INCANDESCENT PANEL MOUNT INDICATORS
507 SERIES CARTRIDGES FOR USE WITH HOLDERS & CLIPS
507-3911-1431-600
RED
10
507-3911-1432-600
GREEN
10
507-3911-1433-600
AMBER
10
507-3911-1435-600
WHITE
10
507-3914-1471-600
RED
14
507-3914-1472-600
GREEN
14
507-3914-1473-600
AMBER
14
507-3914-1475-600
WHITE
14
507-3917-1471-600
RED
28
507-3917-1472-600
GREEN
28
507-3917-1473-600
AMBER
28
507-3917-1475-600
WHITE
28
507-3918-1437-600
CLEAR
28
507-3918-1471-600
RED
28
507-3918-1472-600
GREEN
28
507-3918-1473-600
AMBER
28
507-3918-1475-600
WHITE
28
507-5820-0747-600†
CLEAR
12
507-5821-0747-600†
CLEAR
28
507-5822-0747-600†
CLEAR
48
507-5824-0747-600†
CLEAR
120
† Use Holder 250-8758-33-504 and 250 Series Cap
PART NO.
*
COLOR
V
F
mA
40
40
40
40
80
80
80
80
40
40
40
40
40
40
40
40
40
170
40
53
25
CP
0.08
0.08
0.08
0.08
0.30
0.30
0.30
0.30
0.34
0.34
0.34
0.34
0.30
0.30
0.30
0.30
0.30
2.10
1.20
1.50
1.50
LIFE
HOURS
10,000
10,000
10,000
10,000
15,000
15,000
15,000
15,000
4,000
4,000
4,000
4,000
7,000
7,000
7,000
7,000
7,000
5,000
5,000
5,000
5,000
Fig. 1
FIG
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
3
3
3
8.38
[.330]
28.96 [1.140] MAX
6.73
[.265]
5.16
[.203]
7.14
[.280]
.51
[.020]
Fig. 2
8.38
[.330]
33.73 [1.33] MAX
11.51
[.45]
5.16
[.203]
7.14
[.280]
Fig. 3
8.38
[.330]
37.30 [1.47] MAX
2.74 [.11]
5.16
[.203]
7.14
[.280]
*
PART NUMBER ORDERING CODE
507 – 39xx – xxxx – 600
Series
Lens Shape:
14 – Fig 1 = Cylindrical
09 – Fig 2 = Stovepipe
250 & 508 SERIES HOLDERS FOR 3/8" MOUNTING HOLE
HOLDER WITHOUT COLLAR*
FLANGE NUT
13.1 [.515]
3/8 - 32 NEF THD
HOLDER WITH COLLAR *
COLLAR
FLANGE NUT
3/8 - 32 NEF THD
HOLDER WITHOUT COLLAR
†
FLANGE NUT
3/8 - 32 NEF THD
7.90
[.310]
15.90 [.625]
30.96 [1.22] MAX
5.00
[.197]
7.10
[.280]
15.90 [.625]
5.00
[.197]
43.26 [1.703] MAX
33.34 [1.31] MAX
5.00
[.197]
250-8738-14-504
508-8738-504
250-8758-33-504
for Figure 3 Only
250 Series Caps for use with 507 cartridges.
CAP PART NO.
COLOR
FIG
250-3531-500
250-3532-500
250-3533-500
250-3535-500
250-3537-500
RED
GREEN
AMBER
WHITE
CLEAR
4
4
4
4
4
13.10
[.52]
Fig. 4
*
PART NUMBER ORDERING CODE
250 – xx38 – 14 – 504
508 – xx38 – 504
Series
Terminal Type:
87 = Turret Terminals
74 = Solder Blade (Not Shown)
75 = Solder Cups (Not Shown)
12.25
[.50]
MAX
Material & Finish: Holder – Black Anodized Aluminum, Cap – Polycarbonate, Cartridge Clear Anodized Aluminum
515 SERIES CONNECTORS & SPEED CLIPS FOR 9/32" MOUNTING HOLE
CARTRIDGE WITH SPEED CLIP & CONNECTOR
1.59 [.06]
PANEL
30.02 [1.19]
15.88
[.625]
CONNECTOR
515-0012
15.88 [.625]
CONNECTOR
515-0074
13.89
[.547]
4.76
[.188]
SPEED CLIP 515-0051
9.14
[.360]
6.86
[.270]
7.49
[.295]
Dimensions in mm [inches]
