IllumInatIon
luXEon XF-3535l
Turnkey solution on a flexible substrate with optimized
performance and uniform light distribution
LUXEON XF-3535L is a fully integrated solution optimized for lighting
applications requiring flexible linear LED arrays that can easily fit into
any luminaire housing form factor. The turnkey solution minimizes time
to market and simplifies supply chain by reducing optical and mechanical
design efforts. Combined with LUXEON 3535L, LUXEON XF-3535L
provides the same powerful optical performance guaranteed by
LUXEON LEDs.
FEaturEs and BEnEFIts
1000–5000 lumen strips enabling efficacies of up to 157 lm/W
A full range of CCT/CRI offerings: 2200–5700K with 70–90CRI minimums
Complete integrated solution guarantees simplified supply chain and
faster time to market
Backside adhesive for attachment to heat sink allows for ease of mounting
and assembly
Available with solder terminals or push-in wire connectors for easy
electrical connection
UL-recognized component [E335118]
5 year limited warranty
PrImary aPPlIcatIons
Downlights
Indoor Area Lighting
Specialty Lighting
COMPLIANT
RoHS
LUXEON XF-3535L product performance at 100mA/LED, T
j
=25°C.
nomInal
cct
mInImum
crI
lumInous FluX
[1]
(lm)
mInImum
1080
2200K
80
1680
3240
1368
80
2700K
85
2128
4104
1080
1680
3240
1368
3000K
80
2128
4104
1512
3500K
80
2352
4536
1512
80
4000K
85
2352
4536
1224
1904
3672
1512
5000K
80
2352
4536
1512
80
5700K
70
2352
4536
1584
2464
4752
tyPIcal
1206
1876
3618
1476
2296
4428
1224
1904
3672
1512
2352
4536
1548
2408
4644
1584
2464
4752
1368
2128
4104
1692
2632
5076
1548
2408
4644
1692
2632
5076
tyPIcal lumInous
EFFIcacy (lm/W)
112
112
112
137
137
137
113
113
113
140
140
140
143
143
143
147
147
147
127
127
127
157
157
157
143
143
143
157
157
157
tyPIcal ForWard tEst currEnt
VoltagE (V
f
)
(ma)
18
21
36
18
21
36
18
21
36
18
21
36
18
21
36
18
21
36
18
21
36
18
21
36
18
21
36
18
21
36
600
800
900
600
800
900
600
800
900
600
800
900
600
800
900
600
800
900
600
800
900
600
800
900
600
800
900
600
800
900
Part numBEr
[2]
L235-2280AHLxByAC0
L235-2280AMLF5WAD0
L235-2280AULM5JAI0
L235-2780AHLxByAC0
L235-2780AMLF5WAD0
L235-2780AULM5JAI0
L235-2790AHLxByAC0
L235-2790AMLF5WAD0
L235-2790AULM5JAI0
L235-3080AHLxByAC0
L235-3080AMLF5WAD0
L235-3080AULM5JAI0
L235-3580AHLxByAC0
L235-3580AMLF5WAD0
L235-3580AULM5JAI0
L235-4080AHLxByAC0
L235-4080AMLF5WAD0
L235-4080AULM5JAI0
L235-4090AHLxByAC0
L235-4090AMLF5WAD0
L235-4090AULM5JAI0
L235-5080AHLxByAC0
L235-5080AMLF5WAD0
L235-5080AULM5JAI0
L235-5780AHLxByAC0
L235-5780AMLF5WAD0
L235-5780AULM5JAI0
L235-5770AHLxByAC0
L235-5770AMLF5WAD0
L235-5770AULM5JAI0
Notes:
1. Lumileds maintains a tolerance of ±7.5% on flux measurements.
2. “x” and “y” are part number attributes as explained in product datasheet.
LUXEON XF-3535L physical configurations.
Part numBEr
L235-xxyyAHLGBAAC0
L235-xxyyAHLGBBAC0
L235-xxyyAHLCBAAC0
L235-xxyyAHLCBBAC0
L235-xxyyAMLF5WAD0
L235-xxyyAULM5JAI0
lEd
count
36
36
36
36
56
108
FlEX strIP
lEngth (mm)
600
600
300
300
525
1150
FlEX strIP
WIdth (mm)
10
10
10
10
5.25
5.25
lEd PItch
[1]
(mm)
16.67
16.67
8
8
8.45
10
ElEctrIcal
conFIguratIon
6 Parallel x 6 Series LEDs
6 Parallel x 6 Series LEDs
6 Parallel x 6 Series LEDs
6 Parallel x 6 Series LEDs
8 Parallel x 7 Series LEDs
9 Parallel x 12 Series LEDs
ElEctrIcal
connEctIon
Tin Contacts
IDC Connectors
Tin Contacts
IDC Connectors
IDC Connectors
IDC Connectors
Notes:
1. LED pitch is measured from optical center to optical center of neighboring LED packages.
©2016 Lumileds Holding B.V. All rights reserved.
LUXEON is a registered trademark of the Lumileds Holding B.V.
in the United States and other countries.
lumileds.com
Neither Lumileds Holding B.V. nor its affiliates shall be liable for any kind of loss of data or any
other damages, direct, indirect or consequential, resulting from the use of the provided
information and data. Although Lumileds Holding B.V. and/or its affiliates have attempted to
provide the most accurate information and data, the materials and services information and data
are provided “as is,” and neither Lumileds Holding B.V. nor its affiliates warrants or guarantees
the contents and correctness of the provided information and data. Lumileds Holding B.V. and its
affiliates reserve the right to make changes without notice. You as user agree to this disclaimer
and user agreement with the download or use of the provided materials, information and data.
PB142 LUXEON XF-3535L Product Brief 20160402
