Document 383-1
SMT Power Inductors –MSS7341 Series
The MSS7341 series is ideal for applications requiring
high power and high efficiency such as notebook com-
puters, wireless phones, PDAs and other handheld
products. It provides excellent current handling capabil-
ity in a rugged, low cost part.
These magnetically shielded power inductors are de-
signed for high-density mounting and are available on
tape and reel for auto-insertion. They are offered in 18
inductance values from 3.3 to 100 µH including values
not available in our other power inductor series.
Coilcraft
Designer’s Kit C185
contains samples of all
values shown. To order, contact Coilcraft or purchase
online at
http://order.coilcraft.com.
Part
number
1
L
2
(µH)
3.3 ±30%
5.0 ±30%
6.2 ±30%
7.4 ±30%
8.7 ±30%
10.0 ±20%
12.0 ±20%
15.0 ±20%
18.0 ±20%
22.0 ±20%
27.0 ±20%
33.0 ±20%
39.0 ±20%
47.0 ±20%
56.0 ±20%
68.0 ±20%
82.0 ±20%
100.0 ±20%
Irms
(A)
5
DCR SRF
3
4
20°
max
typ
Isat
40°
(Ohms) (MHz) (A) rise rise
0.020
0.024
0.027
0.031
0.034
0.038
0.053
0.057
0.078
0.082
0.109
0.124
0.138
0.155
0.202
0.276
0.324
0.358
58.0
46.0
42.0
40.0
35.0
32.0
26.2
22.5
24.0
21.5
19.0
18.0
17.0
14.2
13.4
12.0
11.0
10.5
3.5
2.9
2.5
2.3
2.2
2.0
1.7
1.6
1.5
1.3
1.2
1.1
1.0
0.95
0.85
0.75
0.70
0.65
3.95
3.40
3.05
2.80
2.80
2.80
2.45
2.05
1.85
1.70
1.50
1.50
1.50
1.50
1.25
1.00
1.00
0.90
5.00
4.70
4.30
4.10
3.90
3.80
3.30
3.00
2.65
2.35
2.10
1.95
1.90
1.85
1.60
1.35
1.25
1.15
1. When ordering, please specify
packaging
code:
MSS7341-104MXD
MSS7341-332NX_
MSS7341-502NX_
MSS7341-622NX_
MSS7341-742NX_
MSS7341-872NX_
MSS7341-103MX_
MSS7341-123MX_
MSS7341-153MX_
MSS7341-183MX_
MSS7341-223MX_
MSS7341-273MX_
MSS7341-333MX_
MSS7341-393MX_
MSS7341-473MX_
MSS7341-563MX_
MSS7341-683MX_
MSS7341-823MX_
MSS7341-104MX_
Packaging: D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape (1200 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter D instead.
2. Inductance measured at 100 kHz, 0.1 Vrms, 0 Adc using a Coilcraft
SMD-A fixture in an Agilent/HP 4284A impedance analyzer.
3. SRF measured using an Agilent/HP 8753D network analyzer and a
Coilcraft SMD-D test fixture.
4. DC current at which the inductance drops 25% (typ) from its value without
current.
5. Average current for temperature rise above 25°C ambient.
6. Storage and ambient operating temperature range
−40°C
to +85°C.
7. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
Specifications subject to change without notice.
Document 383-1
Revised 09/08/04
Document 383-2
SMT Power Inductors – MSS7341 Series
Typical L vs Frequency
1000
Typical L vs Current
1000
Inductance (µH)
33 µH
Inductance (µH)
100
100 µH
100
100 µH
33 µH
10
10 µH
10
10 µH
3.3 µH
3.3 µH
1.0
0.01
0.1
1.0
10.0
1.0
0.01
0.1
1.0
10.0
Frequency (MHz)
Current (A)
Temperature Rise vs Current
50
Dimensions
0.287 max
7,3
Temperature rise (from 25°C)
100 µH
33 µ
H
40
3.3 µ
H
30
XXX
0.260 typ
6,6
5.0
6.0
10
µH
0.287 max
7,3
20
0.161
max
4,1
10
0
0
1.0
2.0
3.0
4.0
0.280
7,1
Current (A rms)
0.083
typ 0.260 typ
2,1
6,6
0.083
2,1
0.280
7,1
Recommended
Land Pattern
Tape and reel:
1200/13″ reel 16 mm tape width
For packaging data see Tape and Reel Specifications section.
Specifications subject to change without notice.
Document 383-2
Revised 09/08/04
