Part Number:
Status:
Overview:
Description:
0307004161
Active
H-DAC 64™ Dual-Row High Density Automotive Connectors
2.54mm Pitch, H-DAC 64 High Density Automotive Header, Dual Row, Vertical, 16
Circuits, Polarization Option 2, Black, Tray
Documents:
3D Model
Drawing (PDF)
General
Product Family
Series
Application
Comments
Overview
Product Name
UPC
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Product Specification PS-30700-0001-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
PCB Headers
30700
Power, Wire-to-Board
Polarization Option 2
H-DAC 64™ Dual-Row High Density Automotive
Connectors
H-DAC 64
800756066882
No
16
16
Black
10
No
No
No
None
Yes
Copper
Tin
Nickel
Modified Polystyrene
6.250/g
2
Vertical
3.69mm
Yes
Yes
1.57mm
Tray
2.54mm
Yes
Yes
Fully
No
No
-40°C to +100°C
Through Hole
7.0A
500V DC
EU ELV
Compliant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Not Relevant
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Relevant
Compliant
Not Contained
Search Parts in this Series
30700 Series
Mates With
H-DAC 64 Housing 30700-1168
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
040
SMC&WAVE
003
260
PS-30700-0001-001
SD-30700-420
