Product Specification
RoHS-6 Compliant
Industrial Temperature 10Gb/s 850nm Multimode
SFP
+
Datacom Transceiver
FTLX8573D3BTL
PRODUCT FEATURES
•
•
•
•
•
•
•
•
•
•
•
Hot-pluggable SFP+ footprint
Supports 9.95 to 10.5 Gb/s bit rates
Power dissipation < 1W
RoHS-6 compliant (lead-free)
Industrial temperature range
-40°C to 85°C
Single 3.3Vpower supply
Maximum link length of 400m on
4700 MHZ-km OM4 MMF
Heated 850nm VCSEL laser
Receiver limiting electrical
interface
Duplex LC connector
Built-in digital diagnostic functions
APPLICATIONS
•
•
10GBASE-SR/SW 10G Ethernet
1200-Mx-SN-I 10G Fibre Channel
Finisar’s FTLX8573D3BTL Industrial Temperature 10Gb/s SFP+ transceivers are
designed for use in 10-Gigabit Ethernet links over multimode fiber. They are compliant
with SFF-8431
1
, SFF-8432
2
, IEEE 802.3ae 10GBASE-SR/SW
3
and 10G Fibre Channel
1200-Mx-SN-I
4
. Digital diagnostics functions are available via a 2-wire serial interface,
as specified in SFF-8472
5
. The FTLX8573D3BTL is a “limiting module”, i.e., it employs
a limiting receiver. Host board designers using an EDC PHY IC should follow the IC
manufacturer’s recommended settings for interoperating the host-board EDC PHY with a
limiting receiver SFP+ module. The optical transceivers are compliant per the RoHS
Directive 2011/65/EU. See Finisar Application Note AN-2038 for more details.
PRODUCT SELECTION
FTLX8573D3BTL
Finisar Corporation – August 2015
Rev. C1
Page 1
FTLX8573D3BTL Product Specification
I.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Pin Descriptions
Symbol
V
EET
T
FAULT
T
DIS
SDA
SCL
MOD_ABS
RS0
RX_LOS
RS1
V
EER
V
EER
RD-
RD+
V
EER
V
CCR
V
CCT
V
EET
TD+
TD-
V
EET
Name/Description
Transmitter Ground (Common with Receiver Ground)
Transmitter Fault.
Transmitter Disable. Laser output disabled on high or open.
2-wire Serial Interface Data Line
2-wire Serial Interface Clock Line
Module Absent. Grounded within the module
No connection required
Loss of Signal indication. Logic 0 indicates normal operation.
No connection required
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Inverted DATA out. AC Coupled
Receiver Non-inverted DATA out. AC Coupled
Receiver Ground (Common with Transmitter Ground)
Receiver Power Supply
Transmitter Power Supply
Transmitter Ground (Common with Receiver Ground)
Transmitter Non-Inverted DATA in. AC Coupled.
Transmitter Inverted DATA in. AC Coupled.
Transmitter Ground (Common with Receiver Ground)
Ref.
1
2
3
4
4
4
5
1
1
1
1
1
Notes:
1. Circuit ground is internally isolated from chassis ground.
is an open collector/drain output, which should be pulled up with a 4.7k – 10k Ohms resistor on
2. T
FAULT
3.
4.
5.
the host board if intended for use. Pull up voltage should be between 2.0V to Vcc + 0.3V. A high
output indicates a transmitter fault caused by either the TX bias current or the TX output power
exceeding the preset alarm thresholds. A low output indicates normal operation. In the low state, the
output is pulled to <0.8V.
Laser output disabled on T
DIS
>2.0V or open, enabled on T
DIS
<0.8V.
Should be pulled up with 4.7kΩ – 10kΩ on host board to a voltage between 2.0V and 3.6V.
MOD_ABS pulls line low to indicate module is plugged in.
LOS is open collector output. Should be pulled up with 4.7kΩ – 10kΩ on host board to a voltage
between 2.0V and 3.6V. Logic 0 indicates normal operation; logic 1 indicates loss of signal.
VeeT
1
VeeT
TD-
2
TX_Fault
TD+
3
TX_Disable
VeeT
4
SDA
VccT
20
19
18
17
16
Towards
Bezel
5
SCL
VccR
15
6
MOD_ABS
VeeR
14
Towards
ASIC
7
RS0
RD+
13
8
RX_LOS
RD-
12
9
RS1
VeeR
11
10
VeeR
Figure 1. Diagram of Host Board Connector Block Pin Numbers and Names.
Finisar Corporation - August 2015
Rev C1
Page 2
FTLX8573D3BTL Product Specification
II.
Absolute Maximum Ratings
Exceeding the limits below may damage the transceiver module permanently.
Parameter
Maximum Supply Voltage
Storage Temperature
Case Operating Temperature
Relative Humidity
Notes:
I. Non-condensing.
Symbol
Vcc
T
S
T
A
RH
Min
-0.5
-40
-40
0
Typ
Max
4.0
85
85
85
Unit
V
°C
°C
%
Ref.
1
III.
Electrical Characteristics
(T
OP
= -40 to 85
°C,
V
CC
= 3.14 to 3.46 Volts)
Parameter
Symbol
Vcc
Icc
R
in
Vin,pp
V
D
V
EN
Vout,pp
t
r
V
LOS fault
V
LOS norm
VccT/VccR
Min
3.14
Typ
Max
3.46
289
Unit
V
mA
Ω
mV
V
V
mV
ps
V
V
mVpp
Ref.
Supply Voltage
Supply Current
Transmitter
Input differential impedance
Differential data input swing
Transmit Disable Voltage
Transmit Enable Voltage
Receiver
Differential data output swing
Data output rise time, fall time
LOS Fault
LOS Normal
Power Supply Noise Tolerance
100
180
2
Vee
700
Vcc
Vee+ 0.8
1
300
850
28
2
Vcc
HOST
Vee
Vee+0.8
Per SFF-8431 Rev 4.1
2,6
3
4
4
5
Notes:
1. Connected directly to TX data input pins. AC coupling from pins into laser driver IC.
2. Into 100Ω differential termination.
3. 20 – 80 % . Measured with Module Compliance Test Board and OMA test pattern. Use of four 1’s
and four 0’s in sequence in the PRBS^9 is an acceptable alternative. SFF-8431 Rev 4.1
4. LOS is an open collector output. Should be pulled up with 4.7kΩ – 10kΩ on the host board.
Normal operation is logic 0; loss of signal is logic 1.
5. Testing methodology per SFF-8431. Rev 4.1
6. The FTLX8573D3BTL is a “limiting module”, i.e., it employs a limiting receiver. Host board
designers using an EDC PHY IC should follow the IC manufacturer’s recommended settings for
interoperating the host-board EDC PHY with a limiting receiver SFP+ module.
Finisar Corporation - August 2015
Rev C1
Page 3
FTLX8573D3BTL Product Specification
IV.
Optical Characteristics
(T
OP
= -40 to 85
°C,
V
CC
= 3.14 to 3.46 Volts)
Symbol
P
OMA
P
AVE
λ
∆λ
rms
ER
TDP
P
OFF
Tx
j
<4.5µm
<19µm
RIN
12
OMA
R
SENS1
R
SENS2
P
MAX
λ
C
R
rx
LOS
D
LOS
A
+0.5
840
86
-128
-11.1
-7.5
-5
840
3.0
Min
Typ
-1.5
-1
860
0.45
3.9
-30
Per IEEE 802.3ae requirements
30
Max
Unit
dBm
dBm
nm
dB
dB
dB
dBm
Ref.
1
2
1
1
Parameter
Transmitter
Optical Modulation Amplitude
(OMA)
Average Launch Power
Optical Wavelength
RMS Spectral Width
Optical Extinction Ratio
Transmitter and Dispersion Penalty
Average Launch power of OFF
transmitter
Tx Jitter
Encircled Flux
Relative Intensity Noise
Receiver
Receiver Sensitivity (OMA)
@ 10.3Gb/s
Stressed Receiver Sensitivity
(OMA) @ 10.3Gb/s
Maximum Input Power
Wavelength Range
Receiver Reflectance
LOS De-Assert
LOS Assert
LOS Hysteresis
Notes:
1.
2.
3.
4.
5.
850
5.5
%
dB/Hz
dBm
dBm
dBm
nm
dB
dBm
dBm
dB
3
4
5
860
-12
-14
-23
-30
0.5
Per Tradeoff Table 52.8, IEEE 802.3ae 2005
Average Power figures are informative only, per IEEE802.3ae.
Measured into Type A1a (50/125 μm multimode) fiber per ANSI/TIA/EIA-455-203-2.
Measured with worst ER; BER<10
-12
; 2
31
– 1 PRBS.
Per IEEE 802.3ae.
V.
General Specifications
Parameter
Symbol
BR
BER
Min
9.95
Typ
Max
10.5
10
-12
Units
Gb/s
Ref.
1
2
Bit Rate
Bit Error Ratio
Maximum Supported Distances
Fiber Type
850nm OFL
Bandwidth
160 MHz-km
62.5µm
OM1
200 MHz-km
26
Lmax
33
m
Finisar Corporation - August 2015
Rev C1
Page 4
FTLX8573D3BTL Product Specification
400 MHz-km
OM2
500 MHz-km
OM3
2000 MHz-km
OM4
4700 MHz-km
Notes:
1. 10GBASE-SR/SW.
2. Tested with a 2
31
– 1 PRBS
66
82
Lmax
300
400
m
50µm
VI.
Environmental Specifications
Finisar 850nm SFP transceivers have a commercial operating temperature range from
-40°C to +85°C case temperature.
Parameter
Case Operating Temperature
Symbol
T
op
Min
-40
Typ
Max
85
85
Units
°C
°C
Ref.
1
Storage Temperature
T
sto
-40
Notes:
1. Warm-up time at -40°C case temperature is 45 seconds.
VII.
Regulatory Compliance
Finisar transceivers are Class 1 Laser Products and comply with US FDA regulations.
These products are certified by TÜV and CSA to meet the Class 1 eye safety
requirements of EN (IEC) 60825 and the electrical safety requirements of
EN (IEC) 60950. Copies of certificates are available at Finisar Corporation upon request.
Finisar Corporation - August 2015
Rev C1
Page 5
