CBT-90 TE Product Datasheet
CBT-90 TE
Thermally Enhanced
LED Chipset
Features:
•
Large, monolithic chip with uniform emitting area of 9 mm
2
•
Wide color gamut available from Red , Green, Blue single color LEDs. White and UV
CBT-90 LEDs are also available with the same package format
•
Ultra High thermal conductivity package allows operation at up to 27A CW.
•
High precision LEDs placement on copper core PCB for easier thermal management
and optical integration
•
Unencapsulated die with low profile protective window optimizes optical coupling in
etendue-limited applications
•
Environmentally friendly: RoHS and REACH compliant
Table of Contents
Technology Overview . . . . . .2
Test Specifications . . . . . . . . .2
Ordering Information . . . . . .3
Monochrome Binning
Structure . . . . . . . . . . . . . . . . . .4
Monochrome Bin Kits . . . . . .6
Optical and Electrical
Characteristics . . . . . . . . . . . . .6
Angular Distribution and
Spectrum . . . . . . . . . . . . . . . . . .9
Thermal Resistance . . . . . . 10
Mechanical Dimensions . . 11
Packaging Information . . . 13
Revision History . . . . . . . . . 15
Applications
•
Fiber-coupled Illumination
•
Architectural and Entertainment
Lighting
•
Medical Lighting
•
Machine Vision
•
Microscopy
•
Displays and Signage
•
General Illumination
•
Spot Lighting
•
Emergency Vehicle Lighting
•
Projection Systems
1
PDS-002547 Rev 05
© 2017 Luminus Devices, Inc . - All Rights Reserved
Luminus Devices, Inc.
•
T
408.708.7000 • www.luminus.com
1145 Sonora Court • Sunnyvale, CA 94086
CBT-90 TE Product Datasheet
Technology Overview
Luminus LEDs benefit from a suite of innovations in the fields of chip technology, packaging and thermal management. These
breakthroughs allow illumination engineers and designers to achieve solutions that are high brightness and high efficiency.
Luminus LED Technology
Luminus’ Devices vertical chip LED technology enables large
area LED chips with uniform brightness over the entire LED chip
surface. The optical power and brightness produced by these
large monolithic chips enable solutions which replace arc and
halogen lamps where arrays of traditional high power LEDs
cannot.
Reliability
Designed from the ground up, Luminus LEDs are one of the
most reliable light sources in the world today. Luminus LEDs
have passed a rigorous suite of environmental and mechanical
stress tests, including mechanical shock, vibration, temperature
cycling and humidity, and have been fully qualified for use in
extreme high power and high current applications. With very
low failure rates and median lifetimes that typically exceed
60,000 hours, Luminus LEDs are ready for even the most
demanding applications.
Packaging Technology
Thermal management is critical in high power LED applications.
With a thermal resistance from junction to heat sink of 0.5º C/W,
Luminus CBT-90 LEDs have the lowest thermal resistance of any
LED on the market. This allows the LED to be driven at higher
current densities while maintaining a low junction temperature,
thereby resulting in brighter solutions and longer lifetimes.
Environmental Benefits
Luminus LEDs help reduce power consumption and the amount
of hazardous waste entering the environment. All LED products
manufactured by Luminus are RoHS compliant and free of
hazardous materials, including lead and mercury.
Understanding Luminus LED Test Specifications
Every Luminus LED is fully tested to ensure that it meets the high quality standards expected from Luminus’ products.
Testing of Luminus LEDs
Luminus core board products are typically measured in such a
way that the characteristics reported agree with how the
devices will actually perform when incorporated into a system.
This measurement is accomplished by mounting the devices on
a 40ºC heat sink and allowing the device to reach thermal
equilibrium while fully powered. Only after the device reaches
equilibrium are the measurements taken. This method of
measurement ensures that Luminus LEDs perform in the field
just as they are specified.
Expected flux values in real world operation can be extrapolated
based on the information contained within this product data
sheet.
2
PDS-002547 Rev 05
© 2017 Luminus Devices, Inc . - All Rights Reserved
Luminus Devices, Inc.
•
T
408.708.7000 • www.luminus.com
1145 Sonora Court • Sunnyvale, CA 94086
CBT-90 TE Product Datasheet
CBT-90 Monochromatic Binning Structure
All CBT-90 monochromatic LEDs are tested for luminous flux/ dominant wavelength and placed into one of the following flux/ wave
length bins. The binning structure is universally applied across each monochromatic color of the CBT-90 product line.
Flux Bins*
Color
Luminous Flux
Bin (FF)
BM
Red
BN
BP
BQ
CK
Green
CM
CN
G
Blue
H
J
K
Minumum Flux
(lm) @ 13.5A
770
970
1150
1350
1,500
2,000
2,300
Maximum Flux
(lm) @ 13.5A
970
1150
1350
1570
2,000
2,300
2,600
8.3
9.1
10.0
11.0
9.1
10.0
11.0
12.1
Min Power
(Watts) @ 13.5A
Max Power
(Watts) @ 13.5A
Wavelength Bins
Color
Wavelength Bin
R2
R3
Red (Dominant WL)
R4
R5
R6
G2
G3
Green (Dominant WL)
G4
G5
G6
G7
445
450
Blue (Peak WL)
455
460
465
*Note: Luminus maintains a +/- 6% tolerance on flux measurements.
3
PDS-002547 Rev 05
© 2017 Luminus Devices, Inc . - All Rights Reserved
Minumum Wavelength
@ 13.5A
611
615
619
623
627
510
515
520
525
530
535
445
450
455
460
465
Maximum Wavelength
@ 13.5A
615
619
623
627
631
515
520
525
530
535
540
450
455
460
465
470
Luminus Devices, Inc.
•
T
408.708.7000 • www.luminus.com
1145 Sonora Court • Sunnyvale, CA 94086
CBT-90 TE Product Datasheet
Ordering Information
Ordering Part Number
1,2,3
CBT-90-RX-L15-BM100
CBT-90-G-L11-CK100
CBT-90-B-L11-G100
Color
Red
Green
Blue
Description
Red LED CBT-90 consisting of 9 mm
2
LED, thermistor, and connector mounted on a
copper-core PCB.
Green LED CBT-90 consisting of 9 mm
2
LED, thermistor, and connector mounted on a
copper-core PCB.
Blue CBT-90 consisting of 9 mm
2
LED, thermistor, and connector mounted on a
copper-core PCB.
Part Number Nomenclature
CBT
Product Family
90
Chip Area
CC
Color
L##
Package Configuration
L15: 28 mm x 26.75 mm - Common
Cathode Package
L11: 28 mm x 26.75 mm - Common
Anode Package
See Mechanical Drawing section
FF###
Bin Kit
1,2,3
CBT: Copper-core
PCB, No Encap-
sulation
90: 9 mm
2
RX= Red
G= Green
B= Blue
See page 5
for complete bin
definition table
Note 1:
Note 2:
Note 3:
A Bin Kit represents a group of individual flux or power bins that are shippable for a given ordering part number. Individual flux bins are not orderable..
Flux Bin listed is minimum bin shipped - higher bins may be included at Luminus’ discretion
CBT-90-RX-L15-BM100 represents a red CBT-90 Device with a minimum Flux of 770lm and a Dominant Wavelength between 611-631nm
CBT-90-G-L11-CK100 represents a green CBT-90 Device with a minimum flux of 1500lm and a Dominant Wavelength between 510-540nm
CBT-90-B-L11-J100 represents a blue CBT-90 Device with a minimum Power of 10Watts and a Peak Wavelength between 445-470nm
4
PDS-002547 Rev 05
© 2017 Luminus Devices, Inc . - All Rights Reserved
Luminus Devices, Inc.
•
T
408.708.7000 • www.luminus.com
1145 Sonora Court • Sunnyvale, CA 94086
CBT-90 TE Product Datasheet
CBT-90 Orderable Bin Kits
Luminous Flux
Color
Min. Flux Bin
BM
Red
BN
CK
Green
CM
G
Blue
H
J
2,000 lm
8.30 W
9.10 W
10.0 W
970 lm
1,500 lm
Min. Flux/
Power
770 lm
Wavelength Bins
R2, R3, R4, R5, R6
R3, R4, R5
R2, R3, R4, R5, R6
R3,R4,R5
G2, G3, G4, G5, G6, G7
G4, G5, G6
G2, G3, G4, G5, G6, G7
G4, G5, G6
445,450,455,460,465
450,455,460
445,450,455,460,465
450,455,460
445,450,455,460,465
450,455,460
Kit Number
BM100
BM101
BN100
BN101
CK100
CK101
CM100
CM101
G100
G101
H100
H101
J100
J101
5
PDS-002547 Rev 05
© 2017 Luminus Devices, Inc . - All Rights Reserved
Luminus Devices, Inc.
•
T
408.708.7000 • www.luminus.com
1145 Sonora Court • Sunnyvale, CA 94086
