LED PANEL MOUNT INDICATORS
507 SERIES CARTRIDGES FOR USE WITH HOLDERS & CLIPS
507-4762-3331-500
507-4862-3332-500
507-4962-3333-500
507-5062-3334-500
507-4757-3331-500
507-4857-3332-500
507-4957-3333-500
507-5064-3334-500
507-4759-3331-500
507-4859-3332-500
507-4959-3333-500
507-5066-3334-500
507-4760-3331-500
507-4860-3332-500
507-4960-3333-500
507-5067-3334-500
507-4761-3331-500
507-4861-3332-500
507-4961-3333-500
507-5068-3334-500
PART NO.
*
COLOR V
F
Red
Green
Yellow
Blue
Red
Green
Yellow
Blue
Red
Green
Yellow
Blue
Red
Green
Yellow
Blue
Red
Green
Yellow
Blue
2
2.1
2.1
3
5
5
5
5
10
10
10
10
14
14
14
14
28
28
28
28
mA mcd† FIG.
20
20
20
10
15
20
20
10
15
20
20
10
20
20
20
10
15
20
20
10
30
40
45
100
10
50
35
100
10
50
35
100
10
50
35
100
10
50
35
100
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
8.38
[.330]
6.73
[.265]
FIG. 3
28.96 [1.140]
5.16
[.203]
7.14
[.280]
FIG. 4
28.96 [1.140]
6.73
[.265]
5.16
[.203]
+
.51
[.020]
Polarity: To facilitate proper installation of the cartridge, the cartridge is
marked on the cartridge housing and the terminal base is keyed.
*
PART NUMBER ORDERING CODE
507 – xxxx – xx3x – 500
Series
Lens Shape:
33 – Fig 3 = Cylindrical
37 – Fig 4 = Stovepipe
† mcd intensity of LED
* Blue mcd rating with cylindrical cap is 100 mcd;
stovepipe cap is 275 mcd
250
13.1
[.515]
FLANGE
NUT
& 508 SERIES HOLDERS FOR 3/8" MOUNTING HOLE
HOLDER WITHOUT COLLAR
*
HOLDER WITH COLLAR
*
COLLAR
FLANGE
NUT
*
PART NUMBER ORDERING CODE
250 – xx38 – 14 – 504
508 – xx38 – 504
7.90
[.310]
15.90 [.625]
29.70 [1.170]
5.00
[.197]
7.10
[.280]
15.90 [.625]
29.70 [1.170]
5.00
[.197]
Series
Terminal Type:
87 = Turret Terminals
74 = Solder Blade (Not Shown)
75 = Solder Cups (Not Shown)
508-8738-504
Material & Finish: Housing, Cartridge and Holder - Black Anodized Aluminum. Cap -High Impact Plastic
Terminals of holders marked A and B. A = Positive
515 SERIES CONNECTORS & SPEED CLIPS FOR 9/32" MOUNTING HOLE
CARTRIDGE WITH SPEED CLIP & CONNECTOR
1.59 [.06]
PANEL
30.02 [1.19]
15.88
[.625]
CONNECTOR
515-0012
15.88 [.625]
CONNECTOR
515-0074
13.89
[.547]
4.76
[.188]
SPEED CLIP 515-0051
9.14
[.360]
6.86
[.270]
7.49
[.295]
† mcd intensity of LED
Material & Finish: Housing, Cartridge and Holder - Black Anodized Aluminum. Cap -High Impact Plastic
Dimensions in mm [inches]
