SMD PLCC
EAPL2835WD0
Features
PLCC-2 package
Top view white LED
High luminous intensity output
W ide viewing angle
Pb-free
RoHS compliant
ANSI Binning
The Everlight EAPL2835WD0 package has high efficacy, high CRI, low power consumption, wide viewing angle and
a compact form factor. These features make this package an ideal LED for all lighting applications.
1
˙
˙
˙
˙
˙
‧
‧
‧
‧
‧
‧
‧
Description
Applications
General lighting
Decorative and Entertainment Lighting
Indicators
Illumination
Switch lights
Copyright © 2015, Everlight Americas Inc.
. Release Date: 08.Oct. 2015. Issue No:
Issue No:
www.everlightamericas.com
DATASHEET
SMD PLCC
EAPL2835WD0
Mass Production List
Product
EAPL2835WD0
Notes:
1. Tolerance of Color Rendering Index: ±3
2. Tolerance of Luminous flux: ±11%.
CRI
Min.
(1)
80
CCT(K)
2700K
Φ(lm)
Min.
(2)
21
Φ(lm)
Max.
(2)
33
2
Copyright © 2015, Everlight Americas Inc.
. Release Date: 08.Oct. 2015. Issue No:
Issue No:
www.everlightamericas.com
DATASHEET
SMD PLCC
EAPL2835WD0
Device Selection Guide
Chip
Materials
InGaN
Emitted Color
Cool White
Neutral White
Warm White
Water Clear
Resin Color
Absolute Maximum Ratings (T
Soldering
=25℃)
℃
Parameter
Forward Current
Peak Forward Current (Duty 1/10 @10ms)
Power Dissipation
Operating Temperature
Storage Temperature
Thermal Resistance (Junction / Soldering point)
Junction Temperature
Soldering Temperature
Symbol
I
F
I
FP
P
d
T
opr
T
stg
R
th J-S
T
j
T
sol
Rating
75
100
250
-40 ~ +85
-40 ~ +100
50
125
Unit
mA
mA
mW
Hand Soldering : 350
Note:
The products are sensitive to static electricity and must be carefully taken when handling products
Electro-Optical Characteristics (T
Soldering
=25℃)
℃
Parameter
Luminous Flux
(1)
Forward Voltage
(2)
Color Rendering Index
(3)
Viewing Angle
Reverse Current
Symbol
Min.
21
2.8
80
-----
-----
Typ.
-----
-----
-----
120
-----
Max.
33
3.3
-----
-----
50
deg
µΑ
Unit
lm
V
Condition
I
F
=60mA
I
F
=60mA
I
F
=60mA
I
F
=60mA
V
R
=5V
Φ
V
F
Ra
2θ
1/2
I
R
Notes:
1. Tolerance of Luminous flux: ±11%.
2. Tolerance of Forward Voltage: ±0.1V.
3. Tolerance of Color Rendering Index: ±3
3
Copyright © 2015, Everlight Americas Inc.
. Release Date: 08.Oct. 2015. Issue No:
Issue No:
www.everlightamericas.com
℃
℃
Reflow Soldering : 260
for 10 sec.
for 3 sec.
℃
℃
℃
℃
/W
DATASHEET
SMD PLCC
EAPL2835WD0
Bin Range of Luminous Flux
Bin Code
M4
M42
N3
N31
N4
P3
Note:
Tolerance of Luminous flux: ±11%.
Min.
21
23
24
25
27
33
Max.
24
24
27
27
33
39
Unit
Condition
lm
I
F
=60mA
Bin Range of Forward Voltage
Group
Bin Code
35
36
2833
37
38
39
Note:
Tolerance of Forward Voltage: ±0.1V.
Min.
2.8
2.9
3.0
3.1
3.2
Max.
2.9
3.0
3.1
3.2
3.3
Unit
Condition
V
I
F
=60mA
4
Copyright © 2015, Everlight Americas Inc.
. Release Date: 08.Oct. 2015. Issue No:
Issue No:
www.everlightamericas.com
DATASHEET
SMD PLCC
EAPL2835WD0
The C.I.E. 1931 Chromaticity Diagram
Bin Range of Chromaticity Coordinates
CCT
Bin Code
CIE_x
0.4813
0.4687
27K-A
0.4621
0.4667
0.4627
0.4700
CIE_y
0.4319
0.4289
0.4169
0.4180
0.4109
0.4126
Reference Range:2580K~2700K
0.4687
2700K
27K-B
0.4562
0.4465
0.4539
0.4576
0.4621
0.4289
0.4260
0.4071
0.4088
0.4158
0.4169
Reference Range:2700K~2870K
0.4667
27K-F
0.4576
0.4539
0.4627
0.4180
0.4158
0.4088
0.4109
Reference Range: 2665K~2770K
27K-G
0.4627
0.4539
0.4502
0.4588
0.4109
0.4088
0.4020
0.4041
27K-C
0.4465
0.4373
0.4483
0.4544
0.4502
0.4539
0.4071
0.3893
0.3919
0.4030
0.4020
0.4088
27K-D
Bin Code
CIE_x
0.4700
0.4627
0.4588
0.4544
0.4483
0.4593
CIE_y
0.4126
0.4109
0.4041
0.4030
0.3919
0.3944
5
Copyright © 2015, Everlight Americas Inc.
. Release Date: 08.Oct. 2015. Issue No:
Issue No:
www.everlightamericas.com
