DATE
SMU
DZ
6/20/10
6/20/10
A
.X
.XX
.XXX
INCHES
.020
.010
.005
ANGLE 1'
MM
.508
.254
.127
DRAWN
CHECKED
12780 DANIELSON CT, SUITE A, POWAY, CA 92064 U.S.A
PHONE: (800) 522-5546 EMAIL: vccsales@vcclite.com
A
BREAK ALL CORNERS AND SHARP
EDGES .030 MAX
MATERIAL
TITLE:
SEE NOTES
P-C-LITE
SIZE DWG. NO.
R
VERTICAL MOUNT
REV
THIRD ANGLE PROJECTION
ORDERING CODE :
PCV 220
8
7
6
5
4
PROPRIETARY AND CONFIDENTIAL
FINISH
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
VISUAL COMMUNICATIONS COMPANY, INC.
ANY REPRODUCTION IN PART OR AS
A WHOLE WITHOUT THE WRITTEN
PERMISSION OF VISUAL
COMMUNICATIONS COMPANY, INC IS
PROHIBITED.
SEE NOTES
DO NOT SCALE DRAWING
B
2
PCV 220
1
002
SHEET 1 OF 1
SCALE: 5:1
3
