CLD-DS88 Rev 0
Product family data sheet
PRELIMINARY
cree Xlamp cXa1850 led
®
®
Product descriPtion
The
XLamp
CXA1850
expands
Cree’s family of High Density (HD)
LeD arrays, featuring a 12-mm
optical source and enabling lighting
manufacturers to create a new
generation of products that delivers
the same intensity and light quality
as
70-W
ceramic
metal
halide
(CmH) at up to 50 percent lower
power. The new HD class of CXA
arrays
provide
unrivaled
lumen
density that can reduce system
cost for the next generation of LeD
spotlights.
The
CXA
LeD
Design
Guide
features
• Available in ANSI white bins
as well as 4-step and 2-step
easyWhite
®
bins at 2700 K,
3000 K, 3500 K, 4000 K and
5000 K CCT
• Available in ANSI white bins as
well as 4-step easyWhite bins
at 5700 K and 6500 K CCT
• Available in 70-, 80-, 90- and
93-minimum CRI options
• Forward voltage: 35 v
• 85 °C binning and
characterization
• maximum drive current:
2100 mA
• 115° viewing angle, uniform
chromaticity profile
• Top-side solder connections
• Thermocouple attach point
• NEMA SSL-3 2011 standard flux
bins
table of contents
Characteristics .............................. 2
operating Limits ............................ 2
Flux Characteristics, easyWhite
order Codes and Bins .................... 3
Flux Characteristics, ANSI White
order Codes and Bins .................... 5
Relative Spectral power Distribution . 7
electrical Characteristics ................. 7
Relative Luminous Flux ................... 8
Typical Spatial Distribution .............. 9
performance Groups - Brightness..... 9
performance Groups - Chromaticity .10
Cree easyWhite Bins plotted on the
CIe 1931 Color Space ...................12
Cree ANSI White Bins plotted on
the CIe 1931 Color Space ..............13
Bin and order Code Formats ..........14
mechanical Dimensions..................14
Thermal Design ............................15
Notes ..........................................16
packaging ....................................17
provides basic information on the
requirements to use the CXA1850
LeD
successfully
in
luminaire
designs.
1
WWW.CRee.Com/XLAmp
1
Cree XLamp CXA LeD Design Guide,
Design Guide DG02, www.cree.com/
xlamp_app_notes/cxa_design_guide
Copyright © 2014 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, the Cree
logo, XLamp
®
and easyWhite
®
are registered trademarks of Cree, Inc.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
XLamp CXa1850 LED
PRELIMINARY
characteristics
characteristics
viewing angle (FWHm)
eSD withstand voltage (HBm per mil-Std-883D)
DC forward current
Reverse current
Forward voltage (@ 1400 mA, T
j
= 85 °C)
Forward voltage (@ 1400 mA, T
j
= 25 °C)
unit
degrees
v
mA
mA
v
v
35
42
minimum
typical
115
8000
2100*
0.1
maximum
*
Refer to the operating Limits section.
oPerating limits
The maximum current rating of the CXA1850 is dependent on the case temperature (Tc) when the LeD has reached
thermal equilibrium under steady-state operation. please refer to the mechanical Dimensions section on page 16 for
the location of the Tc measurement point.
CXA1850
2200
2000
1800
1600
1400
If (mA)
1200
1000
800
600
400
200
0
0
25
50
75
100
125
150
Case Temperature (°C)
Copyright © 2014 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, the Cree logo, XLamp
®
and EasyWhite
®
are registered
trademarks of Cree, Inc.
2
XLamp CXa1850 LED
PRELIMINARY
fluX characteristics, easyWhite order codes and bins (i
f
= 1400 ma, t
J
= 85 °c)
The following tables provide order codes for XLamp CXA1850 LeDs. For a complete description of the order code
nomenclature, please reference Bin and order Code Formats (page 16).
base order codes
min. luminous flux
@ 1400 ma
group
v4
70
6500 K
80
---
75
W2
W4
v2
v4
W2
v4
70
5700 K
80
---
75
W2
W4
v2
v4
W2
v4
70
75
W2
W4
v2
5000 K
80
---
v4
W2
T4
90
95
U2
U4
flux
(lm) @
85 °c
4545
4860
5225
4230
4545
4860
4545
4860
5225
4230
4545
4860
4545
4860
5225
4230
4545
4860
3440
3680
3955
flux
(lm) @
25 °c*
5231
5593
6014
4868
5231
5593
5231
5593
6014
4868
5231
5593
5231
5593
6014
4868
5231
5593
3959
4235
4551
50H
50H
50H
CXA1850-0000-000N00v450H
CXA1850-0000-000N00W250H
CXA1850-0000-000N00W450H
CXA1850-0000-000N0Hv250H
CXA1850-0000-000N0Hv450H
CXA1850-0000-000N0HW250H
CXA1850-0000-000N0UT450H
CXA1850-0000-000N0UU250H
CXA1850-0000-000N0UU450H
50F
50F
50F
57F
57F
65F
65F
cri
cct
range
min
typ
2-step order code
chromaticity
region
4-step order code
chromaticity
region
CXA1850-0000-000N00v465F
CXA1850-0000-000N00W265F
CXA1850-0000-000N00W465F
CXA1850-0000-000N0Hv265F
CXA1850-0000-000N0Hv465F
CXA1850-0000-000N0HW265F
CXA1850-0000-000N00v457F
CXA1850-0000-000N00W257F
CXA1850-0000-000N00W457F
CXA1850-0000-000N0Hv257F
CXA1850-0000-000N0Hv457F
CXA1850-0000-000N0HW257F
CXA1850-0000-000N00v450F
CXA1850-0000-000N00W250F
CXA1850-0000-000N00W450F
CXA1850-0000-000N0Hv250F
CXA1850-0000-000N0Hv450F
CXA1850-0000-000N0HW250F
CXA1850-0000-000N0UT450F
CXA1850-0000-000N0UU250F
CXA1850-0000-000N0UU450F
Notes
• Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a
tolerance of ±2 on CRI measurements.
* Flux values @ 25 °C are calculated and for reference only.
Copyright © 2014 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, the Cree logo, XLamp
®
and EasyWhite
®
are registered
trademarks of Cree, Inc.
3
