Product Specification
OC-48 LR-1/STM L-16.1 RoHS Compliant Pluggable SFP Transceiver
FTLF1721P1xCL
PRODUCT FEATURES
•
•
•
•
•
•
•
•
•
•
•
Up to 2.67Gb/s bi-directional
data links
Hot-pluggable SFP footprint
Built-in digital diagnostic functions
Uncooled 1310nm DFB laser
transmitter
APD Receiver
Duplex LC connector
RoHS Compliant
Metal enclosure, for lower EMI
Single 3.3V power supply
Low power dissipation typically
<700mW
Extended operating temperature
range: -10°C to 70°C
APPLICATIONS
•
•
•
•
SONET OC-48 LR-1 / SDH STM L-16.1
SONET OC-12 / SDH STM 4
SONET OC-3 / SDH STM-1
Gigabit Ethernet / 1x/2x Fibre Channel
Finisar’s FTLF1721P1xCL Small Form Factor Pluggable (SFP) transceivers are
compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA)
1
.
They comply with SONET OC-48 LR-1 (SDH STM L-16.1) standards
2
, Gigabit Ethernet
as specified in IEEE Std 802.3
3(*)
and Fibre Channel FC-PI 13.0
4(*)
. They are compatible
with SONET OC-12 SR and SONET OC-3 standards
2
. Digital diagnostics functions are
available via the 2-wire serial bus specified in the SFP MSA. The optical transceivers are
compliant per the RoHS Directive 2011/65/EU. See Finisar Application Note AN-2038
for more details.
PRODUCT SELECTION
FTLF1721P1xCL
x
W
B
Wide Extraction Bail
Narrow Extraction Bail
Finisar Corporation July 2015 Rev B1
Page 1
Finisar Corporation July 2015 Rev B1
Page 2
FTLF1721P1xCL Pluggable SFP Product Specification
I.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Pin Descriptions
Symbol
V
EET
T
FAULT
T
DIS
MOD_DEF(2)
MOD_DEF(1)
MOD_DEF(0)
Rate Select
LOS
V
EER
V
EER
V
EER
RD-
RD+
V
EER
V
CCR
V
CCT
V
EET
TD+
TD-
V
EET
Name/Description
Transmitter Ground (Common with Receiver Ground)
Transmitter Fault.
Transmitter Disable. Laser output disabled on high or open.
Module Definition 2. Data line for Serial ID.
Module Definition 1. Clock line for Serial ID.
Module Definition 0. Grounded within the module.
No connection required
Loss of Signal indication. Logic 0 indicates normal operation.
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Inverted DATA out. AC Coupled
Receiver Non-inverted DATA out. AC Coupled
Receiver Ground (Common with Transmitter Ground)
Receiver Power Supply
Transmitter Power Supply
Transmitter Ground (Common with Receiver Ground)
Transmitter Non-Inverted DATA in. AC Coupled.
Transmitter Inverted DATA in. AC Coupled.
Transmitter Ground (Common with Receiver Ground)
Ref.
1
2
3
3
3
4
5
1
1
1
1
1
1
Notes:
1. Circuit ground is internally isolated from chassis ground.
2. Laser output disabled on T
DIS
>2.0V or open, enabled on T
DIS
<0.8V.
3. Should be pulled up with 4.7k – 10kohms on host board to a voltage between 2.0V and 3.6V.
MOD_DEF(0) pulls line low to indicate module is plugged in.
4. Finisar FTLFxx21xxxxx transceivers operate between OC-3 and OC-48, 1x and 2x Fibre Channel, and
Gigabit Ethernet data rates and respective protocols without active control. Finisar FTRJxx19xxxxx
transceivers operate at 1x and 2x Fibre Channel, and Gigabit Ethernet data rates and respective
protocols without active control.
5. LOS is open collector output. Should be pulled up with 4.7k – 10kohms on host board to a voltage
between 2.0V and 3.6V. Logic 0 indicates normal operation; logic 1 indicates loss of signal.
VeeT
1
2
3
4
VeeT
TD-
TXFault
TD+
TX Disable
VeeT
MOD-DEF(2)
VccT
20
19
18
17
16
15
14
13
12
11
Towards
Bezel
5
6
7
8
9
10
MOD-DEF(1)
VccR
MOD-DEF(0)
VeeR
Rate Select
RD+
LOS
RD-
VeeR
VeeR
VeeR
Towards
ASIC
Diagram of Connector Block Pinout on the Host Board
Finisar Corporation July 2015 Rev B1
Page 3
FTLF1721P1xCL Pluggable SFP Product Specification
II.
Absolute Maximum Ratings
Parameter
Maximum Supply Voltage
Storage Temperature
Case Operating Temperature
Symbol
Vcc
T
S
T
OP
Min
-0.5
-40
-10
Typ
Max
4.5
85
70
Unit
V
°C
°C
Ref.
III.
Electrical Characteristics
(T
OP
= -10 to 70
°C,
V
CC
= 3.00 to 3.60 Volts)
Symbol
Vcc
Icc
R
in
Vin,pp
V
D
V
EN
Min
3.00
Typ
230
100
250
Vcc – 1.3
Vee
1200
Vcc
Vee+ 0.8
10
400
100
100
800
175
175
Vcc
HOST
Vee+0.5
0.07
0.007
Max
3.60
300
Unit
V
mA
Ω
mV
V
V
us
mV
ps
ps
V
V
mVpp
UI
UI
Ref.
Parameter
Supply Voltage
Supply Current
Transmitter
Input differential impedance
Single ended data input swing
Transmit Disable Voltage
Transmit Enable Voltage
Transmit Disable Assert Time
Receiver
Single ended data output swing
Data output rise time
Data output fall time
LOS Fault
LOS Normal
Power Supply Rejection
Total Generated Reciever Jitter
(peak to peak)
Total Generated Reciever Jitter
(rms)
1
2
Vout,pp
t
r
t
f
V
LOS fault
V
LOS norm
PSR
J
RX
p-p
J
RX
rms
300
Vcc – 0.5
Vee
100
3
4
4
5
5
6
Notes:
1. AC coupled
2. Or open circuit.
3. Into 100 ohms differential termination.
4. 10 – 90 %
5. Loss Of Signal is LVTTL. Logic 0 indicates normal operation; logic 1 indicates no signal detected.
6. All transceiver specifications are compliant with a power supply sinusoidal modulation of 20 Hz to 1.5
MHz up to specified value applied through the power supply filtering network shown on page 23 of the
Small Form-factor Pluggable (SFP) Transceiver MultiSource Agreement (MSA), September 14, 2000.
Finisar Corporation July 2015 Rev B1
Page 4
FTLF1721P1xCL Pluggable SFP Product Specification
IV.
Optical Characteristics
(T
OP
= -10 to 70°C, V
CC
= 3.00 to 3.60 Volts)
Symbol
P
OUT
λ
σ
ER
SSR
min
t
r
/ t
f
J
TX
p-p
J
TX
rms
Min
-2
1280
9
30
160
0.07
0.007
Typ
Max
+3
1335
1
Unit
dBm
nm
nm
dB
dB
ps
UI
UI
Ref.
1
2
Parameter
Transmitter
Output Opt. Pwr: 9/125 SMF
Optical Wavelength
Spectral Width (-20dB)
Optical Extinction Ratio
Sidemode Supression ratio
Optical Rise/Fall Time
Total Generated Transmitter Jitter
(peak to peak)
Total Generated Transmitter Jitter
(rms)
Receiver
Average Rx Sensitivity @ 2.67Gb/s
Average Rx Sensitivity @ OC-48
Average Rx Sensitivity @ 2X Fibre
Channel
Average Rx Sensitivity @ Gigabit
Ethernet
Average Rx Sensitivity @ OC-12
Average Rx Sensitivity @ OC-3
Maximum Input Power
Optical Center Wavelength
LOS De-Assert
LOS Assert
LOS Hysteresis
3
R
SENS1
R
SENS1
R
SENS2
R
SENS3
R
SENS4
R
SENS5
P
MAX
λ
C
LOS
D
LOS
A
-27
-27
-28
-30
-29
-30
1600
-28
dBm
dBm
dBm
dBm
dBm
dBm
dBm
nm
dBm
dBm
dB
3
3
4
4
5
5
-15
-9
1270
-41
0.5
Notes:
1. Class 1 Laser Safety per FDA/CDRH and IEC-825-1 regulations.
2. Unfiltered
3. With worst-case extinction ratio. Measured with a PRBS 2
31
-1 test pattern interspersed with 72
consecutive ones and 72 consecutive zeros.
4. With worst-case extinction ratio. Measured with a PRBS 2
7
-1 test pattern.
5. With worst-case extinction ratio. Measured with a PRBS 2
23
-1 test pattern.
Finisar Corporation July 2015 Rev B1
Page 5
