CLD-DS10 Rev 12H
Product family data sheet
Cree
®
XLamp
®
XR-C LEDs
PRoDuCt DEsCRiPtion
The
XLamp
®
XR-C
LeD
the
gives
lighting
designers
flexibility
FEAtuREs
•
Available in white (2600 K to
10,000 K CCT), royal blue, blue,
green, amber, red-orange & red
•
•
•
Maximum drive current: up to
700 mA
Low thermal resistance: as low as
12 °C/W
Maximum junction temperature:
150 °C
Industry-leading JEDEC standard
pre-qualification testing
•
•
•
•
•
Reflow solderable – JEDEC
J-STD-020C compatible
Electrically neutral thermal path
Lumen maintenance of greater than
70% after 50,000 hours
RoHS and ReACh compliant
UL
®
recognized component
(E349212)
tAbLE oF ContEnts
Characteristics - White, Royal Blue, Blue,
Green............................................................2
Characteristics - Amber, Red-Orange, Red
.2
Flux Characteristics - White
........................3
Flux Characteristics - Color
........................3
Relative Spectral Power Distribution
.........5
Relative Flux vs. Junction Temperature
.....6
electrical Characteristics ............................7
Relative Flux vs. Current
.............................8
Typical Spatial Distribution
.........................9
Thermal Design ........................................ 10
Reflow Soldering Characteristics
............ 11
Notes ........................................................ 12
Mechanical Dimensions ..........................
14
Tape and Reel ........................................... 15
Packaging .................................................
16
and performance to create the next
generation of LeD lighting products.
XLamp XR-C LEDs feature electrically
neutral thermal path, low thermal
resistance and support for a wide range
of drive currents.
Cree
XLamp
LEDs
bring
high
•
performance and quality of light to a
wide range of lighting applications,
including color-changing, portable and
personal, outdoor, indoor-directional,
transportation,
commercial
lighting.
stage
and
studio,
and
emergency-vehicle
www.CRee.Com/XLAmp
Copyright © 2007-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are
registered trademarks and the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
XLamp
®
XR-C LED
ChARACtERistiCs - WhitE, RoyAL bLuE, bLuE, GREEn
Characteristics
Thermal resistance, junction to solder point
Viewing angle (FWHM) - white
Viewing angle (FWHM) - royal blue, blue, green
Temperature coefficient of voltage
ESD classification (HBM per Mil-Std-883D)
DC forward current
Reverse voltage
Forward voltage (@ 350 mA) - white, royal blue, blue
Forward voltage (@ 350 mA) - green
Forward voltage (@ 500 mA) - white, royal blue, blue
LED junction temperature*
mA
v
v
v
v
°C
3.5
3.7
3.6
150
unit
°C/W
degrees
degrees
mV/°C
Minimum
typical
12
90
100
-4.0
Class 2
500
5
4.0
4.0
Maximum
* note: For lumen maintenance data, see the Cree XLamp LED Reliability document.
ChARACtERistiCs - AMbER, RED-oRAnGE, RED
Characteristics
Thermal resistance, junction to solder point
Viewing angle (FWHM)
Temperature coefficient of voltage - red-orange, red
Temperature coefficient of voltage - amber
ESD classification (HBM per Mil-Std-883D)
DC forward current - red-orange, red
DC forward current - amber
Reverse voltage
Forward voltage (@ 350 mA)
Forward voltage (@ 700 mA) - red-orange, red
LED junction temperature*
mA
mA
v
v
v
°C
2.2
2.4
150
unit
°C/W
degrees
mV/°C
mV/°C
Minimum
typical
15
90
-2.3
-1.8
Class 2
700
350
5
2.5
Maximum
* note: For lumen maintenance data, see the Cree XLamp LED Reliability document.
Copyright © 2007-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
2
XLamp
®
XR-C LED
FLuX ChARACtERistiCs - WhitE (t
J
= 25 °C)
The following tables describe the available colors and flux for XR-C LEDs by listing the correlated color temperature range for the entire
family and by providing several base order codes. It is important to note that the base order codes listed here are a subset of the total
available order codes for the product family. For more order codes, as well as a complete description of the order-code nomenclature,
please consult the XLamp XR LED Family Binning and Labeling document.
CCt Range
Minimum
Maximum
Minimum Luminous Flux
(lm)
Group
N3
N4
Cool White
5,000 K
10,000 K
P2
P3
P4
Q2
N3
N4
Neutral
White
3,700 K
5,000 K
P2
P3
P4
M3
N2
Warm White
2,600 K
3,700 K
N3
N4
P2
Flux (lm)
56.8
62.0
67.2
73.9
80.6
87.4
56.8
62.0
67.2
73.9
80.6
45.7
51.7
56.8
62.0
67.2
XRCWHT-L1-0000-00501
XRCWHT-L1-0000-00601
XRCWHT-L1-0000-00701
XRCWHT-L1-0000-00801
XRCWHT-L1-0000-00901
XRCWHT-L1-0000-00A01
XRCWHT-L1-0000-005E4
XRCWHT-L1-0000-006E4
XRCWHT-L1-0000-007E4
XRCWHT-L1-0000-008E4
XRCWHT-L1-0000-009E4
XRCWHT-L1-0000-003E7
XRCWHT-L1-0000-004E7
XRCWHT-L1-0000-005E7
XRCWHT-L1-0000-006E7
XRCWHT-L1-0000-007E7
Color
order Code
Notes:
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2 on
CRI measurements. See the Measurements section (page 12).
•
Typical CRI for Cool White & Neutral White (3,700 K – 10,000 K CCT) is 75.
•
Typical CRI for Warm White (2,600 K – 3,700 K CCT) is 80.
FLuX ChARACtERistiCs - CoLoR (t
J
= 25 °C)
Dominant Wavelength Range
Color
Minimum
Group
Royal
Blue
D3
DWL
(nm)
450
Maximum
Group
D5
DWL
(nm)
465
Minimum Radiant
Flux (mW)
Group
12
13
Flux (mW)
250
300
XRCROY-L1-0000-00701
XRCROY-L1-0000-00801
order Code
Copyright © 2007-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
3
XLamp
®
XR-C LED
FLuX ChARACtERistiCs - CoLoR (t
J
= 25 °C) - Continued
Dominant Wavelength Range
Color
Minimum
Group
Blue
B3
DWL
(nm)
465
Maximum
Group
B4
DWL
(nm)
475
Minimum Luminous
Flux (lm)
Group
G
H
Flux (lm)
13.9
18.1
XRCBLU-L1-0000-00G01
XRCBLU-L1-0000-00H01
order Code
Dominant Wavelength Range
Color
Minimum
Group
Green
G2
DWL
(nm)
520
Maximum
Group
G4
DWL
(nm)
535
Minimum Luminous
Flux (lm)
Group
M
N
Flux (lm)
39.8
51.7
order Code
XRCGRN-L1-0000-00M01
XRCGRN-L1-0000-00N01
Dominant Wavelength Range
Color
Minimum
Group
DWL
(nm)
Maximum
Group
DWL
(nm)
Minimum Luminous
Flux (lm)
Group
J
Flux (lm)
23.5
30.6
39.8
order Code
XRCAMB-L1-0000-00J01
XRCAMB-L1-0000-00K01
XRCAMB-L1-0000-00M01
Amber
A2
585
A3
595
K2
M2
Dominant Wavelength Range
Color
Minimum
Group
Red-
Orange
O3
DWL
(nm)
610
Maximum
Group
O4
DWL
(nm)
620
Minimum Luminous
Flux (lm)
Group
K2
M2
Flux (lm)
30.6
39.8
order Code
XRCRDO-L1-0000-00K01
XRCRDO-L1-0000-00M01
Dominant Wavelength Range
Color
Minimum
Group
DWL
(nm)
Maximum
Group
DWL
(nm)
Minimum Luminous
Flux (lm)
Group
J
Flux (lm)
23.5
30.6
39.8
order Code
XRCRED-L1-0000-00J01
XRCRED-L1-0000-00K01
XRCReD-L1-0000-00M01
Red
R2
620
R3
630
K2
M2
Note: Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements, ±2 on CRI
measurements and ±1 nm on dominant wavelength measurements. See the Measurements section (page 12).
Copyright © 2007-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
4
XLamp
®
XR-C LED
White
Relative Spectral Power Distribution
RELAtivE sPECtRAL PoWER DistRibution
White
100
Relative Radiant Power (%)
80
60
40
5000 K - 10000 K CCT
3700 K - 5000 K CCT
2600 K - 3700 K CCT
20
0
380
430
480
530
580
630
680
730
780
Wavelength (nm)
Color
Color
100
Relative Radiant Power (%)
80
60
40
Royal Blue
Blue
Green
Amber
Red-Orange
Red
20
0
380
430
480
530
580
630
680
730
780
Wavelength (nm)
Copyright © 2007-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
5
