Product Specification
8 Gigabit RoHS Compliant Long-Wavelength SFP+ Transceiver
FTLF1428P2BNV
PRODUCT FEATURES
•
•
•
•
•
•
•
•
•
•
Up to 8.5 Gb/s bi-directional
data links
Hot-pluggable SFP+ footprint
Built-in digital diagnostic functions
1310nm DFB laser transmitter
Duplex LC connector
RoHS compliant and Lead Free
Up to 10 km on 9/125µm SMF
Metal enclosure, for lower EMI
Single 3.3V power supply
Extended operating temperature
range: -5°C to 85°C
APPLICATIONS
•
Tri Rate 2.125 / 4.25 / 8.5 Gb/s
Fibre Channel through Rate Select
Finisar’s FTLF1428P2BNV SFP+ transceivers are designed for use in Fibre Channel
links up to 8.5 Gb/s data rate and up to 10 km link length. They are compliant with FC-
PI-4 Rev. 8.00
1
and SFF-8472 Rev 10.2
3
, and compatible with SFF-8432
2
and applicable
portions of SFF-8431 Rev. 3.0
4
. The optical transceiver is compliant per the RoHS
Directive 2011/65/EU
5
. See Finisar Application Note AN-2038 for more details
6
.
PRODUCT SELECTION
FTLF1428P2BNV
Finisar Corporation August 2015
Rev D1
Page 1
FTLF1428P2BNV Product Specification
I.
Pin
1
2
3
4
5
6
7
Pin Descriptions
Symbol
V
EET
T
FAULT
T
DIS
SDA
SCA
MOD_ABS
RS0
Name/Description
Transmitter Ground (Common with Receiver Ground)
Transmitter Fault.
Transmitter Disable. Laser output disabled on high or open.
2-wire Serial Interface Data Line (MOD-DEF2)
2-wire Serial Interface Clock (MOD-DEF1)
Module Absent, connected to V
EET
or V
EER
Rx Rate Select:
Open or Low = 2.125 or 4.25 Gb/s Fibre Channel (Low Bandwidth)
High = 8.5 Gb/s Fibre Channel (High Bandwidth)
Loss of Signal indication. Logic 0 indicates normal operation.
Tx Rate Select:
Open or Low = 2.125 or 4.25 Gb/s Fibre Channel (Low Bandwidth)
High = 8.5 Gb/s Fibre Channel (High Bandwidth)
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Inverted DATA out. AC Coupled
Receiver Non-inverted DATA out. AC Coupled
Receiver Ground (Common with Transmitter Ground)
Receiver Power Supply
Transmitter Power Supply
Transmitter Ground (Common with Receiver Ground)
Transmitter Non-Inverted DATA in. AC Coupled.
Transmitter Inverted DATA in. AC Coupled.
Transmitter Ground (Common with Receiver Ground)
Ref.
1
2
3
4
4
4
5
8
9
LOS
RS1
6
5
10
11
12
13
14
15
16
17
18
19
20
V
EER
V
EER
RD-
RD+
V
EER
V
CCR
V
CCT
V
EET
TD+
TD-
V
EET
1
1
1
1
1
Notes:
1. Circuit ground is internally isolated from chassis ground.
2. T
FAULT
is an open collector/drain output, which should be pulled up with a 4.7k – 10k Ohms resistor on
the host board if intended for use. Pull up voltage should be between 2.0V to Vcc + 0.3V. A high
output indicates a transmitter fault caused by either the TX bias current or the TX output power
exceeding the preset alarm thresholds. A low output indicates normal operation. In the low state, the
output is pulled to <0.8V.
3. Laser output disabled on T
DIS
>2.0V or open, enabled on T
DIS
<0.8V.
4. Should be pulled up with 4.7k – 10kohms on host board to a voltage between 2.0V and 3.6V.
MOD_ABS pulls line low to indicate module is plugged in.
5. Rate select can also be set through the 2-wire bus in accordance with SFF-8472 v. 10.2. Rx Rate
Select is set at Bit 3, Byte 110, Address A2h. Tx Rate Select is set at Bit 3, Byte 118, Address A2h.
Note: writing a “1” selects maximum bandwidth operation. Rate select is the logic OR of the input
state of Rate Select Pin and 2-wire bus.
6. LOS is open collector output. Should be pulled up with 4.7k – 10kohms on host board to a voltage
between 2.0V and 3.6V. Logic 0 indicates normal operation; logic 1 indicates loss of signal.
Finisar Corporation August 2015
Rev D1
Page 2
FTLF1428P2BNV Product Specification
Pinout of Connector Block on Host Board
II.
Absolute Maximum Ratings
Parameter
Maximum Supply Voltage
Storage Temperature
Case Operating Temperature
Relative Humidity
Symbol
Vcc
T
S
T
OP
RH
Min
-0.5
-40
-5
0
Typ
Max
4.5
85
85
85
Unit
V
°C
°C
%
Ref.
1
III.
Electrical Characteristics
(T
OP
= -5 to 85
°C,
V
CC
= 3.00 to 3.60 Volts)
Parameter
Symbol
Vcc
Icc
R
in
Vin,pp
V
D
V
EN
Vout,pp
t
r,
t
f
t
r,
t
f
V
LOS fault
V
LOS norm
PSR
RX
∆
DJ
RX
RX
RX
Min
3.00
Typ
200
100
90
2
Vee
185
800
Vcc
Vee+ 0.8
425
120
60
Vcc
HOST
Vee+0.8
51.7
122.4
25.9
61.2
Max
3.60
300
Unit
V
mA
Ω
mV
V
V
mV
ps
ps
V
V
mVpp
ps
ps
ps
ps
Ref.
2
2
3
Supply Voltage
Supply Current
Transmitter
Input differential impedance
Single ended data input swing
Transmit Disable Voltage
Transmit Enable Voltage
Receiver
Single ended data output swing
Data output rise/fall time, 2.125, 4.25 Gb/s
Data output rise/fall time, 8.5 Gb/s
LOS Fault
LOS Normal
Power Supply Rejection
Deterministic Jitter Contribution
< 4.25 Gb/s
Total Jitter Contribution < 4.25 Gb/s
Deterministic Jitter Contribution
= 4.25 Gb/s
Total Jitter Contribution = 4.25 Gb/s
4
5
6
6
7
7
8
9,10
10
9,10
10
2
Vee
100
∆
TJ
∆
DJ
∆
TJ
Finisar Corporation August 2015
Rev D1
Page 3
FTLF1428P2BNV Product Specification
Notes:
1. Non-condensing.
2. Module power consumption never exceeds 1W.
3. AC coupled.
4. Or open circuit.
5. Into 100 ohm differential termination.
6. 20 – 80 %.
7. LOS is LVTTL. Logic 0 indicates normal operation; logic 1 indicates no signal detected.
8. All transceiver specifications are compliant with a power supply sinusoidal modulation of 20 Hz to 1.5
MHz up to specified value applied through the power supply filtering network shown on page 23 of the
Small Form-factor Pluggable (SFP) Transceiver MultiSource Agreement (MSA)
6
, September 14, 2000.
The Power Supply Rejection applies for a supply voltage range of 3.1 to 3.6 V.
9. Measured with DJ-free data input signal. In actual application, output DJ will be the sum of input DJ
and
∆
DJ.
10. For 8.5 Gb/s operation, Deterministic Jitter and Total Jitter are not specified per FC-PI-4 Rev 8.00.
Jitter values for gamma T and gamma R are controlled by TDP and stressed receiver sensitivity.
IV.
Optical Characteristics (T
OP
= -5 to 85
°C,
V
CC
= 3.00 to 3.60 Volts)
Parameter
Symbol
P
O,RH
P
O,RL
λ
σ
OMA
TDP
t
r
/ t
f
Min
-8.4
-8.4
1285
290
3.2
90
-128
0.042
0.029
0.015
+0.5
1360
-19
-30
0.5
Typ
Max
+0.5
-3
1345
1
Unit
dBm
dBm
nm
nm
µW
dB
ps
dB/Hz
mW
mW
mW
dBm
nm
dB
dBm
dBm
dB
Ref.
2
3
4
4
4,5
6
7
Transmitter
Output Opt. Power, 8.5 Gb/s
Output Opt. Power, 2.125, 4.25 Gb/s
Optical Wavelength
Spectral Width
Optical Modulation Amplitude
Transmitter and Dispersion Penalty, 8.5 Gb/s
Optical Rise/Fall Time, 2.125, 4.25 Gb/s
RIN
Receiver
Unstressed Receiver OMA Sensitivity, 8.5 Gb/s
Unstressed Receiver OMA Sensitivity, 4.25 Gb/s
Unstressed Receiver OMA Sensitivity, 2.125 Gb/s
Average Received Power
Optical Center Wavelength
Return Loss
LOS De-Assert
LOS Assert
LOS Hysteresis
R
SENSr
R
SENS4
R
SENS2
Rx
MAX
λ
C
LOS
D
LOS
A
8
8
8
1260
12
Notes:
1. Class 1 Laser Safety per FDA/CDRH and EN (IEC) 60825 regulations.
2. High Bandwidth Mode. Class 1 Laser Safety per FDA/CDRH and EN (IEC) 60825 regulations.
3. Low Bandwidth Mode. Class 1 Laser Safety per FDA/CDRH and EN (IEC) 60825 regulations.
4. Also specified to meet curves in FC-PI-4 Rev 8.00
1
Figures 22 and 23, which allow trade-off between
wavelength, spectral width and OMA.
5. Equivalent extinction ratio specification for Fibre Channel. Allows smaller ER at higher average
power.
6. For 8.5 Gb/s operation, Jitter values for gamma T and gamma R are controlled by TDP and stressed
receiver sensitivity.
7. Unfiltered, 20-80%. Complies with IEEE 802.3 (Gig. E), FC 1x and 2x eye masks when filtered.
8. Measured with conformance signals defined in FC-PI-4 Rev. 8.00 specifications. Value in OMA.
Measured with PRBS 2
7
-1 at 10
-12
BER.
Finisar Corporation August 2015
Rev D1
Page 4
FTLF1428P2BNV Product Specification
V.
General Specifications
Parameter
Symbol
BR
BER
L
MAX1
Min
2.125
Typ
Max
8.5
10
-12
Units
Gb/sec
km
Ref.
1
2
3
Data Rate
Bit Error Rate
Max. Supported Link Length on
9/125
µm
SMF , 2.125, 4.25, 8.5
Gb/s
10
Notes:
1. 2x/4x/8x Fibre Channel compliant.
2. Tested with a PRBS 2
7
-1 test pattern.
3.
Distances are based on FC-PI-4 Rev. 8.00
1
and IEEE 802.3 standards.
VI.
Environmental Specifications
These Finisar 1310nm Extended Temperature SFP+ transceivers have an operating
temperature range from -5°C to +85°C case temperature.
Parameter
Case Operating Temperature
Storage Temperature
Symbol
T
op
T
sto
Min
-5
-40
Typ
Max
85
85
Units
°C
°C
Ref.
VII.
Regulatory Compliance
Finisar transceivers are Class 1 Laser Products and comply with US FDA regulations.
These products are certified by TÜV and CSA to meet the Class 1 eye safety
requirements of EN (IEC) 60825 and the electrical safety requirements of EN (IEC)
60950. Copies of certificates are available at Finisar Corporation upon request.
Finisar Corporation August 2015
Rev D1
Page 5
