Product Specification
OC-12 IR-1/STM S-4.1 RoHS Compliant Pluggable SFP Transceiver
FTLF1322P1xTR
PRODUCT FEATURES
•
•
•
•
•
•
•
•
•
•
Up to 622 Mb/s bi-directional
data links
Hot-pluggable SFP footprint
Built-in digital diagnostic functions
Uncooled Fabry-Perot 1310nm
laser transmitter
Duplex LC connector
RoHS compliant and lead-free
Metal enclosure, for lower EMI
Single 3.3V power supply
Low power dissipation <700mW
typical
Industrial operating temperature
range: -40°C to 85°C
APPLICATIONS
•
SONET OC-12 IR-1 / SDH STM S-4.1
•
SONET OC-12 SR / SDH STM I-4
•
SONET OC-3 IR-1 / SDH STM S-1.1
•
SONET OC-3 SR / SDH STM I-1
Finisar’s FTLF1322P1xTR Small Form Factor Pluggable (SFP) transceivers are
compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA)
1
.
They comply with SONET and SDH standards
2
at OC-12 IR-1/STM S-4.1 and OC-12
SR/STM I-4. In addition, they comply with SONET and SDH standards at OC-3 IR-1
/STM S-1.1 and OC-3 SR/STM I-1, as detailed in Finisar Application Note AN-2042.
Digital diagnostics functions are available via the 2-wire serial bus specified in the SFP
MSA. The optical transceiver is compliant per the RoHS Directive 2011/65/EU
3
. See
Finisar Application Note AN-2038 for more details
4
.
PRODUCT SELECTION
FTLF1322P1xTR
x
W
B
Wide Extraction Bail
Narrow Extraction Bail
Finisar Corporation August 2015
Rev. B1
Page 1
FTLF1322P1xTR Product Specification
I.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Pin Descriptions
Symbol
V
EET
T
FAULT
T
DIS
MOD_DEF(2)
MOD_DEF(1)
MOD_DEF(0)
Rate Select
LOS
V
EER
V
EER
V
EER
RD-
RD+
V
EER
V
CCR
V
CCT
V
EET
TD+
TD-
V
EET
Name/Description
Transmitter Ground (Common with Receiver Ground)
Transmitter Fault. Not supported.
Transmitter Disable. Laser output disabled on high or open.
Module Definition 2. Data line for Serial ID.
Module Definition 1. Clock line for Serial ID.
Module Definition 0. Grounded within the module.
No connection required
Loss of Signal indication. Logic 0 indicates normal operation.
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Inverted DATA out. AC Coupled.
Receiver Non-inverted DATA out. AC Coupled.
Receiver Ground (Common with Transmitter Ground)
Receiver Power Supply
Transmitter Power Supply
Transmitter Ground (Common with Receiver Ground)
Transmitter Non-Inverted DATA in. AC Coupled.
Transmitter Inverted DATA in. AC Coupled.
Transmitter Ground (Common with Receiver Ground)
Ref.
1
2
3
3
3
4
5
1
1
1
1
1
1
Notes:
1. Circuit ground is internally isolated from chassis ground.
2. Laser output disabled on T
DIS
>2.0V or open, enabled on T
DIS
<0.8V.
3. Should be pulled up with 4.7k - 10kohms on host board to a voltage between 2.0V and 3.5V.
MOD_DEF(0) pulls line low to indicate module is plugged in.
4. Finisar FTLF1322xxxxx transceivers operate without active control.
5. LOS is open collector output. Should be pulled up with 4.7k - 10kohms on host board to a voltage
between 2.0V and 3.5V. Logic 0 indicates normal operation; logic 1 indicates loss of signal.
VeeT
1
2
3
4
VeeT
TD-
TXFault
TD+
TX Disable
VeeT
MOD-DEF(2)
VccT
20
19
18
17
16
15
14
13
12
11
Towards
Bezel
5
6
7
8
9
10
MOD-DEF(1)
VccR
MOD-DEF(0)
VeeR
Rate Select
RD+
LOS
RD-
VeeR
VeeR
VeeR
Towards
ASIC
Pinout of Connector Block on Host Board
Finisar Corporation August 2015
Rev. B1
Page 2
FTLF1322P1xTR Product Specification
II.
Absolute Maximum Ratings
Parameter
Maximum Supply Voltage
Storage Temperature
Case Operating Temperature
Relative Humidity
Symbol
Vcc
T
S
T
OP
RH
Min
-0.5
-40
-40
0
Typ
Max
4.5
100
85
85
Unit
V
°C
°C
%
Ref.
1
III.
Electrical Characteristics
(T
OP
= -40 to 85
°C,
V
CC
= 3.10 to 3.50 Volts)
Symbol
Vcc
Icc
R
in
Vin,pp
V
D
V
EN
Min
3.10
Typ
165
100
250
Vcc – 1.3
Vee
1200
Vcc
Vee+ 0.8
10
400
150
800
300
Vcc
HOST
Vee+0.5
Max
3.50
300
Unit
V
mA
Ω
mV
V
V
µs
mV
ps
V
V
mVpp
Ref.
Parameter
Supply Voltage
Supply Current
Transmitter
Input differential impedance
Single ended data input swing
Transmit Disable Voltage
Transmit Enable Voltage
Transmit Disable Assert Time
Receiver
Single ended data output swing
Data rise/fall time @ OC-12
LOS Fault
LOS Normal
Power Supply Rejection
2
3
Vout,pp
t
r
V
LOS fault
V
LOS norm
PSR
300
Vcc – 0.5
Vee
100
4
5
6
6
7
Notes:
1. Non condensing.
2. AC coupled.
3. Or open circuit.
4. Into 100 ohm differential termination.
5. 20 – 80 %
6. Loss Of Signal is LVTTL. Logic 0 indicates normal operation; logic 1 indicates no signal detected.
7.
All transceiver specifications are compliant with a power supply sinusoidal modulation of 20 Hz to 1.5
MHz up to specified value applied through the power supply filtering network shown on page 23 of the
Small Form-factor Pluggable (SFP) Transceiver MultiSource Agreement (MSA), September 14, 2000.
Finisar Corporation August 2015
Rev. B1
Page 3
FTLF1322P1xTR Product Specification
IV.
Optical Characteristics
(T
OP
= -40 to 85
°C,
V
CC
= 3.10 to 3.50 Volts)
Parameter
Transmitter
Output Opt. Pwr: 9/125 SMF
Optical Wavelength
Spectral Width
Optical Extinction Ratio
Optical Rise/Fall Time @ OC-12
Relative Intensity Noise
Generated Jitter (peak to peak)
Generated Jitter (rms)
Mask Margin
Receiver
Average Rx Sensitivity @ OC-12
Average Rx Sensitivity @ OC-3
Optical Center Wavelength
LOS De-Assert
LOS Assert
LOS Hysteresis
Symbol
P
OUT
λ
σ
ER
t
r
/ t
f
RIN
J
TX
p-p
J
TX
rms
Min
-15
1274
8.2
Typ
Max
-8
1356
2.5
300
-120
0.07
0.007
Unit
dBm
nm
nm
dB
ps
dB/Hz
UI
UI
Ref.
1
2
3
3
20%
R
SENS1
R
SENS2
λ
C
LOS
D
LOS
A
-28
-28
1260
-45
0.5
-8
-8
1600
-28
dBm
dBm
nm
dBm
dBm
dB
4
4
5
Notes:
1. Class 1 Laser Safety per FDA/CDRH and EN (IEC) 60825 regulations.
2. Unfiltered, 20-80%
3. Jitter measurements taken using Agilent OMNIBERT 718 in accordance with GR-253.
4. With worst-case extinction ratio. Measured with a PRBS 2
23
-1 test pattern.
5. At 622 Mb/s only.
Finisar Corporation August 2015
Rev. B1
Page 4
FTLF1322P1xTR Product Specification
V.
General Specifications
Parameter
Symbol
BR
BER
L
MAX4
Min
155
Typ
Max
622
10
-12
Units
Ref.
Mb/sec 1
2
km
3
Data Rate
Bit Error Rate
Max. Supported Link Length on
9/125µm SMF @ OC-12
15
Notes:
1. Compliant with SONET and SDH standards at OC-12 IR-1/STM S-4.1 and OC-12 SR/STM I-4. In
addition, they comply with SONET and SDH standards at OC-3 IR-1 /STM S-1.1 and OC-3 SR/STM
I-1, as detailed in Finisar Application Note AN-2042.
2. Tested with a PRBS 2
23
-1 test pattern.
3.
Attenuation of 0.55 dB/km is used for the link length calculations (per GR-253 CORE). Distances are
indicative only. Please refer to the Optical Specifications in Table IV to calculate a more accurate link
budget based on specific conditions in your application.
VI.
Environmental Specifications
Finisar 1310nm SFP transceivers have an industrial operating temperature range from
–40°C to +85°C case temperature.
Parameter
Case Operating Temperature
Storage Temperature
Symbol
T
op
T
sto
Min
-40
-40
Typ
Max
85
100
Units
°C
°C
Ref.
VII.
Regulatory Compliance
Finisar transceivers are Class 1 Laser Products and comply with US FDA regulations.
These products are certified by TÜV and CSA to meet the Class 1 eye safety
requirements of EN (IEC) 60825 and the electrical safety requirements of
EN (IEC) 60950. Copies of certificates are available at Finisar Corporation upon request.
Finisar Corporation August 2015
Rev. B1
Page 5
