LCP-06014A-1
NOTICE
This publication is the proprietary of SHARP and is copyrighted, with all rights reserved. Under the copyright
laws, no part of this publication may be reproduced or transmitted in any form or by any means, electronic or
mechanical for any purpose, in whole or in part, without the express written permission of SHARP. Express
written permission is also required before any use of this publication may be made by a third party.
The application circuit examples in this publication are provided to explain the representative applications of
SHARP's devices and are not intended to guarantee any circuit design or permit any industrial property right or
other rights to be executed. SHARP takes no responsibility for any problems related to any industrial property
right or a third party resulting from the use of SHARP's devices, except for those resulting directly from device
manufacturing processes.
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that
occur in equipment using any of SHARP's devices, shown in catalogs, data books, etc. Contact SHARP in order to
obtain the latest device specification sheets before using any SHARP's device.
SHARP reserves the right to make changes in the specifications, characteristics, data, materials, structures and
other contents described herein at any time without notice in order to improve design or reliability. Contact SHARP
in order to obtain the latest specification sheets before using any SHARP's device. Manufacturing locations are also
subject to change without notice.
Observe the following points when using any device in this publication. SHARP takes no responsibility for
damage caused by improper use of the devices.
The devices in this publication are designed for use in general electronic equipment designs, such as:
•Personal computers
•Office automation
•Telecommunication equipment
•Personal digital assistant
•Test and measurement equipment
•Audio visual and multimedia equipment
•Industrial control
•Consumer electronics
The appropriate design measures should be taken to ensure reliability and safety when SHARP's devices are
used for equipment such as:
•Transportation control and safety equipment (i.e., aircraft, trains, automobiles, etc.)
•Traffic signals
•Alarm equipment
•Gas leakage sensor breakers
•Various safety devices etc.
SHARP's devices shall not be used for equipment that requires extremely high level of reliability, such as:
•Military and space applications
•Nuclear power control equipment
•Medical equipment for life support
Contact a SHARP representative, in advance, when intending to use SHARP's devices for any "specific"
applications other than those recommended by SHARP.
Contact and consult with a SHARP representative if there are any questions about the contents of this
publication.
LCP-06014A-2
(1) Application
This literature applies to LS037V7DW03.
(2) Overview
This module is a color transflective and active matrix LCD module incorporating CG-Silicon TFT
(Continuous Grain-Silicon Thin Film Transistor). It is composed of a color TFT-LCD panel, driver ICs
(with control Function), an FPC(with DC-DC Converter), a back light and a back sealed casing.
It is composed control circuit. Graphics and texts can be displayed on a 480×3×640 dots panel with
262,144 colors by supplying.
This LCD module has multi resolution and multi colors functions. A resolution mode is selective in
VGA (480H×640V) or QVGA (240H×320V). A Color mode is selective in 262,144 colors (18bit RGB) or
8 colors (3bit RGB).
It is a wide viewing-angle-mode (Vertical viewing angle:(±80°) Horizontal viewing angle: (±80°) ,CR≧5).
(3) Mechanical specifications
Table 1
Parameter
Screen size (Diagonal)
Display active area
Pixel format
Dot pitch
Pixel configuration
Display mode
Unit outline dimension
Mass
Specifications
9.4 [3.7”] Diagonal
56.16（H）×74.88（V）
480(H)×640(V)
(1 pixel = R+G+B dots)
0.039（H）×0.117（V）
R,G,B vertical stripe
Normally Black
65.0(W)×89.2(H)×3.6(D)
38
mm
½
【Note3-1】
Units
cm
mm
pixels
mm
Remarks
【Note
3-1】Excluding protrusion. For detailed measurements and tolerances, please refer to Fig. 1.
(4) Pixel configuration
(1,1)
(m,1)
RGB
1
LCD/LED
FPC
51
(1,n)
Display area
VGA mode
：m=480,n=640
QVGA mode：m=240,n=320
(m,n)
