ELYI-K62C5-0LPGS-P6500 datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> ELYI-K62C5-0LPGS-P6500

ELYI-K62C5-0LPGS-P6500: DescriptionHigh Power LEDs - White Cool White 6500K 350lm 700mA; CategoryLED optoelectronic/LED; File Size1011KB，40 Pages; ManufacturerEVERLIGHT; Websitehttp://www.everlight.com/

Download Datasheet Parametric Compare View All

ELYI-K62C5-0LPGS-P6500 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ELYI-K62C5-0LPGS-P6500	-	-	View	Buy Now

ELYI-K62C5-0LPGS-P6500 Overview

High Power LEDs - White Cool White 6500K 350lm 700mA

ELYI-K62C5-0LPGS-P6500 Parametric

Parameter Name	Attribute value
Product Category	High Power LEDs - White
Manufacturer	EVERLIGHT
RoHS	Details
Illumination Color	White (Cool White)
Wavelength/Color Temperature	6500 K
Luminous Flux/Radiant Flux	350 lm
Color Rendering Index - CRI	70
Viewing Angle	105 deg
If - Forward Current	700 mA
Vf - Forward Voltage	8 V
Power Rating	5 W
Mounting Style	SMD/SMT
Length	6 mm
Width	6 mm
Height	3.75 mm
Maximum Operating Temperature	+ 100 C
Minimum Operating Temperature	- 40 C
Packaging	Reel
Color Temperature	6500 K
Lens Shape	Dome
Factory Pack Quantity	250
Type	High Power LEDs

Preview

Download Datasheet

View All

熠

5W Series

“Yi [Yi] is the English translation for the Chinese word meaning Dazzling or Sparkling. This

multi-chip package has the brightness to illuminate the space around it, a beacon in the dark.”

Introduction

The Yi series is a high power, 4-chip device with very low

thermal resistance as a result of the ceramic substrate. The

series is a surface-mount high-power device featuring high

brightness combined with a compact size that is suitable for

all kinds of lighting applications such as general illumination,

spot, signal, industrial and commercial lighting.

Features



Soldering method: SMT

Binning Parameters: Brightness, Forward

Voltage, Wavelength and Chromaticity

Moisture Sensitivity Level:1

RoHS compliant

Matches ANSI binning

Reliability testing conforms to IESNA LM80

Lumen maintenance test method

Applications



General Lighting

Indoor and Outdoor Lighting

Retrofit Bulbs

Decorative and Entertainment

Lighting

Signal Lighting/Beacon Lighting

Exterior and Interior Automotive

Illumination

www.everlight.com

DATASHEET

5W Series

Table of Contents

Product Nomenclature .................................................................................................................................... 3

Absolute Maximum Ratings ........................................................................................................................... 4

JEDEC Moisture Sensitivity........................................................................................................................... 4

Luminous Flux Characteristics for the Yi series............................................................................................. 5

PN of Yi High Luminous Series: White LEDs ............................................................................................. 11

White Bin Structure ...................................................................................................................................... 17

Forward Voltage Bins ................................................................................................................................... 23

Optical Characteristics.................................................................................................................................. 24

Mechanical Dimension ................................................................................................................................. 25

Pad Configuration......................................................................................................................................... 26

Reflow Soldering Characteristics ................................................................................................................. 27

Wavelength Characteristics .......................................................................................................................... 28

Typical Light Output Characteristic vs. Thermal Pad Temperature ............................................................. 29

Typical Electrical Characteristics ................................................................................................................. 30

Typical Relative Luminous Flux vs. Forward Current ................................................................................. 30

Typical CCT Shift Characteristics vs. Forward Current ............................................................................... 31

Current Derating Curves............................................................................................................................... 32

Typical Radiation Patterns ............................................................................................................................ 33

Typical Radiation Patterns ............................................................................................................................ 35

Emitter Tape Packaging ................................................................................................................................ 37

Emitter Reel Packaging ................................................................................................................................ 38

Product Labeling .......................................................................................................................................... 38

Storage Conditions ....................................................................................................................................... 39

Revision History ........................................................................................................................................... 40

www.everlight.com

ELYI-K62C5-0LPGS-P6500 Related Products

	ELYI-K62C5-0LPGS-P6500	ELYI-K32M5-0LPGS-P3000	ELYI-K62C5-0LPGS-P5700	ELYI-K72C5-0LPGS-P5700	ELYI-K22M5-0LPGS-P3000	ELYI-K52C5-0LPGS-P6500	ELYI-K72C5-0LPGS-P6500	ELYI-K52C5-0LPGS-P5700	ELYI-K42M5-0LPGS-P3000
Description	High Power LEDs - White Cool White 6500K 350lm 700mA	High Power LEDs - White Warm White 3000K 275lm 700mA	High Power LEDs - White Cool White 5700K 350lm 700mA	High Power LEDs - White Cool White 5700K 375lm 700mA	High Power LEDs - White Warm White 3000K 250lm 700mA	High Power LEDs - White Cool White 6500K 325lm 700mA	High Power LEDs - White Cool White 6500K 375lm 700mA	High Power LEDs - White Cool White 5700K 325lm 700mA	High Power LEDs - White Warm White 3000K 300lm 700mA
Is it lead-free?	-	-	-	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	-	-	-	conform to	conform to	conform to	conform to	conform to	conform to
Maker	-	-	-	EVERLIGHT	EVERLIGHT	-	EVERLIGHT	EVERLIGHT	EVERLIGHT
package instruction	-	-	-	ROHS COMPLIANT, SMD, 8 PIN	ROHS COMPLIANT, SMD, 8 PIN	ROHS COMPLIANT, SMD, 8 PIN	ROHS COMPLIANT, SMD, 8 PIN	ROHS COMPLIANT, SMD, 8 PIN	ROHS COMPLIANT, SMD, 8 PIN
Reach Compliance Code	-	-	-	compliant	compliant	compliant	compliant	compliant	compliant
color	-	-	-	COOL WHITE	WARM WHITE	COOL WHITE	COOL WHITE	COOL WHITE	WARM WHITE
Configuration	-	-	-	2 BANKS, SERIES CONNECTED, 2 ELEMENTS	2 BANKS, SERIES CONNECTED, 2 ELEMENTS	2 BANKS, SERIES CONNECTED, 2 ELEMENTS	2 BANKS, SERIES CONNECTED, 2 ELEMENTS	2 BANKS, SERIES CONNECTED, 2 ELEMENTS	2 BANKS, SERIES CONNECTED, 2 ELEMENTS
Maximum forward current	-	-	-	1 A	1 A	1 A	1 A	1 A	1 A
Installation features	-	-	-	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Number of functions	-	-	-	1	1	1	1	1	1
Number of terminals	-	-	-	8	8	8	8	8	8
Maximum operating temperature	-	-	-	100 °C	100 °C	100 °C	100 °C	100 °C	100 °C
Minimum operating temperature	-	-	-	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Optoelectronic device types	-	-	-	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED
total height	-	-	-	4.28 mm	4.28 mm	4.28 mm	4.28 mm	4.28 mm	4.28 mm
method of packing	-	-	-	TAPE AND REEL 7\"	TAPE AND REEL 7\"	TAPE AND REEL 7"	TAPE AND REEL 7\"	TAPE AND REEL 7\"	TAPE AND REEL 7\"
shape	-	-	-	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND
size	-	-	-	5.7 mm	5.7 mm	5.7 mm	5.7 mm	5.7 mm	5.7 mm
surface mount	-	-	-	YES	YES	YES	YES	YES	YES
perspective	-	-	-	105 deg	105 deg	105 deg	105 deg	105 deg	105 deg
