Application
Dialight’s 558 series LED panel mount indicator is available with a variety of
LEDs including AlInGaP and InGaN technology for high brightness appli-
cations, bicolor and integral resistors. These indicators are designed for a
variety of applications such as:
•
Fan tray assemblies
•
Datacenter Infrastructure (Servers and Storage)
•
Networking Equipment (Switches and routers)
•
Storage Networking Hardware (Fibre channel host bus adapter cards)
•
Next-Gen Wireless Infrastructure
•
Electronic Test & Measurement Instruments
•
Communications Testing Equipment
•
Process controls
•
Automation
•
Medical Equipment
•
Handheld devices
558 Series
Snap-in LED - .156” Mounting Hole
Panel Mount Indicators
.3mm LED
.190
(4.83)
“A” + .015
“A” + .015
“B”+ .020
“B”+ .020
HOUSING
(VALOX)
.190
(4.83)
Mechanical Information
Mounting Hole Size:
Max Panel Thickness:
0.155 - 0.158” (3.94 - 4.01 mm)
0.031 - 0.062” (.787 - 1.57 mm)
Electrical specifications
Operating Voltage:
1.8 - 3.3 VDC typical (current limiting resistor
required)
5 VDC typical (resistor not required)
See table
(-67°F to +212°F) -55°C to +100°C
Straight terminals for wire wrapping or either
6 or 14 inch 26 AWG lead wire
Straight leads
2 leads
.125
(3.17)
REF.
“C” MIN
SEE NOTE 4
ANODE
LEAD
.040
(1.01)
MIN
CATHODE
LEAD
PIN 2
.500 + .032
(12.7 + 0.81)
RED
WIRE
BLACK
WIRE
Operating Temp:
Storage Temp:
Electrical connection:
PIN 1
.020
(.51)
SQ. TYP
NOM
.100 + .015
(2.54+ 0.38)
Leads:
PIN 2
ANODE
(+)
SINGLE COLOR LED SCHEMATIC
PIN 1
CATHODE
(-)
PIN 2
GREEN
CATHODE
PIN 1
RED CATHODE
FOR R/G LED
YELLOW CATHODE
FOR Y/G LED
Construction
Housing:
Black housing material meets:
UL94V-0 and enhances LED contrast
BI-COLOR LED SCHEMATIC
Dimensions in inches [mm]
Features & Benefits
•
RoHS compliant
•
Long life - typically 100K hours
•
Low power consumption - uses up to 90% less energy
than an incandescent indicator
•
Front panel snap-in mounting requires no additional hardware
•
No heat generated
•
Resistant to shock and vibration
•
Termination - straight terminals for wire wrapping or
lead wire for soldering or optional terminals
•
Available with PVC-free lead wires
www.dialight.com
•
Dialight HQ (P) 732-919-3119
558 Series
Snap-in LED - .156” Mounting Hole
•
Panel Mount Indicators
558-XXXX -0 X X F
LED Code
RoHS Compliant
Wire Code
Termination
Code
Wire
Code
0
2
Termination Code
1
Standard
PVC Free
3
7
Termination Type
Straight Terminals
24 AWG 6" wire leads
24 AWG 14" wire leads
Wire Type
LED
Code
0102
0202
0302
3001
3101
3201
0101
0201
0301
0401
1801
0803
1101
1201
1301
0501
0601
0701
6003
6403
1501
1601
1701
6203
Color
Red
Green
Yellow
Red/Green
Red/Green
Yellow/
Green
Red
Green
Yellow
Orange
Red
Blue
Red
Yellow
Green
Green
Yellow
Red
Blue
White
Green
Yellow
Red
Green
Peak
Wavelength
(nm)
635
565
585
630/565
660 / 565
585 / 565
650
563
585
600
Intensity
Typ.
(mcd)
29
19
12.6
5.6/8.7
@10mA
12.6 / 3.7
5.8/12.3
10
16
16
7
60
57
2.3
1.4
1.6
70
200
170
520
3000
40
70
170
270
If Typ.
(mA)
12
12
12
10/20
20
10
10
10
10
10
20
10
2
2
2
20
20
20
20
20
10
20
20
10
Vf Typ.
(V)
5
5
5
1.9/2.0
@20mA
1.8 / 2.1
2.1 / 2.1
2
2.1
2.1
1.9
1.8
3.2
1.7
1.8
1.9
2.1
1.9
1.8
3.3
3.3
2.1
2.1
1.8
3
Viewing
Angle
60
60
60
200
200
80
40
40
40
60
60
100
60
60
60
45
45
45
45
45
45
45
45
100
Max DC
Forward
Current
(mA)
7.5 Vf
7.5 Vf
7.5 Vf
30 / 30
40 / 30
20 / 30
20
25
20
25
40
30
7
7
7
30
50
40
30
30
30
20
40
30
Type
5V Integral Resistor
5V Integral Resistor
5V Integral Resistor
Bi-Color
Bi-Color
Bi-Color
High Efficiency Diffused
High Efficiency Diffused
High Efficiency Diffused
High Efficiency Diffused
High Efficiency Diffused
High Efficiency Diffused
Low Current Diffused
Low Current Diffused
Low Current Diffused
Non-Tinted/Non-Diffused
Non-Tinted/Non-Diffused
Non-Tinted/Non-Diffused
Non-Tinted/Non-Diffused
Non-Tinted/Non-Diffused
Tinted/Non-Diffused
Tinted/Non-Diffused
Tinted/Non-Diffused
White Diffused
Operating Temp
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
-55°C to +100°C
-55°C to +100°C
-55°C to +100°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-55°C to +100°C
-40°C to +100°C
-40°C to +85°C
-55°C to +100°C
-40°C to +100°C
-55°C to +100°C
-55°C to +100°C
-40°C to +100°C
-40°C to +100°C
-40°C to +85°C
-40°C to +85°C
-55°C to +100°C
-55°C to +100°C
-40°C to +100°C
-45°C to +85°C
DIM
"A"
0.101
0.101
0.101
0.101
0.101
0.101
0.111
0.111
0.111
0.101
0.101
0.107
0.101
0.101
0.101
0.101
0.101
0.101
0.101
0.101
0.101
0.101
0.101
0.101
DIM
"B"
0.381
0.381
0.381
0.381
0.381
0.381
0.391
0.391
0.391
0.381
0.381
0.387
0.381
0.381
0.381
0.381
0.381
0.381
0.381
0.381
0.381
0.381
0.381
0.381
660
468
635
585
565
565
592
660
468
X=.31
Y=.32
565
585
660
518
Dialight reserves the right to make changes at any time in order to supply the best product possible. The most current version of this document will always be available at:
www.dialight.com/Assets/Brochures_And_Catalogs/Illumination/M DEL 5 58 C X0 0 1 .pdf. Warranty Statement: EXCEPT FOR THE WARRANTY EXPRESSLY PROVIDED FOR [HEREIN/ABOVE/BELOW], DIALIGHT DISCLAIMS
ANY AND ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND NON-INFRINGEMENT.
www.dialight.com
•
Dialight HQ (P) 732-919-3119
M D EL 558 CX 00 1_ C
