234-100-H2Z113-98PN datasheet, PDF

Datasheet> All Categories > The connector> The connector> 234-100-H2Z113-98PN

234-100-H2Z113-98PN: DescriptionCircular MIL Spec Connector BOX MT HERM RECEPT PIN SOLDER CUP; CategoryThe connector The connector; File Size140KB，1 Pages; ManufacturerGlenair; Websitehttp://www.glenair.com/

Download Datasheet Parametric Compare View All

234-100-H2Z113-98PN Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	234-100-H2Z113-98PN	-	-	View	Buy Now

234-100-H2Z113-98PN Overview

Circular MIL Spec Connector BOX MT HERM RECEPT PIN SOLDER CUP

234-100-H2Z113-98PN Parametric

Parameter Name	Attribute value
Maker	Glenair
Reach Compliance Code	compliant
Factory Lead Time	17 weeks
Other features	STANDARD: MIL-DTL-38999, EMI SHIELDED
Back shell type	SOLID
Body/casing type	RECEPTACLE
Connector type	MIL SERIES CONNECTOR
Contact to complete cooperation	GOLD (50) OVER NICKEL
Contact completed and terminated	GOLD (50) OVER NICKEL
Contact point gender	MALE
Coupling type	SNAP
DIN compliance	NO
empty shell	NO
Environmental characteristics	CORROSION/MOISTURE/VIBRATION RESISTANT
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	YES
Manufacturer's serial number	234-100-H2
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	PANEL
Options	HERMETIC
Shell material	STAINLESS STEEL
Housing size	13
Termination type	SOLDER
Total number of contacts	10
Base Number Matches	1

Preview

Download Datasheet

View All

234-100-H2

Box Mount Hermetic Receptacle

MIL-DTL-38999 Series IV Type

How To Order:

Commercial

Connector Series

234

Series IV Type

Shell Style

- Hermetic Box Mount

Shell Size

11,13,15,17,19,21,23,25

Contact Termination

- Pin, Solder Cup

- Socket, Solder Cup

- Pin, Eyelet

- Socket, Eyelet

- Pin, PCB

- Socket, PCB

234

100

234-100-H2

Supercedes original

DLA equivalent part

number 230-010

Connector Type

100

Hermetic

Receptacle

Alternate Key Position

A, B, C, D, K, L, M, R, U

(N = Normal)

Connector Material / Finish

- CRES, Nickel

- CRES, Passivated

Insert Arrangement

Per MIL-STD-1560;

See Pages B-2 - B-4

Mounting Hole

Dimensions

4X ø G Holes

HERMETIC LEAK RATE MOD CODES

Designator

–585A

–585B

–585C

Required Leak Rate

1 x 10

-10

cc Helium per second

1 x 10

-9

cc Helium per second

1 x 10

-8

cc Helium per second

ø J Min

Back Panel

Mounting

ø H Min

Front Panel

Mounting

TABLE I: CONNECTOR DIMENSIONS

SHELL

SIZE

CODE

SHELL

SIZE

1.051(26.7)

1.008(25.6)

1.145(29.1)

1.102(28.0)

1.240(31.5)

1.197(30.4)

1.334(33.9)

1.291(32.8)

1.460(37.1)

1.417(36.0)

1.583(40.2)

1.539(39.1)

1.709(43.4)

1.665(42.3)

1.835(46.6)

1.791(45.5)

BSC

.812(20.6)

.906(23.0)

.969(24.6)

1.062(27.0)

1.156(29.4)

1.250(31.8)

1.375(34.9)

1.500(38.1)

DIA

.793(20.1)

.778(19.8)

.919(23.3)

.904(23.0)

1.044(26.5)

1.029(26.1)

1.170(29.7)

1.155(29.3)

1.294(32.9)

1.279(32.5)

1.419(36.0)

1.404(35.7)

1.544(39.2)

1.529(38.8)

1.670(42.4)

1.654(42.0)

DIA

.138(3.5)

.122(3.1)

.138(3.5)

.122(3.1)

.138(3.5)

.122(3.1)

.138(3.5)

.122(3.1)

.138(3.5)

.122(3.1)

.138(3.5)

.122(3.1)

.157(4.0)

.142(3.6)

.157(4.0)

.142(3.6)

øG

HOLES

±.005(0.1)

.128(3.3)

.154(3.9)

øH

MIN

.781(19.8)

.921(23.4)

1.047(26.6)

1.218(30.9)

1.296(32.9)

1.421(36.1)

1.546(39.3)

1.672(42.5)

øJ

MIN

.625(15.9)

.750(19.1)

.906(23.0)

1.016(25.8)

1.142(29.0)

1.266(32.2)

1.375(34.9)

1.484(37.7)

±.005(0.1)

.812(20.6)

.906(23.0)

.968(24.6)

1.062(27.0)

1.156(29.4)

1.250(31.8)

1.375(34.9)

1.500(38.1)

Printed in U.S.A.

Dimensions in Inches (millimeters) are subject to change without notice.

U.S. CAGE Code 06324

GLENAIR, INC.

•

1211 AIR WAY

•

GLENDALE, CA 91201-2497

•

818-247-6000

•

FAX 818-500-9912

www.glenair.com

B-83

E-Mail: sales@glenair.com

MIL-DTL-38999 Type

Hermetic Connectors
