CLM-DS01 LMR4 Rev 6e
Product family data sheet
Cree
®
LMR4 LED Module
with TrueWhite
®
Technology
Cree LED modules provide lighting designers and manufacturers with simple, easy-to-adopt LED lighting solutions that reduce fixture
development time and speed time-to-market. The Cree LED LMR4 module is the ideal choice for enabling rapid fixture development
where bright, beautiful, long-life lighting is required. The LMR series of modules incorporates Cree’s award-winning TrueWhite
®
Technology into a compact system of integrated driver electronics, optics, and primary thermal management for use in residential
and commercial lighting applications. This versatile LED lighting module jump-starts the design process for 5–6” (125–155 mm)
downlights, wall sconces, or pendant lights in demanding end markets such as retail, museums, hospitality and restaurants.
BEnEfiTs foR LuMinaiRE DEsignERs
•
•
•
•
•
Faster time-to-market and lower system cost with complete, compact,
light-source solution
Reduced development time with concurrently designed and tested
optics, driver electronics and primary thermal management
Wide variety of design applications enabled with 2700 K, 3000 K, 3500 K
and 4000 K correlated color temperatures
Industry-leading, 5-year limited warranty backed by patented, reliable
Cree LeD technology
Rapid regulatory approval and voluntary qualification of final luminaire
enabled by:
◊
UL
®
approval (120 V)
◊ California Title 24 compliance (120 V)
◊
LeD LM-80 data for US eNeRGY STAR
®
◊ Compliance with CE and other international standards (230 V)
BEnEfiTs foR EnD usERs
•
•
vibrant color rendering showcases the full beauty of people, rooms and
merchandise with > 90 CRI
Significant energy savings over traditional lighting through superior
efficacy
◊ > 70 lm/W (700 lm)
◊ > 67 lm/W (1000 lm)
Uniform, visually comfortable appearance whether powered on or off by
means of proprietary optics
Designed to last 35,000 hours at L
70
Consistent light quality over time and temperature delivered by built-in
optical management system
Dimming down to 5% of rated light output using standard incandescent
and electronic low-voltage dimmers
No Uv or mercury
34.50
38.00
79.45
•
•
•
•
WWW.CREE.Com/moDULES
•
Ø103.40
Tc LOCATION
THERMOCOUPLE
LOCATION
units: mm
114.00
Copyright © 2011-2016 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, the Cree logo and
TrueWhite
®
are registered trademarks and the Cree TrueWhite Technology logo is a trademark of Cree, Inc. ENERGY STAR
®
is a registered trademark of
the U.S. Environmental Protection Agency. UL
®
and the UR logo are registered trademarks of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
LMR4 LED MoDuLEs
ChaRaCTERisTiCs
Cree TrueWhite Technology is a revolutionary way of generating white light with LEDs. It delivers high efficiency with beautiful light
characteristics and color accuracy, while maintaining color consistency over the life of the product.
nominal
Luminous flux
(lm)
input
Power
(W)
9.5
9.5
9.5
9.5
15
15
15
15
Module
Efficacy
(lm/W)
74
74
74
74
67
67
67
67
input
Voltage (V)/
frequency
(hz)*
120/60
120/60
120/60
120/60
120/60
230/50
120/60
230/50
120/60
230/50
120/60
230/50
CCT
(K)
4000
CRi
> 90
> 90
> 90
> 90
> 90
> 90
> 90
> 90
Power
factor
> .80
> .80
> .80
> .80
> .95
> .90
> .95
> .90
> .95
> .90
> .95
> .90
Dimming
TRIAC
TRIAC
TRIAC
TRIAC
TRIAC
TRIAC
TRIAC
TRIAC
TRIAC
TRIAC
TRIAC
TRIAC
order Code
LMR040-0700-40F9-10100TW
LMR040-0700-35F9-10100TW
LMR040-0700-30F9-10100TW
LMR040-0700-27F9-10100TW
LMR040-1000-40F9-10100TW
LMR040-1000-40F9-20100TW
LMR040-1000-35F9-10100TW
LMR040-1000-35F9-20100TW
LMR040-1000-30F9-10100TW
LMR040-1000-30F9-20100TW
LMR040-1000-27F9-10100TW
LMR040-1000-27F9-20100TW
700
3500
3000
2700
4000
3500
1000
3000
2700
* Input ranges are 110–130 V/60–70 Hz and 220–240 V/50–60 Hz.
Note: Cree maintains a tolerance of +/- 7% on flux and power measurements.
ChRoMaTiCiTy
The Cree LMR4 LeD module provides high color consistency
around the specified color temperature. Individual LEDs are
tested and matched in order to meet our designed chromaticity
specification.
Secondary optics can be added to the module but will reduce light
output and may also alter the color characteristics of the final
luminaire design.
PhoToMETRy
90
90°
90
intensity (Candlepower)
angle
700 lm
Mean CP
365
362
340
300
245
184
124
71
37
27
0
ZonaL LuMEns – 700
1000 lm
Mean CP
491
476
441
395
318
244
159
90
46
33
0
100
100
300
0°
5°
200
200
45
45
15°
25°
35°
45°
55°
65°
75°
85°
90°
600
45°
300
300
ThERMaL ManagEMEnT guiDELinEs
The Cree LMR4 LeD module is designed to perform in a variety
of environments. To achieve lifetime and performance estimates,
and to maintain the warranty, the final luminaire design cannot
allow the module case temperature (Tc) point shown on page
one to exceed 70 °C when the fixture is at thermal equilibrium.
Follow the mechanical and thermal design guidelines listed in the
Cree
LMR4 LeD Module Design Guide
to ensure proper thermal
management.
operating Temperature
(at Tc point)
0-70 °C
900
400
400
500
500
1200
0
0°
0
37w
12 W
27w
15 W
Zone
Lumens
242
381
607
700
ZonaL LuMEns – 1000
%
35
55
87
100
700 lm
1000 lm
0-30°
0-40°
0-60°
0-90°
Zone
0-30°
0-40°
0-60°
0-90°
Lumens
255
451
817
1057
%
24
43
77
100
Copyright © 2011-2016 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, the Cree logo and TrueWhite
®
are registered trademarks and the Cree
TrueWhite Technology logo is a trademark of Cree, Inc. ENERGY STAR
®
is a registered trademark of the U.S. Environmental Protection Agency. UL
®
and the UR logo are registered trademarks of UL LLC.
2
