REV.
DESCRIPTION
DATE
APPROVED
G
Engineering Release
H
Engineering Update w/o Changes
10/03/12
08/08/16
T. Y.
J. C.
VIEWING ANGLE AXIS 1
(CV-XPG4525DEG Lens Only)
0.08 [1.9mm]
0.375 [9.5mm]
Tc
R0.063 [R1.6mm]
0.34 [8.7mm]
0.050 [1.3mm]
0.100 [2.5mm]
0.783 [19.9mm]
0.156 [4.0mm]
0.106 [2.7mm]
0.100 [2.5mm]
0.050 [1.3mm]
SOLDER PADS
VIEWING ANGLE AXIS 2
(CV-XPG4525DEG Lens Only)
Part
Number
L2-PGC1-S
L2-PGC2-S
L2-PGC3-S
L2-PGN1-S
L2-PGN2-S
L2-PGN3-S
L2-PGW1-S
L2-PGW2-S
L2-PGW3-S
Table 1: Typical Characteristics without Additional Heat Sink
Typical Luminous Typical Luminous
Typical DC
Flux @ If =
Flux @ If =
CCT (K) CRI
Forward
350mA, Tc=70C 600mA, Tc=100C
Current, Vf (V)
(lm)
(lm)
6500
75
97
152
2.9 ~ 3.0
6500
6500
4100
4100
4100
3100
3100
3100
75
75
75
75
75
80
80
80
97
97
91
91
91
80
80
80
152
152
142
142
142
125
125
125
2.9 ~ 3.0
2.9 ~ 3.0
2.9 ~ 3.0
2.9 ~ 3.0
2.9 ~ 3.0
2.9 ~ 3.0
2.9 ~ 3.0
2.9 ~ 3.0
Viewing Angle,
Axis 1 / Axis2
(°)
85
35
45 / 25
85
35
45 / 25
85
35
45 / 25
Part
Number
L2-PGC1-S
L2-PGC2-S
L2-PGC3-S
L2-PGN1-S
L2-PGN2-S
L2-PGN3-S
L2-PGW1-S
L2-PGW2-S
L2-PGW3-S
Table 2: Absolute Maximum Ratings with Thermal Management
Typical Luminous Typical Luminous
Typical DC
Flux @ If =
Flux @ If =
CCT (K) CRI
Forward
1000mA, Tc=120C 1500mA, Tc=100C
Current, Vf (V)
(lm)
(lm)
6500
75
216
660
3.2 ~ 3.3
6500
6500
4100
4100
4100
3100
3100
3100
75
75
75
75
75
80
80
80
216
216
186
186
186
155
155
155
660
660
566
566
566
472
472
472
3.2 ~ 3.3
3.2 ~ 3.3
3.2 ~ 3.3
3.2 ~ 3.3
3.2 ~ 3.3
3.2 ~ 3.3
3.2 ~ 3.3
3.2 ~ 3.3
Viewing Angle,
Axis 1 / Axis2
(°)
85
35
45 / 25
85
35
45 / 25
85
35
45 / 25
®
STANDARD TOLERANCE
( UNLESS OTHERWISE SPECIFIED )
DECIMALS
ANGULAR
.X
.XX
.XXX
DESIGNED:
± .1
± .02
± .010
X°
± 1°
4 THOMAS, IRVINE, CA. 92618
TEL: (949) 951-8808
FAX: (949) 951-3974
TITLE:
DATE:
L2 Starboard Light Engine
REVISION:
PART NO:
B. Oliver
CHECKED:
11/02/11
DATE:
L2-PGXX-S
H
M. Chen
CAGE CODE : 32559
SHEET #
1
OF
1
11/02/11
CAD GENERATED DOCUMENT, DO NOT MEASURE DRAWING.
