2.5x5mm RECTANGULAR SOLID LAMPS
L-383HDT BRIGHT RED
L-383IDT HIGH EFFICIENCY RED
L-383SRx SUPER BRIGHT RED
L-383GDT GREEN
L-383EDT ORANGE
L-383YDT YELLOW
L-383SGWT SUPER BRIGHT GREEN
Features
!
LOW
Description
The Bright Red source color devices are made with
Gallium Phosphide Red Light Emitting Diode.
The High Efficiency Red and Orange source color devices
are made with Gallium Arsenide Phosphide on Gallium
Phosphide Orange Light Emitting Diode.
The Green and Super Bright Green source color devices
are made with Gallium Phosphide Green Light Emitting
Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
The Super Bright Red source color devices are made with
Gallium Aluminum Arsenide Red Light Emitting Diode.
POWER CONSUMPTION.
BRIGHTNESS IS AVAILABLE.
AND RUGGED.
UNIFORMITY OF LIGHT OUTPUT.
FOR LEVEL INDICATOR.
!
ULTRA
!
RELIABLE
!
EXCELLENT
!
SUITABLE
!
LONG
LIFE - SOLID STATE RELIABILITY.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: KDA0290
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: SEP/15/2001
DRAWN: J.X.FU
PAGE: 1 OF 6
Selection Guide
Par t No .
L-383HDT
L-383IDT
L-383EDT
L-383GDT
L-383YDT
L-383SRDT
L-383SRWT
L-383SGWT
Dic e
BRIGHT RED (GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
ORANGE (GaAsP/GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
SUPER BRIGHT RED (GaAlAs)
SUPER BRIGHT GREEN (GaP)
L en s Ty p e
RED DIFFUSED
RED DIFFUSED
ORANGE DIFFUSED
GREEN DIFFUSED
YELLOW DIFFUSED
RED DIFFUSED
WHITE DIFFUSED
WHITE DIFFUSED
Iv (m c d )
@ 10 m A *20m A
Min .
0.5
3
3
1
1
*40
*40
*8
Ty p .
1
5
5
4
4
*70
*70
*15
V i ew i n g
An g l e
2θ1/2
110°
110°
110°
110°
110°
110°
110°
110°
Notes:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
2. * Luminous intensity with asterisk is measured at 20mA.
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
Par am et er
D ev i c e
Bright Red
High Efficiency Red
Orange
Green
Yellow
Super Bright Red
Super Bright Green
Bright Red
High Efficiency Red
Orange
Green
Yellow
Super Bright Red
Super Bright Green
Ty p .
700
627
627
565
590
660
565
660
625
625
568
588
640
568
45
45
45
30
35
20
30
40
15
15
15
20
45
15
2.25
2.0
2.0
2.2
2.1
1.85
2.2
2.5
2.5
2.5
2.5
2.5
2.5
2.5
10
Max .
Un it s
Tes t Co n d it io n s
λ
peak
Peak Wavelength
nm
IF=20mA
λ
D
Dominate Wavelength
nm
IF=20mA
∆λ
1/2
Bright Red
High Efficiency Red
Orange
Spectral Line Halfwidth Green
Yellow
Super Bright Red
Super Bright Green
Bright Red
High Efficiency Red
Orange
Green
Yellow
Super Bright Red
Super Bright Green
Bright Red
High Efficiency Red
Orange
Green
Yellow
Super Bright Red
Super Bright Green
All
nm
IF=20mA
C
Capacitance
pF
VF=0V;f=1MHz
V
F
Forward Voltage
V
IF=20mA
I
R
Reverse Current
uA
V R = 5V
SPEC NO: KDA0290
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: SEP/15/2001
DRAWN: J.X.FU
PAGE: 2 OF 6
Absolute Maximum Ratings at T
)
=25°C
°
Par am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
B r ig h t
R ed
12 0
25
12 0
5
Hig h
E f f i c i en c y
R ed
105
30
16 0
5
Or an g e
105
30
16 0
5
Gr een
10 5
25
140
5
Yello w
105
30
140
5
S u p er
B r ig h t
R ed
100
30
155
5
S u p er
B r ig h t
Gr een
105
25
14 0
5
Un it s
mW
mA
mA
V
-40
°
C To +85
°C
260
°
C For 5 Seconds
Bright Red L-383HDT
SPEC NO: KDA0290
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: SEP/15/2001
DRAWN: J.X.FU
PAGE: 3 OF 6
