CAPABILITY OVERVIEW
RESISTIVE TOUCH PANELS
FUJITSU, TOUCH PANELS
simple solutions in a complex world
Fujitsu Touch Panels
Fujitsu is a one of the leading touch panel manufacturers. Our
production process is based on the best choice of industry
materials, achieving an outstanding optical and mechanical
performance.
We have developed a wide range of touch panels to fit many
applications for various operating environments. We can
supply touch panels suitable for heavy industrial environment,
computing or the POS world. For mobile phones and PDAs we
can offer panels that are shock resistant with various
thicknesses, which are important factors when designing
mobile applications. Fujitsu also manufactures panels that can
withstand high temperatures, suitable for automotive
applications.
Fujitsu offers all of their resistive touch panel products in
RoHS-compliant versions.
The Benefits
Fujitsu touch panels offer various major advantages:
•
High optical quality
- Standard transparency 80% to 82%
- Anti-Glare coating standard
- Anti-Newton ring technology
- Micro dot spacer almost invisible
•
High mechanical quality
- Sealed construction preventing dirt and dust entering the
panel
- Hard top coating preventing scratches
•
Customization options
- All sizes from 2 to 17 inch
- Anti-Reflective coating for 87% and 92% transparency
- Clear coating
- Chemically strengthened glass
- Thick glass for shock resistance
- Linear polarizer for sunlight readability
- Anti-Smudge coating allowing easy cleaning and avoiding
fingerprints on the screen
Fujitsu touch panels feature:
•
High operating temperature for automotive
•
Film/Glass and Film/Film/Glass
•
Transparency up to 92%
•
Various coatings
•
Polarizer options for sunlight readability
•
Anti-Newton ring technology
•
Pen and finger input
•
Sizes up to 17 inch
Page 1 of 04
CAPABILITY OVERVIEW
RESISTIVE TOUCH PANELS
Select The Touch Panel Type That Fits Your Needs
OVERVIEW OF TOUCH PANEL TYPES
Material
Film/Glass
Wires
7-wire
Description
Long life time
Auto-calibration
Little aging
Little temperature drift
Industry standard
High temperature range
Unbreakable
Protecting the LCD screen
Pen / finger
Pen & finger
Life time
10 Million touches
Size
5 - 17”
Transparency
80% standard
90% max.
Film/Glass
Film/Glass
automotive
Film/Film/Plastic
4-wire
4-wire
4-wire
Pen & finger
Finger
Pen & finger
1 Million touches
1 Million touches
1 Million touches
2 - 17”
3.5 - 8”
1 - 7”
80% standard
92% max.
80% standard
77% standard
85% max.
All touch panels can be offered with customized sizes and optical options to fit customers’ requirements. For those looking for
small quantitites or fast development Fujitsu can offer a selection of standard touch panels that can be ordered from the shelf.
Furthermore controller boards and drivers are available making integration easier.
CHARACTERISTICS 7-WIRE & 4-WIRE TOUCH PANELS, FILM/GLASS
Item
Optical
Mechanical
Description
Transparency
Haze
Hardness
Linearity
Writing life
Knocking life
Power supply
Resolution
Sampling
Transmission rate
Consumption
Insulation resistance
Operation temperature
Storage temperature
Operating humidity
Storage humidity
7-wire (550 SERIES)
80% - 82%
5% typical
3 H min
1.5% to 3.5%
1 million
10 million
+5 V or 3.3 VDC
0.1 mm (0.004 in)
192 pps (variable)
9,600 bps
20 mA max.
10M Ohm
-5
o
C - +60
o
C
-30
o
C - +70
o
C
20% - 90%
10% - 90%
4-wire (554 SERIES)
80% - 82%
5% typical
3 H min
1.5% to 3.5%
100,000 words
1 million words
+5 V or 3.3 VDC
0.1 mm (0.004 in)
192 pps (variable)
9,600 bps
20 mA max.
10M Ohm
-2
o
C - +55
o
C
-20
o
C - +70
o
C
20% - 85%
10% - 90%
Electrical
Environmental
7-Wire Touch Panels, Film/Glass
Fujitsu’s 7-wire touch panels are available from 5 to 17 inch. Our 7-wire touch panels can handle up to 10 million plus touches
with an operating temperature of -5
o
C to +60
o
C and storage from -30
o
C to +70
o
C. This unique technology has been
developed especially for high demanding applications such as heavy industry, or car diagnostics tools. It combines the
advantages of the 5- and 8-wire technologies: the resistance to a higher number of input and compensation of temperature
and aging drift. Even when the top layer would be cut, our 7-wire touch panel still functions. The panels have the same high
optical quality as our 4-wire touch panels, standard sizes are 8.4, 10.4, 12.1, 15 and 17 inch.
7-WIRE SERIES, FILM/GLASS
Glass
1.8 mm
Part number
N010-0551-T642
N010-0551-T253
N010-0510-T236
N010-0510-T303
N010-0550-T345
N010-0550-T627
N010-0551-T255
N010-0510-T216
Size
10.4”
12.1”
15.0”
17.0”
8.4”
10.4”
12.1”
15.0”
FPC tail
100 mm
100 mm
100 mm
220 mm
46 mm
100 mm
100 mm
100 mm
Input
Pen & finger,
Pen & finger,
Pen & finger
Pen & finger
Pen & finger
Pen & finger,
Pen & finger,
Pen & finger
light touch
light touch
Control board:
- N16B-0558-B280 (Serial)
-
N16B-0558-B740 (USB)
Control chip:
- N010-0559-V026 (Serial)
- NC41120-0017 (USB)
(PS2 optional)
1.1 mm
light touch
light touch
Page 2 of 04
4-Wire Touch Panels, Film/Glass
Fujitsu’s 4-wire touch panels are available from 2 to 17 inch and can handle up to 1 million touches with an operating
temperature of -2
o
C to +55
o
C and storage from -30
o
C to +70
o
C. The 4-wire technology comes in a standard version with
anti-scratch hard-top coating, an anti-glare finish avoiding the mirror effect. The standard transparency for these touch panels
is 82%. The technology used allows pen and finger input making the touch panels suitable for PDA’s, cash registers and many
other applications.
4-WIRE SERIES, FILM/GLASS
Glass
0.7 mm
1.1 mm
Part number
N010-0554-T703
N010-0554-T504
N010-0554-T009
N010-0555-T043
N010-0555-T943
N010-0554-T347
N010-0554-T805
N010-0554-T902
Size
3.8”
8.4”
5.7”
6.4”
7.9”
10.4”
12.1”
15.0”
FPC tail
21 mm
75 mm
50 mm
61 mm
61 mm
75 mm
75 mm
61 mm
Input
Pen &
Pen &
Pen &
Pen &
Pen &
Pen &
Pen &
Pen &
finger
finger
finger
finger
finger
finger
finger
finger
Control board:
- N16B-0558-B270 (Serial)
-
N16B-0558-B730 (USB)
Control chip:
- N010-0559-V036 (Serial)
- NC41120-0018 (USB)
(PS2 optional)
Automotive 4-Wire Touch Panels, Film/Glass
The automotive film/glass touch panels are available from 3.5 to 8 inch, they can handle 1 million finger touches (not made
for intensive pen application) and have a high operating temperature range of -30
o
C to +85
o
C, the storage temperature range
is -40
o
C to +95
o
C. Our standard product sizes are 6.5 and 7 inch in 16/9 format. They have the same optical quality as our
standard 4-wire products including an anti-scratch hard top coating with an anti-glare finish avoiding mirror effect. To solve
the problem of sunlight decreasing legibility, experienced in the automotive applications, Fujitsu developed a linear polarizer
that significantly reduces sunlight reflection.
SPECIFICATION AUTOMOTIVE TOUCH PANELS, FILM/GLASS
Item
Minimum frame size (one side of film side
Electrode is an object)
Flex tail side
Optical
Transparency
Transparency (luminance)
Reflection
Haze
Operation force
Surface Hardness
Linearity
Chattring
Insulation resistance
Operating temperature
Operation humidity
Storage temperature
Storage humidity
High temperature storage
Low temperature storage
High humidity storage
Transparency 82%
2.5mm and 4.0mm
7.0mm
82% typical*
-
18%
at 550 nm: 13%
5.5%
initial: 0.05 - 0.78N
after the test: 0.05 - 1.49N
> 3H
initial: < 1.5%
after the test: < 3.0%
< 20m sec
> 10M Ohm
-30
o
- 85
o
C
10% - 90% RH
-40
o
- 95
o
C
10% - 90% RH
95
o
C,192hrs
-40
o
C,192hrs
2.5mm: 60
o
C,90% RH,192hrs
4.0mm: 85
o
C,85% RH,192hrs
Transparency 88%
2.5mm and 4.0mm
7.0mm
88% typical*
-
10%
at 550 nm: 8%
5.5%
initial: 0.05 - 0.78N
after the test: 0.05 - 1.49N
> 3H
initial: < 1.5%
after the test: < 3.0%
< 20m sec
> 10M Ohm
-30
o
- 85
o
C
10% - 90% RH
-40
o
- 95
o
C
10% - 90% RH
95
o
C,192hrs
-40
o
C,192hrs
2.5mm: 60
o
C,90% RH,192hrs
4.0mm: 85
o
C,85% RH,192hrs
Linear Polarizer
4.4mm
7.0mm
-
77% typical*
at 550 nm: 8%
7%
initial: 0.05 - 0.78N
after the test: 0.05 - 1.96N
> 3H
initial: < 1.5%
after the test: < 3.0%
< 20m sec
> 10M Ohm
-30
o
- 80
o
C
10% - 90% RH
-40
o
- 85
o
C
10% - 90% RH
85
o
C,192hrs
-40
o
C,192hrs
60
o
C,90% RH,192hrs
Mechanical
Environmental
(maximum wet bulb
temperature 38
o
C)
Reliability
Note: *JIS K-7105
Page 3 of 04
CAPABILITY OVERVIEW
RESISTIVE TOUCH PANELS
4-WIRE AUTOMOTIVE SERIES, FILM/GLASS
4-WIRE AUTOMOTIVE SERIES | FILM/GLASS
Glass
1.1 mm
Part number
N010-0514-T003
N010-0514-T005
N010-0514-T101
Size
6.5”
6.5”
7.0”
Transparency
82%
88%
82%
Size ratio
16/9
16/9
16/9
Input
Finger
Finger
Finger
Control board:
Control board:
- similar toto 4-wire series (film/glass)
- similar 4-wire series (film/glass)
Control chip:
Control chip:
- similar toto 4-wire series (film/glass)
- similar 4-wire series (film/glass)
4-Wire Touch Panels, Film/Film/Plastic
Fujitsu has developed special film/film/plastic touch panels.
Available in sizes from 1 to 7 inch operating from -10
o
C to
60
o
C. The panels are flexible and cannot break even when
dropped. The film/film/plastic touch panels are based on
strong polycarbonate plate, offering the additional advantage
to protect the LCD in case of shock.
Control Engineering’s Editors’ Choice Award
Fujitsu’s line of high-transparency touch panels was awarded
the 2005 Editors’ Choice Award in the Human-Machine
Interface category by Control Engineering magazine.
Fujitsu’s high-transparency touch panels were among 45
products from various categories selected as the most
significant innovations from the thousands featured in the
2005 North American print edition of Control Engineering, in
its monthly and weekly e-mailed newsletter, and on its
www.controleng.com website. Editors judged the products
based on service to the industry, technological advancement
and market impact.
About Fujitsu Components Europe B.V.
Fujitsu Components Europe B.V. is responsible for managing
the sales, marketing and distribution of its connectors, relays,
KVM switches, touch panels, thermal printer mechanisms,
keyboards, and pointing and input devices, in Europe, Middle
East and Africa.
ASK FUJITSU COMPONENTS
Contact us on +31 (0) 23 556 0910 or
info@fceu.fujitsu.com
or visit
emea.fujitsu.com/components/
Page 4 of 04
