REV
ECN NO
REVISIONS
NEW RELEASE
DRN CKD APP
DATE
NOTES:
A
TWC
KLJ
TC N.O. 9-22-05
NO
NO
MES 2-15-08
MES 2-29-12
CATHODE
MARKING
.114
[2.90]
.149/.134
[3.80/3.40]
.165/.149
[4.20/3.80]
.094
[2.4]
1. COLORLESS CLEAR WINDOW.
2. LED CHIP: InGaAlP
3. LED LEAD FINISH: PURE MATT TIN (Sn) 8.0
2.0 m WITH NICKEL (Ni)
UNDERLAYER OVER COPPER (Cu).
4. DIALIGHT PART NUMBERS: 597-2001-202F, -213F
597-2301-202F, -213F
597-2401-202F, -213F.
5. PACKAGING:
-202F SUFFIX INDICATES 20 PCS SAMPLE STRIP
-213F SUFFIX INDICATES 2000 PARTS/REEL ON 13" [330 mm] DIA. REEL
6. REEL AND PACKAGING HAS A LABEL WITH DIALIGHT LOGO, DIALIGHT P/N,
QTY PER REEL, DATE CODE, LOT NUMBER, INTENSITY BIN CODE, COLOR BIN
CODE, AND COUNTRY OF ORIGIN.
7. THIS ASSEMBLY CONTAINS ELECTROSTATIC DISCHARGE SENSITIVE DEVICES
(ESDS). MAINTAIN ALL PRECAUTIONARY MEASURES DURING ASSEMBLY,
HANDLING, AND STORAGE IN ACCORDANCE WITH IPC-A-610.
B
C
UPDATED LED SPECS, ADDED
RoHS COMPLIANT NOTE, ADDED
ESD NOTE AND SYMBOL.
UPDATE LED INT (3.55 & 42) WAS
JTD
(2.24 &37) FOR 5972301213F,202F
REEL SPROCKET HOLES
.165/.149
[4.2/3.8]
.028
[0.70]
CATHODE MARKING
.472
[12.0]
.110/.094
[2.8/2.4]
ANODE
CATHODE
.100
[2.54]
.043/.035
[1.10/0.90]
.112
[2.85]
.315
8mm
PITCH
BI-COLOR OPERATING CHARACTERISTICS AT T
DIALIGHT
P/N
FORWARD
VOLTAGE (V)
@ I
F
= 10 mA
MIN.
TYP.
MAX.
LUMINOUS
INTENSITY (mcd)
@ I
F
= 2 mA
MIN.
TYP.
7.8
5.6
14.0
A
= 25
C AMBIENT
PEAK
WAVELENGTH
(nm)
TYP.
643
572
591
DOMINANT
WAVELENGTH
(nm)
MIN. TYP. MAX.
624
566
580
630
570
587
636
575
595
120
120
120
VIEWING
ANGLE
(2
q
1/2)
COLOR
LUMINOUS
INTENSITY (mcd)
@ I
F
= 10 mA
MIN.
20
10
25
TYP.
40
42
70
.112
[2.85]
MAX.
MAX.
60
50
115
SOLDER TERMINALS
597-2001-213F, -202F
597-2301-213F, -202F
597-2401-213F, -202F
RED
GREEN
YELLOW
1.7
1.7
1.7
1.8
1.8
1.8
2.2
2.2
2.2
4.5
3.55
5.6
11.2
9.0
22.4
.043/.035
[1.10/0.90]
ABSOLUTE MAXIMUM RATINGS AT 25 C AMBIENT
.146
[3,7]
.047
[1,2]
UNITS
mW
mA
mA
V
C
C
C
RED
45
GREEN YELLOW
40
20
100
12
260
-40 TO +100
-40 TO +100
THIS DRAWING AND THE CONTENTS HEREIN ARE CONFIDENTIAL AND
THE SOLE PROPERTY OF DIALIGHT. REPRODUCTION OF THIS DRAWING
OR CONSTRUCTION OF ANY PARTS WITHIN THIS DRAWING ARE
FORBIDDEN WITHOUT THE WRITTEN CONSENT OF DIALIGHT.
SCALE: DRAWING SCALE
ALL DIM'S IN: INCHES (MM)
TOLERANCES:
UNLESS OTHERWISE SPECIFIED
POWER DISSIPATION
CONTINUOUS FORWARD CURRENT
PEAK FORWARD CURRENT t
REVERSE VOLTAGE
P
45
.146
[3,7]
.047
[1,2]
< 10 µS, D=.005
@ 10 µA
SOLDERING TEMPERATURE, 10 SEC.
OPERATING TEMPERATURE
.118
[3]
.118
[3]
STORAGE TEMPERATURE
DRAWING NUMBER
REV
C-17300
TITLE
MATERIAL
C
RoHS COMPLIANT 597-2X01-2XXF
RECOMMENDED PAD LAYOUT
SOLDER
RESIST
Cu AREA > 16mm
2
RECOMMENDED PAD LAYOUT
FOR IMPROVED HEAT DISSIPATION
Part Numbers with the "F" suffix ending are RoHS Compliant.
For example: 597-2401-207F
Reel and bag packaging are marked with "RoHS Compliant" label or
equivalent markings. These parts can be used with RoHS reflow profile.
Parts can be wave soldered, dip soldered or hand soldered using typical
lead-free soldering process with max 260°C temp. for 10 sec.
FRACTIONS:
1/64
DECIMALS (.XX):
.01
DECIMALS (.XXX):
.005
DECIMALS (.XXXX):
.0005
ANGLES:
1
SMT-SIDELED
RoHS COMPLIANT
FINISH:
1501 ROUTE 34 SOUTH
FARMINGDALE, NJ 07727
FSCM
83330
SHEET
1
OF
1
